BENTLY NEVADA / 3300 XL PROXIMITY TECHNOLOGY
102044-00-32-10-02
8 mm Proximity Probe Configuration
Designed for non-contact measurement of shaft position and dynamic mechanical movement in rotating machinery. The 102044 family is associated with Bently Nevada proximity sensing architecture, where the probe works as the machine-side sensing element in a complete eddy-current proximity measurement chain.
|
CONFIGURATION SNAPSHOT
|
| PART NUMBER 102044-00-32-10-02 |
DELIVERY 3–5 Days |
WARRANTY 12 Months |
PACKING Brand New |
PAYMENT T/T |
|
01 / PRODUCT POSITION
A sensing element built for rotating machinery
The 102044-00-32-10-02 belongs to the Bently Nevada 102044 proximity probe family and follows the 8 mm proximity sensing architecture used for machinery condition monitoring. Its purpose is to provide a non-contact measurement point between the probe tip and a conductive machine target. In a complete transducer chain, the probe is paired with compatible signal-conditioning electronics and associated cabling. The resulting measurement can be used for shaft vibration, shaft position, radial movement, axial movement and other machinery protection functions depending on the installed monitoring scheme. WHY THE CONFIGURATION MATTERS
The complete ordering string controls physical and connection characteristics. Replacement should therefore be matched by the complete part number rather than by the 8 mm probe diameter alone.
|
02 / CONFIGURATION
|
|
03 / TECHNICAL CORE
Configuration details
The 102044-00-32-10-02 configuration is centered on the 8 mm probe format. Its mechanical dimensions and cable arrangement are significant when replacing an installed probe because mounting geometry and cable routing affect practical installation. |
|
|
01
Non-contact measurement
The probe measures relative movement without mechanical contact between the probe tip and the conductive target. |
02
Compact 8 mm format
The 8 mm sensing format is widely used for rotating equipment vibration and position measurements where installation space and probe geometry must be controlled. |
03
Matched configuration
The complete ordering string defines physical and connection characteristics, helping maintenance teams avoid mismatched probe replacements. |
04
Machinery protection role
When correctly paired with compatible electronics, the sensing chain supports monitoring and protection functions for critical rotating machinery. |
|
04 / FIELD APPLICATION
Where the sensing chain matters
The probe format is intended for machinery monitoring arrangements where shaft motion must be measured without physically touching the rotating surface. |
|
|
05 / MAINTENANCE LOGIC
What replacement problems should be avoided?
|
|
|
06 / SAME FAMILY
3300 XL 8 mm proximity family
Within the 3300 XL 8 mm architecture, different part numbers change mechanical dimensions, cable length, connector style, armor or other configuration elements. These differences are important when selecting a direct replacement. |
|
|
07 / QUOTATION CHECK
Send the complete operating context
For a fast quotation and correct replacement selection, please include the following details in your inquiry:
|
LOGISTICS
Lead time: 3–5 days
Warranty: 12 months
Packing: Brand new
Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS
Payment term: T/T
Fast quotation principle
Complete part number + quantity + destination + required date + machine/system. |
|
08 / BRAND COVERAGE
One sourcing desk for multiple control platforms
|
|
|
09 / PURCHASING FAQ
102044-00-32-10-02
Five practical questions for replacement planning, configuration matching and purchasing. |
Q1. Why should I match the complete 102044-00-32-10-02 number instead of only asking for an 8 mm probe?
Because the 8 mm sensing diameter does not define the complete mechanical and connection configuration. The ordering string determines characteristics such as case configuration, cable length and connector arrangement. A complete part-number match reduces the risk of receiving a physically similar but unsuitable replacement.
Q2. Can 102044-00-32-10-02 be selected when the installed system already uses a Bently Nevada 8 mm probe?
Only when the complete installed configuration is compatible. The 8 mm format identifies the sensing family, but mounting thread, case length, cable arrangement, connector and the associated signal-conditioning chain still need to match the installed system.
Q3. What should I check before replacing 102044-00-32-10-02 during a maintenance shutdown?
Confirm the complete part number, probe mounting arrangement, available installation space, cable route, connector style and the compatible Proximitor / signal-conditioning equipment. The installed machine and monitoring channel should also be identified before ordering.
Q4. What type of machinery measurement can 102044-00-32-10-02 support?
In a correctly configured proximity measurement chain, the probe can support non-contact shaft vibration and position measurements. The exact monitored variable depends on probe placement, target geometry, signal conditioning and the monitoring channel used by the machine.
Q5. How can I reduce the risk of ordering the wrong 102044-00-32-10-02 replacement?
Send the exact installed part number together with quantity, destination, required date and machine/system details. If the installed probe label is available, keeping the complete suffix intact is especially useful because different configurations can share the same basic 8 mm sensing architecture.
|
|
