ABB CI810B 3BSE020520R1		 Advant Fieldbus 100 Interface
Full redundant media support
AF100 A
twisted pair
CI810B
FCI


 AF100 B
twisted pair
2 × AF100
media connections		 S800 I/O
field communication interface		 TB807
ModuleBus terminator included
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.
EMAIL QUOTE WHATSAPP +86 18020776792


S800 I/O · Advant Fieldbus 100
CI810B
3BSE020520R1 · AF100 Field Communication Interface

CI810B links an S800 I/O station to Advant Fieldbus 100. It combines the station interface and an integrated twisted-pair modem in one module, supporting long-distance field communication and redundant bus media where plant availability requires two independent paths.
2
AF100 twisted-pair connections		 1–79
station address range
Included: power-supply connector + TB807 Modulebus terminator
Communication Architecture
01
Fieldbus Interface

Transfers control and status traffic between the controller side and the distributed S800 I/O station over AF100.

 →
02
Redundant Media

Line 1 uses X2 and Line 2 uses X3, allowing two AF100 cable routes to serve the same station.

 →
03
Local Supervision

Front indicators support rapid checks of active state, station condition, communication and hardware or software events.
Design Point CI810B Configuration Project Value
Network medium Two AF100 twisted-pair ports Single or redundant cable routing
Station role FCI for an S800 I/O station Distributed I/O integration
Addressing Station address 1–79 Deterministic station identity
Bus termination TB807 supplied Completes the Modulebus end
Need a Quote for CI810B 3BSE020520R1?
Send the required quantity and destination to receive an availability and delivery response.
 Miya Zheng
Sales Manager		 EMAIL QUOTE WHATSAPP
SYSTEM RELATIONSHIP
Where CI810B Fits — and What Changes
Item Role / Difference Selection Impact
CI810B Single FCI module with integrated twisted-pair modem and dual AF100 media connections. Direct replacement path for CI810A applications after checking station engineering and firmware conditions.
CI810A Earlier AF100 FCI generation. CI810B is the later replacement; verify the installed base before exchange.
CI820V1 A different S800 I/O FCI architecture; redundant FCI arrangements use two CI820 units and associated termination hardware. Not a pin-for-pin substitute for CI810B; match the complete station topology.
S800 I/O modules Input and output modules reside behind the FCI on the station Modulebus. Check station address, module order, termination and AF100 media before commissioning.
Compatibility checkpoint: confirm the exact product code, S800 station architecture, AF100 cabling, station address and engineering state. Similar front-panel appearance does not establish interchangeability.
