YOKOGAWA AAV141-S53/K4A00 16-Channel Analog Input Module

YOKOGAWA AAV141-S53/K4A00
YOKOGAWA AAV141-S53/K4A00
YOKOGAWA AAV141-S53/K4A00

YOKOGAWA AAV141-S53/K4A00 16-Channel Analog Input Module

Calculate shipping
Quotation Request
YOKOGAWA / FIO
AAV141
S53 / K4A00

ANALOG INPUT
VOLTAGE SIGNAL
16-CHANNEL MODULE
◇ FIELD SIGNAL INTERFACE
MODEL SERIES / 01
SPECIFICATION / INPUT
16-channel voltage acquisition
For compatible Yokogawa FIO control-system applications.
01 / CHANNELS
16
Non-isolated inputs
02 / INPUT RANGE
1–5 V DC
Differential input

03 / INPUT ACCURACY
±4 mV
Verify operating conditions in the applicable specification.
◇ KS cable interface option: K4A00
AMIKON / GLOBAL SUPPORT
International Delivery on the Day
Quick Response Support
Intercontinental Cooperation Network
Sales manager: Miya zheng
✉ EMAIL SALES ☎ PHONE / WHATSAPP




AI-16
CENTUM FIO / HIGH-DENSITY VOLTAGE ACQUISITION




AAV141-S53/K4A00

16-Channel Analog Input Module

Sixteen process voltages move through one clear acquisition path and a dedicated KS cable interface.


SIGNAL 0116 INPUT CHANNELS SIGNAL 021-5 V DC INTERFACEATK4A-00 ADAPTER

ENGINEERING PROFILE

SIXTEEN SIGNALS, ONE PROCESS VIEW

PRODUCT ROLE

AAV141-S53/K4A00 provides dense voltage acquisition for CENTUM FIO. Its sixteen non-isolated channels receive 1 to 5 V DC process signals through the supplied KS cable interface adapter.

ORDERING DISCIPLINE
Keep the complete suffix and option code together. Signal type, isolation, adapter and environmental build must match the installed system.
01
 Sixteen 1 to 5 V DC analog input channels
02
 Non-isolated channel architecture
03
 ATK4A-00 KS cable interface adapter
04
 Standard type with no explosion-protection suffix
05
 ISA Standard G3 and -20 to 70 deg C option
01
FIELD SENSOR		 02
SIGNAL CONDITIONER		 03
KS CABLE PATH		 04
FIO ACQUISITION
REQUEST A SIGNAL MATCH CHECK MAIL MIYA WHATSAPP +86 180 2077 6792 Sales Manager
Miya Zheng
EXACT CONFIGURATION

A 16-Channel Signal Path, Fully Decoded

Module function Analog input acquisition
Input channels 16 channels
Input signal 1 to 5 V DC
Isolation Non-isolated
Suffix -S Standard type
Suffix 5 No explosion protection
Suffix 3 ISA Standard G3 and -20 to 70 deg C option
Option /K4A00 ATK4A-00 KS cable interface adapter
System role CENTUM VP / CS 3000 FIO signal acquisition
Migration context Compatible D-series nest paths depend on termination
PURCHASING CHECK

Match the complete model, suffix, adapter, signal type, termination, project revision and environmental requirement. The base model alone is not enough for approval.
SYSTEM RELATIONSHIP

AAV141 System Fit - Voltage Input Without Guesswork

MODEL CHANNELS SIGNAL ROLE KEY DIFFERENCE
AAV141-S53/K4A00 16 AI 1-5 V, non-isolated KS cable adapter
AAB141 variants 16 AI 1-5 V / 4-20 mA Model-specific HART option
AAI141 variants 16 AI 4-20 mA, non-isolated Current input focus

Replacement approval must follow the signal range, isolation architecture, adapter and complete suffix. Visual similarity does not establish interchangeability.

AMIKON / GLOBAL AUTOMATION SUPPLY
Sixteen field voltages move through one clear acquisition path.
PEOPLE / RESPONSE

Responsive communication for current and discontinued automation requirements.
CHECK / MATCH / TRACK

Careful model matching and accountable order handling.
STOCK / UPTIME

Efficient delivery helps restore and sustain production.

CHECK STOCK AND DELIVERY MAIL MIYA WHATSAPP +86 180 2077 6792 Sales Manager
Miya Zheng
QUALITY
Careful matching for dependable operation.		 RELIABILITY
Fast handling to reduce avoidable downtime.		 TRUST
Clear communication throughout the order.		 RETURNS
Contact us within seven days after receipt. Goods must remain in original condition with a clear reason. Eligible returns or replacements follow inspection; return freight is paid by the buyer.
BUYER FAQ

Five Checks Before Choosing AAV141-S53/K4A00

What signals can AAV141-S53/K4A00 receive?
It is intended for sixteen 1 to 5 V DC analog input channels. It is not the correct choice for a direct 4 to 20 mA input unless the signal is converted appropriately.
What does /K4A00 add to AAV141-S53/K4A00?
It adds the ATK4A-00 KS cable interface adapter for connection through the applicable KS cable and termination arrangement.
Are AAV141-S53/K4A00 inputs isolated from one another?
No. The module is non-isolated, so common potential, grounding and field-conditioner behavior require attention.
Can AAV141-S53/K4A00 directly replace AAB141?
Not automatically. AAB141 supports a different input-signal combination. Confirm every loop signal and the configured range before substitution.
Which details should be verified before ordering AAV141-S53/K4A00?
Verify the full suffix, 1 to 5 V signal requirement, KS adapter, cable, terminal arrangement, environmental option and the installed FIO project.
