YOKOGAWA AAB841-S53/M4A00 Mixed Analog Input / Output Module

YOKOGAWA AAB841-S53/M4A00
YOKOGAWA AAB841-S53/M4A00
YOKOGAWA AAB841-S53/M4A00

YOKOGAWA AAB841-S53/M4A00 Mixed Analog Input / Output Module

Calculate shipping
Quotation Request
AAB841
S53 / M4A00

ANALOG INPUT
+ ANALOG OUTPUT
◇ MIXED SIGNAL MODULE
MODEL / 02
Two signal directions. One module.
Non-isolated analog I/O for compatible Yokogawa systems.
01 / INPUT PATH →
8 channels
1–5 V DC   Voltage input
02 / OUTPUT PATH →
8 channels
4–20 mA DC  Current output
03 / ISOLATION
Non-isolated I/O
Adapter option: M4A00
AMIKON
INDUSTRIAL PARTS SUPPORT
International Delivery on the Day
Quick Response Support
Intercontinental Cooperation Network
Sales manager: Miya zheng
◇ INPUT / OUTPUT INTERFACE



8I-8O
CENTUM FIO / MAC2-COMPATIBLE SIGNAL BRIDGE




AAB841-S53/M4A00

Mixed Analog Input / Output Module

A balanced analog bridge where eight voltage measurements meet eight current-control outputs.


SIGNAL 018 x 1-5 V INPUT SIGNAL 028 x 4-20 mA OUTPUT INTERFACEATM4A-00 ADAPTER

ENGINEERING PROFILE

MEASUREMENT MEETS CONTROL

PRODUCT ROLE

AAB841-S53/M4A00 combines two signal directions in one CENTUM FIO position. Differential 1 to 5 V inputs acquire process values while 4 to 20 mA outputs command compatible field circuits.

ORDERING DISCIPLINE
Keep the complete suffix and option code together. Signal type, isolation, adapter and environmental build must match the installed system.
01
 Eight differential 1 to 5 V DC analog inputs
02
 Eight 4 to 20 mA DC analog outputs
03
 Non-isolated circuit architecture
04
 ATM4A-00 adapter for MAC2-compatible connection
05
 S53 suffix adds G3 and -20 to 70 deg C capability
01
FIELD MEASUREMENT		 02
1-5 V ACQUISITION		 03
CONTROL DECISION		 04
4-20 mA OUTPUT
REQUEST A SIGNAL MATCH CHECK MAIL MIYA WHATSAPP +86 180 2077 6792 Sales Manager
Miya Zheng
EXACT CONFIGURATION

The 8-In / 8-Out Architecture at a Glance

Module function Mixed analog input and output
Input channels 8 channels
Input signal 1 to 5 V DC, differential
Output channels 8 channels
Output signal 4 to 20 mA DC
Isolation Non-isolated
Suffix -S Standard type
Suffix 5 No explosion protection
Suffix 3 ISA Standard G3 and -20 to 70 deg C option
Option /M4A00 ATM4A-00 MAC2-compatible adapter
PURCHASING CHECK

Match the complete model, suffix, adapter, signal type, termination, project revision and environmental requirement. The base model alone is not enough for approval.
SYSTEM RELATIONSHIP

AAB841 System Fit - Adapter, Signals and Alternatives

MODEL CHANNELS SIGNAL ROLE KEY DIFFERENCE
AAB841-S53/M4A00 8 AI + 8 AO 1-5 V in / 4-20 mA out MAC2-compatible adapter
AAB841-S53/K4A00 8 AI + 8 AO Same base signal split KS cable adapter
AAB842 variants 8 AI + 8 AO Input supports model-specific current option HART on -H versions

Replacement approval must follow the signal range, isolation architecture, adapter and complete suffix. Visual similarity does not establish interchangeability.

AMIKON / GLOBAL AUTOMATION SUPPLY
Measurement and control meet inside one engineered signal bridge.
PEOPLE / RESPONSE

Responsive communication for current and discontinued automation requirements.
CHECK / MATCH / TRACK

Careful model matching and accountable order handling.
STOCK / UPTIME

Efficient delivery helps restore and sustain production.

CHECK STOCK AND DELIVERY MAIL MIYA WHATSAPP +86 180 2077 6792 Sales Manager
Miya Zheng
QUALITY
Careful matching for dependable operation.		 RELIABILITY
Fast handling to reduce avoidable downtime.		 TRUST
Clear communication throughout the order.		 RETURNS
Contact us within seven days after receipt. Goods must remain in original condition with a clear reason. Eligible returns or replacements follow inspection; return freight is paid by the buyer.
BUYER FAQ

Five Buying Checks for AAB841-S53/M4A00

What signal split does AAB841-S53/M4A00 provide?
It provides eight differential 1 to 5 V DC inputs and eight 4 to 20 mA DC outputs in one non-isolated module.
Why does the /M4A00 suffix matter on AAB841-S53/M4A00?
It specifies the ATM4A-00 MAC2-compatible adapter. A module with another adapter option may not match the installed nest and connector arrangement.
Is AAB841-S53/M4A00 channel-isolated?
No. The analog circuits are non-isolated, so grounding, common-mode conditions and shield practice must be reviewed carefully.
Can AAB841-S53/M4A00 replace an AAB842 without checks?
No. Compare input signal capability, HART requirements, adapter type, project configuration and termination before approving a substitution.
What should be supplied for an AAB841-S53/M4A00 quotation?
Provide the complete order code, quantity, installed nest type, required condition, channel use and clear label photos so the adapter and suffix can be matched.
RELATED INDUSTRIAL MODELS

Broader automation availability

6ES7193-6BP00-0BD0 MVI69L-MBS AAI135-S50/K4A00 IC695ALG626-CA
1734-EP24DC 2093-AC05-MP5 PM860K01 3BSE018100R1 2198-P070
5501-367 AFV30D-A41262 DS200DTBDG1A MVME172-433A
177230-01-01-05 EC7850A1072 FBM240 5441-693
PLX31-EIP-MBS ADV559-P01 FC-TSRO-0824 ADV551-P60
DS200DTBBG1A X20PD0016 PM856K01 3BSE018104R1 6ES7507-0RA00-0AB0
6ES7516-3FN02-0AB0 6EP1334-3BA10-8AB0 1769-CRL1 6GK7243-1BX30-0XE0
6ES7517-3AP00-0AB0 SDCS-CON-H01 3ADT320000R1501 S2SC70D-FA12010 AAI835-S50/K4A00
1756-L65 1756-L64 IS420UCSBH1A 6GK1500-3AA10
FC-TSDO-0824 1756-L71 VM600 RPS6U SIM-275D-24 1769-L35E
KJ3241X1-BA1 PLX51-PBS FC-TSDI-16UNI MVME172-263
6ES7505-0RB00-0AB0 ANT502-5E HQ40D PR6423/011-040
1394C-AM03 PR6424/011-110 IS200ESELH1A A2FV70D-A411000/HKU
IS200ESELH2A CC-PFB802 51454953-176 PM866K02 3BSE050199R1 1756-L63
KJ3222X1-EA1 1746-IB16 F8650E 2097-V32PR0
SEND YOUR RFQ TODAY MAIL MIYA WHATSAPP +86 180 2077 6792 Sales Manager
Miya Zheng
Hot Tags : YOKOGAWA AAB841-S53/M4A00 AAB841-S53 AAB841-S53/M4A00 AAB841-S53/M4A00 datasheet AAB841-S53/M4A00 manual AAB841-S53/M4A00 pdf
