POWER PATH
800
AMPERE CLASS
|
ALLEN-BRADLEY · POWERFLEX 7000
81001-450-51-R
Gate-Controlled Power for the MV Drive Cell
|
SGCT
SINGLE DEVICE
|
| The Allen-Bradley 81001-450-51-R is one 800 A symmetric gate commutated thyristor (SGCT) used in the power-electronic section of a PowerFlex 7000 medium-voltage drive. It is a single device, not a matched pair or trio. Correct selection depends on current class, assembly position and the complete installed drive configuration. |
INSTALLED FAMILY
PowerFlex 7000 Medium-Voltage Drive
POWER CELL / 800 A
|
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| Device format | Single 800 A SGCT |
| Installed family | PowerFlex 7000 |
| Replacement scope | One device; verify matched-set policy |
| Primary function | Medium-voltage power switching |
| Handling | ESD-sensitive power semiconductor |
| Selection key | Exact current class and suffix |
|
SYSTEM POSITION
POWER CELL / 800 A
|
The SGCT is a principal switching element in the drive power cell. Gate commands regulate the medium-voltage output waveform while the surrounding clamp, cooling and gate-drive assemblies manage electrical and thermal stress. |
| PRICE & AVAILABILITY | Sales manager: Miya zheng | EMAIL SALES | WHATSAPP 86-18020776792 |
| MODEL / FAMILY | RATING OR ROLE | SELECTION POINT |
| 81001-450-51-R | 800 A | Single SGCT — this model |
| 81001-450-52-R | 800 A | Matched set of two |
| 81001-450-53-R | 800 A | Matched set of three |
| 81004-286-51-R | 400 A | Different current class |
| 81001-451-61-R | 1500 A | Different current class |
| 01 | De-energize, isolate and verify absence of hazardous voltage before opening the power-cell area. |
| 02 | Use ESD controls and handle the semiconductor by its mechanical body; protect gate connections. |
| 03 | Preserve the original clamping stack, insulation placement, cooling contact and specified fastener sequence. |
| 04 | Do not mix current classes or substitute a visually similar SGCT. Confirm whether the installed cell requires a matched set. |
| 05 | After installation, inspect gate wiring, fiber/gate-drive connections, clearances and cooling contact before energization. |
|
