Compact machine visualization with a 320 × 240 color TFT, resistive touch operation, serial connectivity and Ethernet project transfer.
BLANK OEM BEZEL / PANEL MOUNT
DISPLAY
5.7
INCH TFT
RESISTIVE TOUCH COLOR DISPLAY
◆ 320 × 240 PIXELS
✦ 16 MB FLASH + DRAM
◇ 12–30 VDC
⌁ RS-232 / RS-485
PRODUCT
01
INSTALLED ROLE
QuickPanel Visualization in a Compact Format
The IC754VBB06CTD is a Basic QuickPanel View terminal with a blank OEM bezel, 5.7-inch color TFT and resistive touch input. It provides machine visualization while the connected controller executes control logic.
Before replacement, confirm the complete catalog number, supply, communication assignments, installed project and required bezel arrangement.
EXACT-MATCH QUOTE
Send the full part number, quantity, condition and destination.
158 x 126 x 52 mm cutout envelope; NEMA 4/4X front
◇ SERIES / DIFFERENCE / SELECTION ◇
Where IC754VBB06CTD Fits in the QuickPanel Family
MODEL OR GROUP
DISPLAY / ROLE
KEY DIFFERENCE
WHEN IT FITS
IC754VBB06CTD
Basic View, color TFT, blank OEM bezel
Color visualization without local controller execution
Exact replacement for the same catalog number and project role
IC754VBB06MTD
Basic View, monochrome display, blank bezel
Monochrome screen changes the visual presentation
Only when the installed project and operator requirements allow monochrome
IC754VBL06CTD
Loaded View, color TFT
Expanded communication and storage capability
When the project requires the Loaded feature set rather than Basic View
QuickPanel Control
Visualization plus local control execution
Runs control logic; it is not only an operator display
Use only where the machine architecture requires the control-class platform
◆ PRACTICAL ADVANTAGES
• Color TFT improves recognition of alarms, status changes and process graphics. • Resistive touch operation suits compact panel installations. • Blank OEM bezel supports machine-builder branding and overlay integration. • Serial communication serves controller links while Ethernet supports project transfer. • The 12–30 VDC input range suits common industrial DC power arrangements.
✦ HOW TO CHOOSE
1. Match the complete IC754 catalog number, not screen size alone. 2. Confirm color versus monochrome and Basic versus Loaded role. 3. Verify supply voltage, serial wiring and controller protocol. 4. Preserve the application, communication settings and touch calibration. 5. Confirm bezel, gasket, cutout and mounting orientation before installation.
Selection rule: A similar 5.7-inch QuickPanel housing does not prove interchangeability. Runtime class, memory, display type, communication role, bezel arrangement and project compatibility must be checked together.
20 YEARS OF INDUSTRIAL AUTOMATION SUPPLY
Responsive Support for Critical Parts
QUALITY Careful handling of current and discontinued part numbers.
URGENT SHIPPING Responsive coordination for time-sensitive maintenance.
PART SEARCH Support for difficult automation spare requirements.
Returns and replacement: Contact us within seven days of receipt if a concern appears. Keep the item in its original condition and state the reason. A return or replacement is arranged after receipt and inspection; return shipping costs are paid by the buyer.
◇ PURCHASING FAQ ◇
Five Checks Before an Exact-Match Order
◈
IC754VBB06CTD: Can IC754VBB06CTD replace IC754VBB06MTD?
Not without project review. The CTD is color while the MTD is monochrome, so graphics, alarm colors and application behavior must be checked.
✣
IC754VBB06CTD: Does IC754VBB06CTD execute the machine control program?
It is a Basic QuickPanel View visualization terminal. The external controller remains responsible for machine logic.
⌁
IC754VBB06CTD: What should be backed up before replacing IC754VBB06CTD?
Save the operator project, serial-driver settings, Ethernet download settings, touch calibration and all OEM screen and overlay conventions.
◇
IC754VBB06CTD: Is the IC754VBB06CTD Ethernet port a general control-network interface?
This Basic model uses Ethernet for project download. Confirm the installed project communication path rather than assuming full runtime Ethernet connectivity.
✓
IC754VBB06CTD: What should be inspected during IC754VBB06CTD installation?
Check the blank bezel, OEM overlay, gasket, panel cutout, DC polarity, serial wiring, screen image and touch alignment before operation.
