| 7M | 2711P-RDT7CM is the marine-certified display module for a compatible Allen-Bradley PanelView Plus 6 700 modular terminal. It combines a 6.5-inch color TFT LCD with analog-resistive touch input, 640 × 480 resolution and a 132 × 99 mm active viewing area. It is the display assembly, not a complete operator terminal. | MARINE COLOR TOUCH DISPLAY MODULE Exact configuration matching comes first. |
|
DISPLAY
6.5-inch color TFT
|
RESOLUTION
640 × 480 pixels
|
TOUCH INPUT
Analog resistive
|
|
LUMINANCE
300 cd/m²
|
PANEL CUTOUT
220 × 154 mm
|
SPECIAL EXECUTION
Marine certified
|
|
TRACK 01
DISPLAY ROLE
|
The module supplies the screen, touch surface and front-panel assembly. Processing, memory, communications and the HMI application reside in the compatible logic module attached behind the display. | 1 |
|
TRACK 02
VISUAL PERFORMANCE
|
The color TFT presents 640 × 480 pixels across a 132 × 99 mm active area at 300 cd/m². Evaluate brightness uniformity, color, missing lines and surface condition when inspecting a replacement. | 2 |
|
TRACK 03
TOUCH SYSTEM
|
The analog-resistive touch surface is rated for one million actuations with a nominal 10 g operating force. Test response across the full active area rather than confirming only the center. | 3 |
|
TRACK 04
BACKLIGHT LIFE
|
The CCFL backlight has a stated minimum life of 50,000 hours. Reduced brightness or uneven illumination can indicate display aging even when the terminal still boots correctly. | 4 |
|
TRACK 05
MARINE EXECUTION
|
The M suffix marks the marine-certified version. Preserve the matching gasket, mounting hardware and installation conditions required for the applicable NEMA and IP front-panel ratings. | 5 |
|
TRACK 06
LIFECYCLE PLANNING
|
The article was discontinued on December 30, 2021, with no planned direct Rockwell Automation replacement. Migration requires engineering review; a compatible spare still requires logic-module and application checks. | 6 |
| 2711P-RDT7CM | Touch, color TFT, marine-certified display module |
| 2711P-RDT7C | Touch, color TFT, standard display execution |
| Compatible logic module | Required to create an operating PanelView Plus terminal |
| Migration path | No planned direct replacement; conversion requires engineering review |
|
GLOBAL SUPPORT
Responsive multilingual service.
|
ORDER INSPECTION
Model checking and order tracking for every purchasing stage.
|
READY STOCK
Efficient delivery helps reduce downtime.
|
| ORDER CARE | Contact us within seven days if an order concern appears after receipt. | Keep the item in its original condition and provide a clear reason. A return or replacement is arranged after receipt and inspection. | The buyer covers return-related shipping costs. |
| Q1 | Is Allen-Bradley 2711P-RDT7CM a complete HMI terminal? | No. It is the display module. The correct PanelView Plus 6 logic module, communications and HMI application are also required. |
| Q2 | What does the M mean in Allen-Bradley 2711P-RDT7CM? | The M denotes the marine-certified display execution. A standard 2711P-RDT7C should not be substituted solely because its screen and connectors appear similar. |
| Q3 | What should be saved before replacing Allen-Bradley 2711P-RDT7CM? | Secure a valid HMI application backup and record the logic-module catalog, firmware, communication configuration and terminal settings before disassembly. |
| Q4 | Can Allen-Bradley 2711P-RDT7CM be replaced by a current terminal without changes? | No direct replacement is planned. Migration can affect the panel cutout, application conversion, communications, power, certification and operator behavior. |
| Q5 | How should a stored Allen-Bradley 2711P-RDT7CM be checked? | Inspect the LCD, backlight, overlay, bezel, gasket and connectors, then test touch response across the complete active area and confirm the marine marking. |
