Product Type 3300 XL 11 mm Proximity Probes Origin Made in U.S.A Certificate Of Origin (COO) Available as add-on Overall Case Length Option (050) 50 mm Total Length Option (10) 1.0 metre (3.3 feet)
Operating Voltage 220 V Frequency Range 30 kHz Probe Type Proximitor Probe Application Environment Industrial Machinery Material High-grade stainless steel
Material High-grade, corrosion-resistant Length Customizable, up to 10 meters Connector Type Standard Bently Nevada connector (compatible with 3300 XL NSv series) Temperature Range -40°C to +85°C Operating Voltage 12V DC
Main Module Operating Temp -30°C to +65°C (-22°F to +150°F) Main Module Storage Temp -40°C to +85°C (-40°F to +185°F) I/O Module Operating Temp 0°C to +65°C (+32°F to +150°F) I/O Module Storage Temp -40°C to +85°C (-40°F to +185°F) Humidity 95% non-condensing
Series 3500 Product Type Proximitor Seismic Monitor Module Dimensions 241.3 mm × 24.4 mm × 241.8 mm Weight 0.91 kg (2.0 lbs) Radiated Emissions EN 55011, Class A Conducted Emissions EN 55011, Class A
Operating Temperature -30°C to +65°C (-22°F to +150°F) Storage Temperature -40°C to +85°C (-40°F to +185°F) Humidity 95% non-condensing Contact Rating 5 A @ 24 Vdc or 120 Vac Arc Suppressor 250 Vrms (standard) Operation Mode Selectable Normally De-energized/Energized
Power Consumption 5.8 W (typical) Input Signal Range +10.0 V to -24.0 V Full Scale Range Up to 99,999 rpm RPM/Min Accuracy ±20 rpm/min Transducer Power Supply -24 Vdc, 40 mA max per channel Output Impedance 550 Ω Voltage Compliance 0 to +12 Vdc across 0-600 Ω load
Manufacturer Bently Nevada Product No. 135813-01 Product Type 3500/93 Display Interface I/O Module Origin Made in U.S.A Additional Certification Certificate Of Origin (COO) available
Part Number 330881-16-00-175-00-02 Manufacturer Bently Nevada Product Type Proximity Transducer Operating Temperature -35°C to +85°C Storage Temperature -51°C to +100°C Country of Manufacture USA (United States)
