POWERFLEX 7000 · XIO
|
STANDARD DRIVE INPUT / OUTPUT
80190-299-01/9
XIO BOARD ASSEMBLY
An internal PowerFlex 7000 control-board assembly for the standard drive input and output role. Correct selection depends on the complete suffix, hardware revision, assigned card slot and installed drive architecture.
|
|
BOARD FAMILY
80190-299 XIO assembly
|
SYSTEM ROLE
Standard drive input / output
|
PLATFORM
PowerFlex 7000 medium-voltage drive
|
|
CONFIGURATION
Assigned XIO card slot in drive setup
|
INSTALLATION
Internal drive control compartment
|
ORDERING
Match the complete suffix and hardware revision
|
| Signal path | The XIO board links external control points with the drive control architecture. Its assigned card slot must agree with the active drive configuration. |
| Standard role | A standard XIO is part of the normal drive package. Other XIO roles can be assigned for external faults, liquid cooling, Logix exchange, heat-pipe functions or special applications. |
| Service discipline | Power must be isolated and stored energy verified before cabinet access. Connector positions, terminal identification and board revision should be recorded before removal. |
| Commissioning | After installation, confirm card-slot assignment, terminal wiring, configurable outputs, permissives and interlocks before returning the drive to service. |
| Request Availability & Configuration Check
Send the complete catalog marking, drive identity and clear board photos for a precise match.
|
EMAIL MIYAWHATSAPP |
|
BEFORE INSTALLATION
Configuration Must Travel With the Board
Preserve terminal identity, connector orientation, cable routing and installed-board position. Confirm the complete catalog marking and hardware revision before energization. |
◇ |
Controlled Return to Service
01 · Apply ESD controls and isolate all hazardous energy.
02 · Inspect connectors, coatings, fibers and terminal markings. 03 · Install only in the verified board position. 04 · Validate indications, permissives and protection behavior. 05 · Observe the drive during a controlled restart. |
| ITEM | ROLE | PURCHASE CHECK |
|---|---|---|
| 80190-299-01/9 | Selected XIO assembly | Exact suffix/revision must match |
| 80190-299 family | XIO board family | Hardware variants may differ |
| Standard XIO | Normal drive I/O role | Typically assigned to Card #1 |
| Optional XIO roles | External fault, cooling or special use | Configured by assigned slot |
|
