Product Details

TRICONEX / 9666X

Overview Technical Series Application Contact FAQ Related

TRICON CX DIGITAL OUTPUT TERMINATION

9666X

Field External Termination Connector

24 VDC / Commoned / 32-Point DO FET

PRODUCT CLASS

DO FET

SYSTEM

TRICON CX

Sales manager: Miya zheng

sales@amikon.cn | 86-18020776792

PRODUCT NOTE 01

Termination
Interface

TRICONEX 9666X is a Field External Termination (FET) connector designed for the Tricon CX digital-output termination architecture. The specified configuration is commoned, 24 VDC and 32-point.

The 9666X is associated with the digital-output termination arrangement used with the Model 8131X I/O Expansion Chassis and is compatible with the 3626X digital-output module. For replacement work, the complete termination arrangement should be matched rather than selecting a connector only by physical appearance.

24 VDC

Defined for the 24 VDC commoned termination arrangement.

32 POINT

A 32-point FET connector configuration for the DO termination path.

COMMONED

The termination arrangement is specified as commoned.

DO FET

Dedicated field termination interface for the digital-output architecture.

ENGINEERING DATA

Technical Profile

Model	TRICONEX 9666X
Function	DO Field External Termination
Voltage	24 VDC
Point Capacity	32 points

Termination	Commoned
Compatible DO Module	3626X
Chassis Association	8131X I/O Expansion Chassis
System Family	Tricon CX

TRICON CX TERMINATION FAMILY

Series Relationship

Different FET connectors serve different I/O functions and electrical arrangements within the Tricon CX architecture.

9512X

24 VDC
8-point FET

9666X

DO
24 VDC
32-point

9769X

AI
24 VDC
32-point

9770X

DI
24 VDC
32-point

9963X / 9963AX

Universal I/O
16-point

9965X / 9965AX

AO
16-point

For replacement selection, the I/O function, field voltage, commoning arrangement and point configuration should correspond to the installed architecture. Same-family status alone does not establish interchangeability.

FIELD APPLICATION

Designed Around
the Existing DO Path

The 9666X is relevant where a Tricon CX installation uses the defined 24 VDC commoned DO FET termination arrangement.

It is particularly relevant to component replacement where the existing termination architecture is intended to remain unchanged.

01	Existing FET replacement A failed or damaged FET connector can require component-level replacement while preserving the established DO termination architecture.
02	Point configuration verification The 32-point arrangement should be confirmed before selecting a replacement connector.
03	DO module compatibility The relationship with the 3626X DO module is an important part of replacement verification.
04	Cabinet maintenance Matching the established termination arrangement can help avoid introducing an unrelated I/O configuration during maintenance.
