SAFETY LEVEL
SIL 3
Safety system capability
|
CONFIGURATION
Dual Redundancy
Redundant control design
|
TEMPERATURE
−20 to 70 °C
Wide-range specification
|
| International Delivery on the Day Quick Response Support Intercontinental Cooperation Network |
✉ Email Sales ☏ WhatsApp |
| Yokogawa S2SC70D-FA12010 is a rack-mountable duplexed safety control unit for ProSafe-RS systems using N-IO and FIO. The code specifies the wide-temperature -20 to 70 °C execution with fan unit and ISA Standard G3 treatment, a pair of S2CP471 processor modules, dual-redundant Vnet/IP, dual-redundant power supplies, 220 to 240 V AC input and no explosion-protection execution. |
INSTALLED FAMILY
ProSafe-RS Safety Instrumented System
SIL 3 · Dual Vnet/IP · 220–240 V AC
|
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| Product type | Duplexed safety control unit |
| Safety integrity | SIL 3 |
| Processor configuration | Two S2CP471 modules |
| Control network | Dual-redundant Vnet/IP |
| Power configuration | Dual-redundant, 220 to 240 V AC |
| Temperature execution | -20 to 70 °C with fan unit |
| Environmental treatment | ISA Standard G3 |
| Approximate weight | 13 kg |
|
SYSTEM POSITION
SIL 3 · Dual Vnet/IP · 220–240 V AC
|
This unit forms the redundant processing core of a ProSafe-RS safety control station. It stores and executes the safety application, communicates through dual Vnet/IP paths and connects N-IO nodes or safety node units through the appropriate bus couplers. Up to eight FIO modules can be installed in the unit, subject to slot and bus-interface restrictions. |
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| MODEL / FAMILY | RATING OR ROLE | SELECTION POINT |
| S2SC70D-FA12010 | Duplexed; S2CP471; 220–240 V AC | This model |
| S2SC70S-FA12010 | Single safety control unit | Different redundancy architecture |
| S2SC70D-SA12010 | Standard-temperature execution | No wide-temperature fan execution |
| S2SC70D-FA11010 | 100–120 V AC execution | Different mains input |
| S2SC70D-FA14010 | 24 V DC execution | Different power input |
| 01 | Use the specified rack hardware, insulating bushes and M5 x 12 mounting screws for the fan-equipped unit. |
| 02 | Provide the correct 220 to 240 V AC supply, protective grounding and cabinet ventilation. |
| 03 | Install bus-interface modules only in permitted paired slots and observe the restrictions for slots 1 through 8. |
| 04 | Use two identical processor modules and maintain matching redundant network and power paths. |
| 05 | After service, verify processor synchronization, Vnet/IP redundancy, fan operation, power status and all safety diagnostics. |
|
