Honeywell CC-TDOB01 Protected Field Termination Assembly board

Honeywell CC-TDOB01
Honeywell CC-TDOB01
Honeywell CC-TDOB01

Honeywell CC-TDOB01 Protected Field Termination Assembly board

Calculate shipping
Quotation Request



HONEYWELL / SERIES C I/O
CC-TDOB01
Digital Output 24V IOTA

Termination assembly for the compatible Series C 24 V digital output module.
TERMINATE · PROTECT · CONNECT
OUTPUT CONNECTION / PROTECTION
Built around the Series C 24 V digital output platform
01 / OUTPUT TYPE
24 V DC Digital
Bussed output system
02 / ASSOCIATED MODULE
CC-PDOB01
Digital output module
03 / PROTECTION BEHAVIOR
The associated output system detects field overcurrent and shuts down the affected point until the short-circuit condition is corrected.
CC-TDOB01 is the non-redundant IOTA; confirm the matching output module and terminal arrangement for your installation.

AMIKON LIMITED
Need the IOTA or module?
Tell us whether you need CC-TDOB01 or its associated CC-PDOB01.
✉ EMAIL SALES ☏ WHATSAPP
Miya zheng
sales manager
◇ International Delivery on the Day ◉ Quick Response Support ◎ Intercontinental Cooperation Network


H
CONTROL
SERIES C 24 V DC OUTPUT IOTA

HONEYWELL CC-TDOB01

Protected Field Termination for 32 Discrete Outputs

CC-TDOB01 is the 9-inch, non-redundant Series C Input Output Termination Assembly for the CC-PDOB01 electronics module. It provides field terminals, bussed 24 V DC distribution and the physical interface for thirty-two sourced digital outputs.
PURCHASING FOCUS
Match the complete article code, installed architecture and required accessories before release.
CHANNELS32 digital outputs
OUTPUT TYPE24 V DC source
CHANNEL CURRENT0.5 A maximum
ISOLATION1500 V field to system
FORMAT9-inch non-redundant IOTA
MATCHED IOMCC-PDOB01
CHECK THE COMPLETE ARTICLE NUMBER BEFORE ORDERING
Sales manager: Miya Zheng
 EMAIL A QUOTE WHATSAPP 86-18020776792
PRODUCT ENGINEERING

A Complete View of CC-TDOB01

01
IOTA function
The IOTA remains with the field wiring while the removable CC-PDOB01 module contains the active output electronics. This separation supports orderly module service without disturbing every field conductor.
02
Output architecture
Thirty-two source-type channels switch bussed 24 V DC to compatible discrete loads such as interposing devices, indicators and appropriately rated solenoid circuits.
03
Short-circuit response
When an output senses over-current, the affected channel shuts down, the point enters Manual and an over-current soft failure is reported. Other healthy channels can remain operating.
04
Open-wire supervision
The paired digital output arrangement supports open-wire detection. Diagnostic behavior depends on correct field power, load characteristics and channel configuration.
05
Electrical separation
The arrangement provides 1500 V field-to-system isolation. Cabinet grounding, shield practice and separation from higher-voltage conductors remain part of the installation design.
06
Polarity protection practice
External 24 V power must be checked before energizing. Reversed field power can damage the installed output module, so polarity testing belongs in the commissioning sequence.
07
Redundancy choice
CC-TDOB01 is the non-redundant IOTA. CC-TDOB11 is the related redundant option. The IOTA choice must match the availability philosophy and supported module arrangement.
08
Ordering checkpoint
Confirm IOTA code, CC-PDOB01 module code, redundancy requirement, terminal plug condition, field voltage, maximum load current, wiring orientation and spare fuse requirements.
SYSTEM RELATIONSHIP

Function, Compatibility and Selection Difference

MODEL SYSTEM ROLE SELECTION POINT

CC-TDOB01 Selected 24 V DC IOTA Non-redundant, 9-inch source-output termination for CC-PDOB01.

CC-TDOB11 Redundant 24 V DC IOTA Related termination when the supported redundant output architecture is required.

CC-TDOR01 Relay output IOTA Dry-contact path for loads that do not match the 24 V DC sourced-output design.

