Weight 2.00 lbs (0.91 kg) Input Voltage 85 to 264 Volts AC, 1-Phase Input Current 35 milliamps maximum Input Frequency 45 to 63 Hertz Storage Temp. -40 to 85 degrees Celsius Rack Sizes 1/4, 1/2, 3/4, Full
No. of outputs Sixteen (16) outputs Operating Voltage Range 10-60VDC Nominal output voltage 48 VDC Minimum load current 2.5 mA Power Dissipation 15.6 Watts Thermal Dissipation 53.3 BTU/hr Max Continuous Current Per Output 2 Amps Max Continuous Current Per Module 8 Amps
Probe Type 8 mm High-Performance Eddy Current Probe Length 0.5 m Linear Range 2.0 mm (80 mils) Output Signal 4-20 mA Power Supply -18 to -26 VDC Cable Length 5.0 m Operating Temperature -35°C to +177°C (probe)
Probe Length 0.5 m Linear Range 4.0 mm (160 mils) Output Signal -2 to -18 VDC Power Supply -24 VDC Cable Length 7.0 m Operating Temperature -35°C to +120°C (probe)
Input Signals 2 independent Keyphasor inputs Input Range 0.5–150 Vrms (sine/triangle) Frequency Range 1–20,000 RPM Output Signals 4 buffered TTL/24 VDC pulses Power Consumption 5.6 W Operating Temperature 0°C to +65°C
Sensitivity 20 mV/mm/s (typical) Frequency Range 4.5–1000 Hz Measurement Range 0–20 mm/s RMS Power Supply 18–30 VDC, 2-wire Output Signal 4–20 mA (velocity proportional) Operating Temperature -50°C to +100°C
Probe Length 0.5 m Linear Range 2.0 mm (80 mils) Output Signal 4-20 mA Power Supply -18 to -26 VDC Cable Length 10 m Operating Temperature -35°C to +350°C (probe)
Sensitivity 100 mV/g (nominal) Frequency Range 0.5-10,000 Hz Measurement Range ±50 g peak Power Supply 18-30 VDC, 2-wire Output Signal 4-20 mA (velocity or acceleration) Operating Temperature -50°C to +120°C Connector MIL-C-5015 or integral cable Mounting M10 × 1.0 threaded stud
Linear Range 25.4 mm (1.0 in) Probe Length 3.0 m Output Signal 4-20 mA Power Supply -18 to -26 VDC Cable Length 10 m Operating Temperature -35°C to +177°C (probe) Connector 2-pin Eurofast
Module Type 16-Channel Relay Contact Rating 2 A @ 30 VDC / 0.5 A @ 120 VAC Response Time ≤ 15 ms Power Consumption 5 W Isolation Voltage 1500 Vrms Operating Temperature 0°C to +65°C Mounting 3U high, rack slot module Certification CE, ATEX (optional)
Product Series 3300 XL Proximity Transducer System Probe Type 11 mm Eddy Current Linear Range 4.0 mm (160 mils) Probe Length 1.5 m Output Signal 4 20 mA Power Supply -18 to -26 VDC Cable Length 10 m Operating Temperature -35°C to +177°C (probe)
Measuring Range 0-1.2 mm (0-50 mils) Frequency Response 10-1000 Hz Output Signal 4-20 mA Power Supply 18-30 VDC Cable Length 5 m (integrated) Operating Temperature -40°C to +120°C (probe)
Frequency Range 1-20,000 RPM Output Signal Isolated digital pulse (24 VDC) Power Supply 18-30 VDC Operating Temperature -40°C to +85°C Housing Stainless steel, IP67
Linear Range 1.2 mm (50 mils) Output Signal 4-20 mA Power Supply 18-30 VDC Sensitivity 8 mA/mm (200 mA/inch) Cable Length 5 m Operating Temperature -40°C to +120°C (probe)
Output Signal 4-20 mA Power Supply 18-30 VDC Sensitivity 8 mA/mm (200 mA/inch) Cable Length 5 m Operating Temperature -40°C to +120°C (probe) Housing Rating IP67
Measuring Range 0-2.0 mm (80 mils) Frequency Response 0-10 kHz Output Signal 4-20 mA (2-wire) Power Supply 18-30 VDC Operating Temperature -40°C to +85°C Housing Stainless steel, IP67
Measuring Range 0-20 mm/s RMS Frequency Response 4.5-1000 Hz Output Signal 4-20 mA (2-wire) Power Supply 12-30 VDC Operating Temperature -40°C to +85°C
