Transmission Rate 10/100 Mbps Supply Voltage 24 V DC Dimensions (approx.) 70 x 100 x 25 mm (W x H x D) Operating Temperature 0°C to 60°C Protection Rating IP20
Number of Channels 4 Input Types Voltage, Current, RTD, Thermocouple Resolution 16 bit Accuracy ±0.03% (voltage) Supply Voltage 24 V DC Power Consumption 1.3 W Dimensions 35 x 147 x 129 mm (W x H x D)
Product Type IM 155-5 PN HF Interface Module Interface Type PROFINET (High-Function) Transmission Rate 10/100 Mbps Supply Voltage 24 V DC Maximum Stations Up to 32 modules Dimensions 60 x 147 x 129 mm (W x H x D) Operating Temperature 0°C to 60°C
Memory 1 MB work memory Interfaces PROFINET, PROFIBUS DP Execution Speed 200 ns per bit instruction Ethernet Ports 2 x RJ45, 10/100 Mbps Supply Voltage 24 V DC Power Consumption 8 W typical Dimensions 35 x 147 x 129 mm (W x H x D)
Product Type 16-channel Digital Input Input Voltage 24 V DC Input Current Typically 2.5 mA Connection 40-pin front connector Status Indicators Diagnostic and status LEDs Dimensions 35x147x129 mm (WxHxD)
Product Type 16-channel Digital Output Output Type Transistor Supply Voltage 24 V DC Output Current 0.5 A per channel Total Current 4 A (all channels) Connection 40-pin front connector Dimensions 35x147x129 mm (WxHxD)
Transmission Rate 10 - 100 Mbit/s Ethernet Interfaces 1 Supply Voltage 15 V DC (from backplane) Power Consumption 3.3 W Dimensions (L×W×H) 129 × 35 × 142 mm
Rated Supply Voltage 24 V DC (±20%) Power Consumption Approx. 20 W Communication Interface PROFINET (2-port switch) Safety Function Integrated Safety (STO/SS1/SBC) Control Functions Vector control (sensorless/open-loop) Operating Temperature 0°C to +55°C (horizontal mount)
Model CPU 1212C DC/DC/DC Onboard I/O 8 DI 24V DC, 6 DO 24V DC, 2 AI 0-10V DC Power Supply 20.4 - 28.8 V DC Program/Data Memory 75 KB Communication Interface PROFINET Expansion Capability 3 Comm. Modules, 1 Signal Board, 2 Signal Modules Power Loss 9 W (Typical) Dimensions (WxHxD) 90 x 100 x 75 mm
Cellular 4G LTE Cat 4 Ethernet 2× Gigabit ports Serial 1× RS-232/RS-485 Voltage 9-36 V DC Temp Range -40°C to +75°C VPN IPsec/OpenVPN Protocols Modbus TCP/RTU, EtherNet/IP
Product Description 3300 XL 8 mm Probe, M10x1 thread, without armor Unthreaded Length 0.0 mm Overall Case Length 40 mm Total Length 0.5 metre (1.6 feet)
Unthreaded Length 0 mm Overall Case Length 50 mm Total Length 1.0 metres (3.3 feet) Connector Type Miniature coaxial ClickLoc connector Cable Type Standard cable Agency Approval Not required
Power Supply 24 V DC ±10% Module Type NETA-01 V1.x Mounting On to a standard mounting rail (DIN rail) Configuration Through drive parameters and/or DIP switches Current Consumption 80 mA at 24 V DC
