Model Bently Nevada 330704-000-100-10-01-05 Function Radial Vibration Monitoring System Power Supply -24 VDC Components Proximitor, 8mm High-Temp Probe, 9.8m Armored Cable Measurement Range 2 mm Linearity ±1% Operating Temp. Range -40°C to +175°C Enclosure Rating IP67 / NEMA 4X
Type Industrial Control Circuit Board Material High-grade Copper Alloy Dimensions (W x H x D) 120mm x 100mm x 5mm Operating Temperature Range -20°C to +85°C Power Consumption 15W
Operating Temperature -20°C ~ +60°C (non-condensing) Operating Humidity 5% ~ 95% (non-condensing) Protection Class IP20 (panel mounting) Ethernet Speed 100 Mbps Profibus Speed Up to 12 Mbps Power Consumption ~10 W (typical) Power Supply 24V DC (±10%)
Part Time Rating 60A x 10 seconds (10% duty cycle) Continuous Rating 18A AC Supply Voltage 380V to 460V Trip Level (DC) 630V to 760V (User adjustable, 10 steps) Default Trip Level 760V (Highest) Min. External Resistor 12.8 Ohms Heat Loss 36W Enclosure Rating IP20 Dimensions (W x D x H) 120mm x 157mm x 150mm
Brand ABB Module Category Inverter Interface Series Advanced Inverter Components Input Voltage Range 200V – 690V AC Output Current Capacity 100A Communication Protocol Modbus TCP/IP Environmental Temperature Range -20°C to +50°C
Module 8102-HO-IP Description 8-channel, 4-20 mA output, HART support, non-incendive Outputs 8 single-ended Signal Range 4-20 mA (nominal), 1-23 mA (full) Accuracy ±0.25% of span Safety FM non-incendive (V<sub>oc</sub>=28.7V, I<sub>sc</sub>=33mA) Field Power 24V DC, 300 mA max
Number of Outputs 8 Outputs Voltage Category 120 Volts AC AC Operating Voltage 92-138 Volts Backplane Current 1.5 Amperes Max Continuous Current Per Output 1.5 Amperes Max Current Per Module 6 Amperes Wiring Arm 1771-WH
Interface Type Serial Supply Voltage - Min. 24 V Supply Voltage - Max. 24 V Minimum Operating Temperature 0 °C Maximum Operating Temperature +55 °C Brand HMS Networks Dimensions 120 mm x 75 mm x 27 mm
Operating Temperature 32°F to 140°F (0°C to 60°C) Storage Temperature -40°F to +185°F (-40°C to +85°C) Recommended Cable Belden 9463 Mounting Method In-Chassis Backplane Current 1 mA at 5V dc Lower Connector Keying 16 to 18
Analog Input (AI) 8 channels Input Range 0-10V / 4-20mA (configurable) Resolution 16-bit Sampling Rate 100 Hz/channel Typical Devices Temperature sensors, Pressure transmitters, Flow meters Digital Input (DI) 4 channels Input Voltage 24V DC (±10%) Isolation Voltage 2500V AC
Integrated Digital Inputs 4 x 24 V DC Integrated Digital Outputs 2 x 24 V DC / 0.5 A Integrated Analog Inputs 2 x U/I (Voltage/Current) Bit Processing Time 30 ns PROFINET Interface 2 x RJ45 (PROFINET IO IRT/RT & MRP)
Power Consumption Max 10 W Operating Temperature Range -10°C to 50°C Control Protocol BACnet, Modbus Communication Interface RS-485, Ethernet Memory Capacity 100 events Display Type LCD
