An in-rack flow computer that brings hydrocarbon gas and liquid measurement, calculation and Modbus connectivity into a 1771 PLC chassis.
The PROSOFT MVI71-AFC is a single-slot, 1771 backplane-compatible Liquid & Gas Flow Computer Module. It supports eight meter channels for hydrocarbon gas or liquid measurement. Process values from rack-mounted analog and pulse/frequency I/O are transferred by the PLC processor to the module; the MVI71-AFC calculates flow rate and accumulated quantities, then returns results to processor memory for ladder logic or SCADA use.
| Module type | Liquid & Gas Flow Computer for PLC platform |
| Form factor | Single-slot, 1771 chassis compatible; BTR/BTW data transfer |
| Meter channels | 8; configurable for linear (pulse) or differential (orifice) measurement |
| Measurement standards | AGA 3, AGA 7, AGA 8 and applicable API MPMS Chapters 11 and 12 |
| Calculated values | Flow rates; accumulated volume, mass and energy |
| Backplane current | 800 mA at 5 VDC |
| Operating / storage | 0 to 60°C / −40 to 85°C |
| Relative humidity | 5 to 95%, non-condensing |
| Modbus serial settings | 300 to 19,200 baud; RTU or ASCII; 7/8 data bits; configurable parity and stop bits |
The MVI71-AFC is a single-slot liquid and gas flow computer for the PLC-5 / 1771 platform, providing eight configurable meter channels.
It accepts process values transferred from rack analog modules and pulse/frequency input modules. Channels may be configured for linear pulse or differential measurement.
The processor and module exchange configuration, input and calculated result data through BTR/BTW backplane transfers controlled by ladder logic.
Yes. Its Modbus communications can make calculated and configured data available to a SCADA host or other compatible device.
No. ProSoft’s manual specifies hydrocarbon-fluid measurement and states that water-measurement applications are not supported.