CC-PDOB01 Digital output IOM Active 32-channel electronics module installed on the appropriate output IOTA.

AMIKON INDUSTRIAL SUPPLY

Reliable Parts Support Across the Supply Cycle

Responsive TeamClear matching support for current and discontinued industrial automation parts.
Quality FocusArticle-code checks and practical order tracking help reduce procurement risk.
Delivery CommitmentEfficient global handling supports faster recovery from unplanned downtime.
QUALITY
Careful product matching		 RELIABILITY
Fast order response		 TRUST
Transparent communication		 SERVICE
Ongoing customer support
READY FOR A FAST AVAILABILITY CHECK?
Sales manager: Miya Zheng
 EMAIL A QUOTE WHATSAPP 86-18020776792
PURCHASING FAQ

Questions Buyers Ask Before Release

Does CC-TDOB01 include the CC-PDOB01 output electronics?
No. CC-TDOB01 is the termination assembly. The matching CC-PDOB01 electronic output module is a separate item unless explicitly included in the quotation.
Is CC-TDOB01 the correct choice for a redundant output pair?
No. CC-TDOB01 is the non-redundant 9-inch IOTA. Use the compatible redundant termination architecture when redundancy is required.
What load style is appropriate for CC-TDOB01?
It is intended for 24 V DC bussed, source-type discrete loads within the specified 0.5 A per-channel limit. Relay or sinking applications require the appropriate alternative IOTA.
What happens if a field short occurs on CC-TDOB01?
The output circuitry detects over-current, shuts down the affected channel, places that point in Manual and reports a soft failure; unaffected channels remain in operation.
What should be verified before energizing CC-TDOB01?
Confirm external supply polarity, field voltage, load current, grounding, terminal assignment, compatible CC-PDOB01 module and whether the project needs non-redundant or redundant termination.
Return and replacement terms
Contact us within seven days after receipt if a problem is found. Keep the item in its original condition and provide a clear reason for return. After the returned item is received and checked, a return or replacement can be arranged. Shipping costs related to the return are paid by the buyer.
MORE INDUSTRIAL PARTS

Related Model Directory

ABC4013-A 32-9826 KJ3201X1-BA1 5X00481G04
BP470-25.5 SY5440-5LU NT100-RE-CC/+ML ABC3090-A
F4000-15N-WM KJ3002X1-BH1 6RA7078-6DV62-0 F4000-W-BOWL-M1
IS210DTAIH1A 7XV124.50-12 FPM-3150G-XC AF30-03D-A
KJ3002X1-BG2 6SL3353-1AG41-8DA1 SB-DIM4c3A-DN 16J1Y0784R01
X20CP1584 VE4003S2B10 CC-PDIL51 KJ3002X1-BF1
6SN1145-1BB00-0FA1 EM-07K 1850-0L PSV-624-1 LQV157
CE4003S2B10 H3DE-S1 1756-EN2TR 6ES7322-8BF00-0AB0
DIN-AP2 2215-20523-001 DR4900 1X01047H01L
TSXPSY2600 1756-EN2T 6SL3310-1TE33-8AA3 XP10BKB/DC
PM861AK01 3BSE018157R1 PHC805 1C31199G05 DDNP1501
ADV551-P60 X20AI4632-1 X20SP1130 UTA85830
KJ3203X1-BA1 KL3007X1-BA1 GHQ6310062R0111 37103004
3DO650.6 X20DO8331 81-484-000 KJ3202X1-BA1
KJ4006X1-BK1 SB-3R-TC A03B-0824-C001 V600-D8KR12
NEED ANOTHER INDUSTRIAL AUTOMATION PART?
Sales manager: Miya Zheng
 EMAIL A QUOTE WHATSAPP 86-18020776792
Sales manager: Miya Zheng   |   sales@amikon.cn   |   Phone / WhatsApp: 86-18020776792
Hot Tags : Honeywell CC-TDOB01 Honeywell IOTA CC-TDOB01 datasheet Honeywell Experion PKS Series C CC-TDOB01 PDF CC-TDOB01 manual
