GE FANUC / SERIES 90-30
IC694PWR321B
PLC Power Supply Module
|
90-30 PLC |
|
01 INPUT
120/240 VAC
AC rated input
|
02 DC OPTION
125 VDC
Rated DC input option
|
03 OUTPUT
30 W Max.
Combined output limit
|
| International Delivery on the Day Quick Response Support · Intercontinental Cooperation Network |
✉ Contact Sales ☏ WhatsApp |
| GE IC694PWR321B is a 30 W standard power supply for PACSystems RX3i serial expansion backplanes. It accepts 120/240 VAC or 125 VDC input and provides the regulated backplane rails used by compatible IC694 modules. Although its total capacity is 30 W, the +5 VDC output is limited to 15 W. |
INSTALLED FAMILY
PACSystems RX3i Serial Expansion
120/240 VAC OR 125 VDC / 30 W
|
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| Product type | Standard expansion-backplane power supply |
| Input | 120/240 VAC or 125 VDC |
| Total load capacity | 30 W maximum |
| +5 VDC output | 5.0 VDC; 15 W maximum |
| +24 VDC relay output | 24 VDC nominal |
| Isolated +24 VDC | Available for supported loads |
| Installed platform | RX3i serial expansion backplane |
| Revision suffix | B hardware revision |
| Protection focus | Calculate all rail loads before installation |
| Mounting | Dedicated power-supply position on IC694 backplane |
|
SYSTEM POSITION
120/240 VAC OR 125 VDC / 30 W
|
This supply energizes the logic and auxiliary rails of an RX3i serial expansion backplane. It is not the IC695 universal-backplane power supply. Correct selection therefore depends on the backplane type, input source and calculated consumption on each output rail, especially the 15 W ceiling on +5 VDC. |
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| MODEL / FAMILY | RATING OR ROLE | SELECTION POINT |
| IC694PWR321B | 30 W; 120/240 VAC or 125 VDC | This model and revision |
| IC694PWR330 | 30 W high-capacity +5 VDC execution | Different rail allocation |
| IC694PWR331 | 24 VDC input supply | Different input source |
| IC695PSA040 | 40 W AC universal-backplane supply | Not for IC694 serial expansion backplane |
| IC695PSD040 | 40 W DC universal-backplane supply | Different backplane and input |
| 01 | Verify that the target is an IC694 serial expansion backplane, not an IC695 universal backplane. |
| 02 | Isolate the mains/DC source and confirm protective grounding before removing the supply. |
| 03 | Calculate total watts and individual rail loading; observe the 15 W maximum on +5 VDC. |
| 04 | Match the input wiring to the actual 120/240 VAC or 125 VDC source and secure all terminals. |
| 05 | After energization, confirm the supply indicators and verify stable operation of every expansion module. |
|
