TRICONEX 9770X 24 VDC Commoned DI FET Connector

Calculate shipping

Quotation Request

TRICONEX FIELD TERMINATION PANEL

Digital Output Termination

MODEL: 9770X

❖ TRICON INTERFACE

Non-Supervised Output

Provides field terminal points and signal conditioning for non-supervised digital output modules.

⚡ High-Current Relay Capable
⚡ Rugged Industrial Design

[01] ALIGNMENT

Digital Output ETP

Engineered for Tricon Digital Output Modules.

[02] OUTPUT TYPE

Non-Supervised

Robust field switching point contacts.

[03] ISOLATION

Surge Protection

Integrated isolation protects backplane circuits.

Sales Manager: Miya zheng

✉ Email: sales@amikon.cn

☎ WhatsApp: 86-18020776792

✦ We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world. ✦

Product Categories

Brands
- ABB
- BENTLY NEVADA
- HONEYWELL
- EMERSON
- ALLEN BRADLEY
- YOKOGAWA
- GENERAL ELECTRIC
- TRICONEX
- ICS TRIPLEX
- HIMA
- BACHMANN
- SIEMENS
- PROSOFT
- SCHNEIDER
- FOXBORO
- OTHERS

New Products

Product Details

TRICON CX

FIELD TERMINATION

DIGITAL INPUT

32 POINT ARCHITECTURE

TRICONEX

9770X

24 VDC · COMMONED · 32 POINTS

Digital Input Field External Termination Connector

Designed for the Tricon CX field-termination architecture and the 3506X supervised digital-input module.

PRODUCT CODE

9770X

FET CONNECTOR

DI / 32 POINT

TYPE

FET Connector

SIGNAL FAMILY

Digital Input

FIELD VOLTAGE

24 VDC

POINT COUNT

32 Points

EMAIL SALES WHATSAPP / PHONE

01 / ENGINEERING PROFILE

Built around
the termination path

The 9770X is a field external termination connector for digital-input applications in the Tricon CX platform. Its defined role is to connect digital-input external termination arrangements to compatible DI modules in the 8131X I/O Expansion Chassis.

FUNCTION Digital-input field termination Used as the field-side termination interface for compatible Tricon CX DI arrangements.	ARCHITECTURE Commoned 24 VDC The specified panel type is commoned and rated for 24 VDC field termination.
CAPACITY 32 points The connector is specified as a 32-point field termination interface.	SYSTEM LOCATION 8131X I/O Expansion Chassis The 9770X is intended for the field-termination path associated with the expansion-chassis architecture.

PANEL TYPE

Commoned

FIELD VOLTAGE

24 VDC

POINTS

SIGNAL

MODULE

3506X

02 / FIELD APPLICATION

A defined interface
for digital inputs

In a Tricon CX arrangement, the 9770X sits on the field-termination side of the digital-input path. This makes correct matching important when replacing a termination connector or rebuilding an expansion-chassis connection.

Field wiring

Digital input field termination path

9770X

32-point commoned FET connector

3506X

Supervised TMR digital-input module

REPLACEMENT LOGIC

Match the termination architecture first.

A replacement decision should verify the DI function, 24 VDC commoned arrangement, 32-point capacity, compatible module family and the physical field-termination arrangement. The 9770X is specifically associated with the 3506X digital-input module in the Tricon CX expansion architecture.

For a maintenance replacement, avoid substituting an FET from another signal family simply because its connector format appears similar. The 9666X, 9769X, 9770X and 9963X/9965X families serve different I/O functions.

03 / RELATED TRICON CX TERMINATION FAMILY

Same platform,
different signal roles

The Tricon CX termination family contains dedicated FET connectors for different I/O functions. Choosing within the same family still requires matching the signal type and compatible module.

9770X DI · 24 VDC · Commoned · 32 points	9666X DO · 24 VDC · Commoned · 32 points
9769X AI · 24 VDC · Commoned · 32 points	9963X / 9963AX UIO · 24 VDC · Commoned · 16 points
9965X / 9965AX AO · 24 VDC · Commoned · 16 points

AMIKON INDUSTRIAL PARTS

Need 9770X for
your maintenance plan?

Send the exact part number together with your required quantity and destination. Our sales team can check availability, delivery arrangements and replacement requirements.

EMAIL sales@amikon.cn	PHONE / WHATSAPP 86-18020776792
SALES MANAGER Miya zheng

DELIVERY

3–5 Days

WARRANTY

12 Months

PACKAGING

Brand New

PAYMENT

T/T

DELIVERY WAY

E-packing / FedEx / EMS / TNT / DHL / UPS

RFQ CHECKPOINT

Send these five details

Part Number

Quantity

Destination

Required Date

Machine / System

04 / BUYER FAQ

Five questions before replacement

01	Can TRICONEX 9770X replace a damaged field-termination connector on an existing 3506X installation? Yes, when the existing configuration is the compatible 3506X digital-input arrangement and the required termination architecture matches the 9770X specification. The 9770X is the 32-point, commoned, 24 VDC FET connector associated with the 3506X DI module.
02	Why does TRICONEX 9770X matter when the 3506X module itself is still operational? The FET connector is part of the field-termination path. A functioning I/O module does not remove the need for a correctly matched field interface. If the termination connector is damaged, unavailable or being replaced during maintenance, matching the correct FET prevents a signal-family mismatch.
03	Is TRICONEX 9770X interchangeable with 9666X or 9769X because they share a 32-point format? No. Point count alone is not sufficient for selection. The 9770X is assigned to digital-input termination, while 9666X is associated with digital-output termination and 9769X with analog-input termination. Their signal roles are different even where the point count and 24 VDC commoned architecture appear similar.
04	What should a buyer verify before ordering TRICONEX 9770X as a maintenance spare? Confirm the installed module is the 3506X, verify that the field side uses the 24 VDC commoned 32-point DI arrangement, and confirm whether the installation is in the Tricon CX expansion-chassis termination architecture. Providing the complete machine or system context is useful when the existing part number is uncertain.
05	When should TRICONEX 9770X be considered instead of changing the entire digital-input assembly? If the 3506X module remains suitable and the issue is confined to the field-termination connector, replacing the compatible FET can address the termination-side component without automatically replacing the I/O module. The final replacement decision should be based on the actual fault location and installed configuration.
