The 20-750-PBUS is the PROFIBUS DPV1 communication option for compatible PowerFlex 750-Series drives. It connects the drive to a PROFIBUS network through a female DB9 connector and provides local switches and status indicators for commissioning.
| Request Exact-Model Quote | sales@amikon.cn | WhatsApp 86-18020776792 |
| Sales manager: Miya zheng | ||
| Network | PROFIBUS DPV1 |
| Drive family | Compatible PowerFlex 750-Series drives |
| Network connector | Female PROFIBUS DB9 |
| Status display | Three status LEDs |
| Node setup | Seven node-address switches |
| Data alignment | Switch 8 selects the transmitted-data alignment |
| Configuration assets | Compatible GSD and option firmware |
| Lifecycle | Active product family |
| CATALOG NUMBER | RELATIONSHIP | SELECTION POINT |
| 20-750-PBUS | PROFIBUS DPV1 | Requested option |
| 20-750-ENETR | EtherNet/IP option | Different industrial network |
| 20-750-DNET | DeviceNet option | Different cabling and configuration |
| 20-COMM-P | Earlier PowerFlex PROFIBUS adapter | Not a direct 750-Series substitute |
| Confirm Compatibility with Miya | sales@amikon.cn | WhatsApp 86-18020776792 |
| Sales manager: Miya zheng | ||
| GLOBAL COOPERATION | INSPECTION COORDINATION | URGENT INTERNATIONAL DELIVERY |
| Check Price and Availability | sales@amikon.cn | WhatsApp 86-18020776792 |
| Sales manager: Miya zheng | ||
| 01 |
Will 20-750-PBUS work in every PowerFlex drive?
No. Confirm the exact PowerFlex 750-Series drive, supported option port, drive firmware and adapter firmware.
|
| 02 |
What must match in the controller project?
The station address, GSD selection, telegram or data layout, byte alignment and expected input/output length must agree.
|
| 03 |
Can 20-750-PBUS replace an EtherNet/IP option?
No. The network protocol, controller configuration, cabling and diagnostics are different.
|
| 04 |
Why can the drive be visible but not exchange process data?
A valid physical connection does not correct an address, GSD, telegram, byte-order or I/O-size mismatch.
|
| 05 |
What should be recorded before replacement?
Record the node switches, option port, drive and adapter revisions, parameter settings, connector termination and controller configuration.
|
