GE FANUC / SERIES 90-30
IC693PBM200
PROFIBUS-DP Master Module
|
NETWORK
|
|
◎ NETWORK
PROFIBUS-DP
Master module
|
⇄ DATA RATE
Up to 12 Mbps
Supported standard rates
|
▦ SLAVES
Up to 125
DP slave devices
|
| International Delivery on the Day Quick Response Support Intercontinental Cooperation Network |
✉ Email Sales ☏ WhatsApp |
| GE Fanuc IC693PBM200 is a PROFIBUS-DP master module for Series 90-30 PLC systems. It allows the host CPU to exchange cyclic I/O data with as many as 125 DP slaves, supports standard PROFIBUS data rates from 9.6 kbaud through 12 Mbaud, and provides network and module diagnostics. |
INSTALLED FAMILY
Series 90-30
125 SLAVES / 12 MBAUD / DB9
|
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| Product type | PROFIBUS-DP master module |
| Host platform | Series 90-30 |
| Maximum slaves | 125 DP slaves |
| Per-slave capacity | Up to 244 input and 244 output bytes |
| Data rates | 9.6 kbaud to 12 Mbaud |
| Network connector | Female 9-pin D-sub |
| Service connector | Male 9-pin RS-232 for firmware service |
| Backplane load | 450 mA typical at 5 VDC |
| CPU requirement | Firmware 8.00 or later |
| Mounting | Any baseplate slot except slot 1 of a modular CPU baseplate |
|
SYSTEM POSITION
125 SLAVES / 12 MBAUD / DB9
|
The module is the class-1 PROFIBUS master between a Series 90-30 CPU and distributed DP devices. It controls cyclic data exchange, supports Sync and Freeze functions, and exposes slave status, diagnostics and network counters. It does not provide redundant-master operation. |
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| MODEL / FAMILY | RATING OR ROLE | SELECTION POINT |
| IC693PBM200 | PROFIBUS-DP master | This model |
| IC693PBS201 | PROFIBUS-DP slave module | Slave rather than master role |
| IC695PBM300 | RX3i PROFIBUS master | Different controller platform |
| IC693CMM311 | Serial communications coprocessor | Not a PROFIBUS master |
| IC693BEM331 | Genius bus controller | Different fieldbus |
| 01 | Use a supported Series 90-30 CPU with firmware 8.00 or later and compatible configuration software. |
| 02 | Do not install the module in slot 1 of a modular CPU baseplate. |
| 03 | Use PROFIBUS cable and connectors with correct shield bonding, segment length and termination at both physical ends. |
| 04 | Match the configured baud rate, station addresses and slave I/O sizes to the installed network. |
| 05 | After commissioning, check SYS and COM indications, slave status, diagnostic arrays and network error counters. |
|
