01 / PRODUCT IDENTIFICATION
HART Analog Input Module
|
| Yokogawa AAI135-H50 is an eight-channel analog input module for 4 to 20 mA field signals. Each channel is isolated, and the H execution adds HART digital communication over the current loop. The 5 code denotes a non-explosion-protected execution, while 0 denotes the basic environmental type. Style S3 identifies the installed hardware style and must be matched during replacement. |
INSTALLED FAMILY
CENTUM VP Field I/O
|
| Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
|
◆
|
02 / FUNCTIONAL DESCRIPTION
Signal or Power Role in the Installed System
|
| FUNCTIONAL PATH | The module acquires eight independent analog process signals and passes both the primary current value and supported HART data to the control system. Channel isolation helps limit interaction between loops. HART operation also depends on the field device, loop impedance, wiring and system configuration. |
|
◆
|
03 / TECHNICAL SPECIFICATIONS
Key Configuration Details
|
|
◆
|
04 / COMPATIBILITY AND RELATED MODELS
Select by Function, Suffix and Installed Platform
|
|
◆
|
05 / MODEL COMPARISON AND REPLACEMENT GUIDE
Replacement Checks Before Shutdown
|
| Identity: match the complete suffix and style. | Connection: verify the base, terminal block, adapter and field wiring. | System fit: confirm platform release, channel behavior and environmental execution. |
| Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
|
GLOBAL TEAM / RESPONSIVE SUPPORT
|
PRODUCT CHECKING / QUALITY FOCUS
|
WAREHOUSE NETWORK / URGENT DISPATCH
|
| International coordination for planned and urgent requirements. | Careful catalog-code checking before quotation and dispatch. | Support for active and discontinued automation components. |
| Contact us within seven days if a concern appears after delivery. | Return the item in its original condition with the reason stated. Resolution follows receipt and inspection. | Return-related transport costs are arranged by the buyer. |
|
◆
|
06 / TECHNICAL FAQ
Five Checks Buyers Should Complete
|
| 01 |
AAI135-H50 S3 - What is the most important ordering check?
Match the complete model, suffix code and style with the installed unit; the base model alone is not sufficient.
|
| 02 |
AAI135-H50 S3 - Can a related model be used as a direct substitute?
Only after channel count, signal type, isolation, termination, environmental execution and supported system release are confirmed.
|
| 03 |
AAI135-H50 S3 - What should be recorded before removal?
Record slot position, terminal assignment, field polarity, connected base or terminal block, and all visible suffix and style markings.
|
| 04 |
AAI135-H50 S3 - What should be tested after installation?
Verify seating, wiring, power and diagnostics, then commission each affected channel under controlled conditions.
|
| 05 |
AAI135-H50 S3 - What should be sent with a quotation request?
Send the full catalog code, quantity, required condition, destination and clear photos of the unit label and front connection area.
|
|
◆
|
