SERIES-A 13-SLOT CHASSIS

HONEYWELL TC-FXX132

Mechanical Capacity for a Structured Control Node

TC-FXX132 is a panel-mounted Series-A chassis with thirteen module positions. It provides the mechanical frame and backplane path used to assemble compatible controller, communication, interface and I/O hardware inside an Experion cabinet.

PURCHASING FOCUS
Match the complete article code, installed architecture and required accessories before release.

MODULE CAPACITY13 slots	OVERALL WIDTH58.8 cm	HEIGHT16.9 cm
DEPTH14.5 cm	APPROX. MASS1.9 kg without modules	MOUNTINGPanel mount

CHECK THE COMPLETE ARTICLE NUMBER BEFORE ORDERING

Sales manager: Miya Zheng

EMAIL A QUOTE

WHATSAPP 86-18020776792

PRODUCT ENGINEERING

A Complete View of TC-FXX132

01	Chassis purpose The chassis establishes module alignment, backplane engagement and cabinet mounting for a Series-A control node. Functional capability comes from the installed power, controller, communication and I/O modules.

02	Slot planning Thirteen positions provide more expansion room than a 10-slot chassis while requiring less cabinet width than the 17-slot version. Reserve positions for mandatory system modules before allocating I/O.

03	Physical envelope Dimensions with mounting tabs and power supplies are approximately 58.8 x 16.9 x 14.5 cm. Wiring duct, connector bend radius and service access require additional cabinet space.

04	Vertical clearance Maintain at least 15.2 cm between the chassis and cabinet boundary and 20.3 cm between vertically stacked chassis so cooling and maintenance access are not restricted.

05	Horizontal clearance Maintain at least 10.2 cm between the chassis and cabinet wall and between adjacent chassis. Check door hardware and side wiring routes before drilling the panel.

06	Power architecture Power-supply quantity and rating depend on the fitted modules and redundancy plan. Calculate slot loading and available capacity for the complete installed arrangement.

07	Migration work Moving from a 10-slot or 17-slot chassis changes mounting holes, cable reach, slot numbering and cabinet space. Preserve the original module map before dismantling the node.

08	Ordering checkpoint Confirm chassis code, populated slot map, power-supply codes, module codes, cabinet dimensions, backplane condition and connector photographs. A bare chassis and a populated assembly are different scopes.
