Allen-Bradley 700-HC14Z24 Gold-Contact Plug-In Control Relay

Allen-Bradley 700-HC14Z24
Allen-Bradley 700-HC14Z24
Allen-Bradley 700-HC14Z24

Allen-Bradley 700-HC14Z24 Gold-Contact Plug-In Control Relay

Calculate shipping
Quotation Request


CONTROL COMPONENT / 03
ALLEN-BRADLEY
700-HC14Z24
24 V DC COIL
General Purpose Miniature Relay
BULLETIN 700-HC


CONTACT DESIGN / RATINGS
Switching in a Compact Form
4PDT
Contact Arrangement
4 change-over poles
7 A
Contact Rating
Gold contacts
24 V DC   Coil Voltage
● International Delivery on the Day
● Quick Response Support
● Intercontinental Cooperation Network
AMIKON
Get in Touch

Sales Manager
Miya zheng
INDUSTRIAL AUTOMATION PARTS
ALLEN-BRADLEY · BULLETIN 700-HC

700-HC14Z24

Gold-Contact Plug-In Control Relay


A compact 24 VDC relay with four changeover poles and gold-plated AgNi contacts for dependable low-energy signal switching.

24 VDC COIL 4PDT 7 A
CONTACT CODE
4
CHANGEOVER POLES
A1 ⇄ A2
GOLD-PLATED AgNi
PLUG-IN BLADES
SOCKET ORDERED SEPARATELY
◆ LOW-ENERGY SIGNALS ✦ 50 MILLION MECHANICAL OPERATIONS ◇ 700-HN SOCKET FAMILY
PRODUCT
01

INSTALLED FUNCTION

Signal Switching Through a Socket-Mounted Relay

The 700-HC14Z24 combines a 24 VDC coil, 4PDT contact form and gold-plated contact surfaces in a compact plug-in body. The relay fits a compatible Bulletin 700-HN socket, allowing field wiring to remain at the socket.

Confirm coil voltage, contact form, contact material, socket catalog number and installed accessories before replacement.
EXACT-MATCH QUOTE
Send the model, quantity, condition and destination.
CONTACT MIYA ZHENG
Coil voltage 24 VDC
Contact arrangement 4PDT; four changeover contacts
Nominal contact current 7 A
Contact construction AgNi with 5 micrometre gold plating
Low-energy capability Gold-contact configuration for low-level signals
Connection Plug-in blade terminals; socket ordered separately
Mechanical life 50 million operations for DC coil version
Electrical life 100,000 operations minimum
Dimensions / protection 27.7 x 37.2 x 20.7 mm; IP20 with guarded socket
◇ SERIES / DIFFERENCE / SELECTION ◇

How 700-HC14Z24 Differs from Nearby Relay Options

MODEL OR ITEM SHARED FEATURE IMPORTANT DIFFERENCE SELECTION EFFECT
700-HC14Z24 4PDT plug-in relay 24 VDC coil; 7 A; gold-plated AgNi contacts Use for exact replacement and low-energy signal duty
700-HC14Z12 / Z48 Same contact form family 12 VDC or 48 VDC coil instead of 24 VDC Coil voltage must match the control circuit
700-HC24Z24 24 VDC coil and 4PDT form Silver-contact relative rather than the gold-contact configuration Do not substitute where low-level signal reliability requires gold contacts
700-HN sockets Mounting and wiring partner Terminal layout, retention and accessory options depend on socket type Confirm the installed socket rather than choosing by relay outline
◆ PRACTICAL ADVANTAGES
• Gold-plated contacts support reliable switching of low-energy signals.
• Four changeover poles provide multiple isolated switching paths in one relay.
• Plug-in construction simplifies relay replacement while wiring remains at the socket.
• The 7 A rating covers a broad range of control-circuit loads when applied within contact ratings.
• Long mechanical life supports frequently operated control applications.
✦ HOW TO CHOOSE
1. Match the 24 VDC coil supply.
2. Confirm that the circuit requires four changeover poles.
3. Check whether low-energy duty requires gold contacts.
4. Verify load type, current and switching frequency.
5. Match the 700-HN socket, retention hardware and indication options.
Selection rule: Matching coil voltage and contact count is not enough. Contact material, socket compatibility, load characteristics and optional indication or test hardware must also agree with the installed circuit.
20 YEARS OF INDUSTRIAL AUTOMATION SUPPLY

Responsive Support for Critical Parts

AMIKON automation service
AMIKON automation service
AMIKON automation service
QUALITY
Careful handling of current and discontinued part numbers.		 URGENT SHIPPING
Responsive coordination for time-sensitive maintenance.		 PART SEARCH
Support for difficult automation spare requirements.
DIRECT SALES CONTACT
Miya Zheng
 EMAIL: sales@amikon.cnPHONE / WHATSAPP: 86-18020776792
Returns and replacement: Contact us within seven days of receipt if a concern appears. Keep the item in its original condition and state the reason. A return or replacement is arranged after receipt and inspection; return shipping costs are paid by the buyer.
◇ PURCHASING FAQ ◇

Five Checks Before an Exact-Match Order

◆
700-HC14Z24: Is 700-HC14Z24 supplied with a socket?
No. The relay is a plug-in component and the compatible 700-HN socket is selected separately for the panel wiring and accessory requirements.
✦
700-HC14Z24: Why do the gold contacts on 700-HC14Z24 matter?
Gold-plated contacts support dependable switching of low-energy signals. Do not choose a silver-contact variant solely because the outline is similar.
⌁
700-HC14Z24: Can 700-HC14Z24 replace a 700-HC24Z24?
Not automatically. Both may use a 24 VDC coil and 4PDT form, but their contact materials and low-energy switching characteristics differ.
⬡
700-HC14Z24: Does 700-HC14Z24 include an LED or test button?
The base catalog number has no additional option. Confirm any suffix if the installed relay requires indication or push-to-test hardware.
✓
700-HC14Z24: What should be checked before ordering 700-HC14Z24?
Confirm 24 VDC coil supply, 4PDT logic, load current and type, low-level signal requirement, socket catalog number and available panel clearance.
