Weight 1.00 lbs (0.45 kg) Voltage Range 90-146 Volts DC Sink Inputs 16 Backplane Current (5 Volts DC) 85 milliamps Signal delay 9 milliseconds Off State Current 0.8 milliamps
Weight 2.00 lbs (0.91 kg) Input Voltage 85 to 264 Volts AC, 1-Phase Input Current 35 milliamps maximum Input Frequency 45 to 63 Hertz Storage Temp. -40 to 85 degrees Celsius Rack Sizes 1/4, 1/2, 3/4, Full
No. of outputs Sixteen (16) outputs Operating Voltage Range 10-60VDC Nominal output voltage 48 VDC Minimum load current 2.5 mA Power Dissipation 15.6 Watts Thermal Dissipation 53.3 BTU/hr Max Continuous Current Per Output 2 Amps Max Continuous Current Per Module 8 Amps
Probe Type 8 mm High-Performance Eddy Current Probe Length 0.5 m Linear Range 2.0 mm (80 mils) Output Signal 4-20 mA Power Supply -18 to -26 VDC Cable Length 5.0 m Operating Temperature -35°C to +177°C (probe)
Probe Length 0.5 m Linear Range 4.0 mm (160 mils) Output Signal -2 to -18 VDC Power Supply -24 VDC Cable Length 7.0 m Operating Temperature -35°C to +120°C (probe)
Input Signals 2 independent Keyphasor inputs Input Range 0.5–150 Vrms (sine/triangle) Frequency Range 1–20,000 RPM Output Signals 4 buffered TTL/24 VDC pulses Power Consumption 5.6 W Operating Temperature 0°C to +65°C
Sensitivity 20 mV/mm/s (typical) Frequency Range 4.5–1000 Hz Measurement Range 0–20 mm/s RMS Power Supply 18–30 VDC, 2-wire Output Signal 4–20 mA (velocity proportional) Operating Temperature -50°C to +100°C
Probe Length 0.5 m Linear Range 2.0 mm (80 mils) Output Signal 4-20 mA Power Supply -18 to -26 VDC Cable Length 10 m Operating Temperature -35°C to +350°C (probe)
Sensitivity 100 mV/g (nominal) Frequency Range 0.5-10,000 Hz Measurement Range ±50 g peak Power Supply 18-30 VDC, 2-wire Output Signal 4-20 mA (velocity or acceleration) Operating Temperature -50°C to +120°C Connector MIL-C-5015 or integral cable Mounting M10 × 1.0 threaded stud
Linear Range 25.4 mm (1.0 in) Probe Length 3.0 m Output Signal 4-20 mA Power Supply -18 to -26 VDC Cable Length 10 m Operating Temperature -35°C to +177°C (probe) Connector 2-pin Eurofast
