BENTLY NEVADA 200151-XX-XX-XX MOD: 323357-15-03-00 Accelerometer interface cable
|
CONDUCTORS
4
22 AWG construction
|
SHIELD
BRAIDED
Shield + drain wire
|
SEALING
IP67
When correctly mated
|
BEND RADIUS
63.5 mm
Minimum published value
|
|
MEASUREMENT CHAIN
From Sensor
to Monitoring Point The 200151 cable belongs to the accelerometer connection side of the vibration monitoring arrangement. It carries the sensor power and signal through a shielded four-conductor construction.
|
For a replacement, the complete base designation and MOD number should remain together. The special MOD configuration should be verified against the installed assembly before substitution.
|
|
|
|
APPLICATION & MAINTENANCE
When the Vibration Signal Path Matters
In a machine condition-monitoring installation, an accelerometer depends on a suitable cable path to transfer its signal to the monitoring equipment. A damaged jacket, compromised connector, poor shielding or excessive bending can interrupt the measurement chain or introduce uncertainty into vibration data.
|
REPLACEMENT CHECK
Match the Complete Configuration
Confirm the complete 200151 designation and MOD: 323357-15-03-00 before purchasing.
✓ Mating accelerometer
✓ Monitoring interface ✓ Cable routing ✓ Connector arrangement ✓ Complete MOD identification |
|
01
Why should the base number and MOD number be quoted together?
Because the base number identifies the cable family while the MOD designation defines a specific modified configuration. Keeping both identifiers together reduces the risk of matching a standard cable to a special installation.
|
02
What should be checked if the monitoring channel suddenly loses its signal?
Inspect the cable route, connector engagement, jacket condition and shield/drain continuity before replacing the monitoring electronics. A cable fault can interrupt the sensor-to-monitoring path.
|
|
03
Does the 200151 construction have protection against moisture at the connector?
The published series construction provides IP67 sealing at the connector when mated with the appropriate transducer and mating hardware.
|
04
Why does cable routing matter during replacement?
The published minimum bend radius for 200151 is 63.5 mm. Routing that places excessive bending stress on the cable can compromise long-term mechanical integrity.
|
|
05 · ORDERING DECISION
What should I send with my enquiry to avoid a configuration mismatch?
Provide the complete part number, MOD designation, quantity, destination, required date and the machine/system where the cable is installed. A nameplate photograph is also useful when the configuration is critical.
|
|
|
01
Global Shipping
International delivery coordination
|
02
Multilingual Team
Communication across markets
|
03
Flexible Sourcing
Hard-to-find automation parts
|
04
Worldwide
Open to global enquiries
|
|
REQUEST A QUOTE
Send the Complete Ordering Details
To reduce configuration errors, please include:
Part Number · Quantity · Destination · Required Date · Machine/System
|
COMMERCIAL TERMS
Delivery: 3–5 days
Warranty: 12 months Condition: New Delivery: E-packing / FedEx / EMS / TNT / DHL / UPS Payment: T/T |
|
