GE FANUC / VERSAMAX
IC200MDL650M
Discrete DC Input Module
|
INPUT / DC
|
|
▦ POINTS
32 Inputs
4 groups of 8
|
ϟ VOLTAGE
24 VDC
Nominal input
|
◷ RESPONSE
0.5 ms
Maximum on/off response
|
| International Delivery on the Day Quick Response Support · Intercontinental Cooperation Network |
✉ Email Sales ☏ WhatsApp |
| GE IC200MDL650M is a VersaMax discrete input module with 32 points arranged as four groups of eight. It accepts 24 VDC positive- or negative-logic field signals and reports each input state to the VersaMax backplane. The M suffix is the hardware revision and should be retained when evaluating a replacement. |
INSTALLED FAMILY
VersaMax I/O
32 DI / 24 VDC / 4 GROUPS
|
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| Product type | Discrete input module |
| Input points | 32, arranged as four groups of eight |
| Input voltage | 0 to 30 VDC; 24 VDC nominal |
| Logic compatibility | Positive or negative logic |
| ON-state voltage | 15 to 30 VDC |
| OFF-state voltage | 0 to 5 VDC |
| Input current | 2.0 to 5.5 mA ON; up to 0.5 mA OFF |
| Response | 0.5 ms maximum; filter 0, 1 or 7 ms |
| Backplane load | 50 mA maximum at 5 VDC |
| External supply | Not required by the module |
|
SYSTEM POSITION
32 DI / 24 VDC / 4 GROUPS
|
The module forms the discrete sensing layer of a VersaMax station. Four isolated groups receive switches, proximity devices and other 24 VDC signals; point LEDs show field state while the OK LED confirms backplane power. It mounts on a compatible VersaMax terminal-style or connector-style carrier. |
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| MODEL / FAMILY | RATING OR ROLE | SELECTION POINT |
| IC200MDL650M | 32-point 24 VDC input | This model and revision |
| IC200MDL650L | Same catalog family | Earlier hardware revision |
| IC200MDL643 | 16-point 5/12/24 VDC input | Lower density, different input range |
| IC200MDL640 | 16-point 24 VDC input | Lower point count |
| IC200MDL750 | 32-point 24 VDC output | Opposite signal direction |
| 01 | Confirm the complete IC200MDL650M catalog code and carrier type before removal. |
| 02 | Record all four eight-point group commons and every terminal position; point-to-point isolation is not provided. |
| 03 | Remove field and station power before changing the module or carrier wiring. |
| 04 | Keep 24 VDC input wiring separated from noisy power conductors and maintain the intended positive- or negative-logic arrangement. |
| 05 | After installation, check the OK indicator and prove all 32 inputs from field device to controller logic. |
|
