Fiber First
IC200PNS002 uses two 100 Mbps multi-mode fiber ports, distinguishing it from IC200PNS001, which uses two 10/100 Mbps copper interfaces. |
Remote Node Scanning
The scanner interfaces a remote VersaMax node to a PROFINET IO-Controller, scans installed modules, retrieves input data, supplies output data and manages module configuration and PROFINET communication. |
| Parameter | IC200PNS002-AB |
| Product role | VersaMax PROFINET Scanner / IO-Device |
| Firmware revision | 1.10 for -AB revision |
| Fiber interface | Two 100 Mbps multi-mode fiber ports; SC-Duplex connectors |
| PROFINET | Version 2.3 Class A IO-Device |
| I/O data capacity | 2880 bytes total; 1440 input + 1440 output |
| I/O modules per station | Up to 8 |
| Update periods | 1, 2, 4, 8, 16, 32, 64, 128, 256 or 512 ms |
| USB | Micro-B, USB 2.0 full-speed, used for firmware upgrades |
| Status/control | 32 input status bits and 32 output control bits |
| Power | 1.10 A at 5 VDC |
| Dimensions | 132 mm H × 134 mm W; integrated carrier |
| Environment | 0 to 60°C surrounding air temperature without fan |
For IC200PNS002-AB, revision identity matters. The -AB release corresponds to firmware 1.10, while later -AC hardware revisions correspond to firmware 2.00 and add Hot-Standby CPU Redundancy support. The complete suffix should therefore be matched during replacement rather than treating every IC200PNS002 as identical.
| Device | Network interface | Selection logic |
| IC200PNS001 | 2 × RJ45 copper, 10/100 Mbps | Choose for copper Ethernet infrastructure |
| IC200PNS002-AB | 2 × multi-mode fiber, 100 Mbps | Choose when the VersaMax node requires fiber Ethernet connectivity |
| IC200GBI001-FG | Genius bus | Choose when the remote station belongs on a Genius network |
|
AMIKON LIMITED
Exact Revision? Let's Verify It.Send the complete IC200PNS002-AB part number when requesting availability. Our team can help check the revision, network interface and replacement requirements. Sales Manager: Miya zheng
|
sales@amikon.cn Phone / WhatsApp: +86 18020776792 |
| Delivery | 3–5 days | Warranty | 12 months |
| Packaging | Brand New | Payment | T/T |
| Shipping | E-packing / FedEx / EMS / TNT / DHL / UPS | ||
|
Why does IC200PNS002-AB use fiber instead of the copper interface used by IC200PNS001?
IC200PNS002 is the fiber version of the VersaMax PROFINET scanner family. It uses two 100 Mbps multi-mode fiber ports, while IC200PNS001 uses two 10/100 Mbps copper interfaces. |
What does the -AB suffix mean for an IC200PNS002 replacement?
The -AB revision corresponds to firmware 1.10. The revision should be matched because later revisions introduced additional functionality, including Hot-Standby CPU Redundancy in the -AC release. |
|
Can IC200PNS002-AB support a large VersaMax I/O station?
The scanner supports up to eight I/O modules per station and up to 2880 bytes of I/O data, divided into 1440 input bytes and 1440 output bytes. |
What should be checked before replacing IC200PNS002-AB?
Match the exact suffix, fiber interface, configured PROFINET device identity, power supply, installed I/O modules and project configuration. Also verify the fiber path and connector condition before commissioning. |
|
Does IC200PNS002-AB require a separate carrier?
No separate carrier is required. The PROFINET scanner has an integrated carrier arrangement. This simplifies the physical architecture of the VersaMax remote node. |
|
