TRICON CX / SAFETY SYSTEM HARDWARE
8108X
Blank Slot Panel for a Single I/O Module Position
The TRICONEX 8108X is a passive blank slot panel designed for the Tricon CX architecture. It closes an unused single I/O module position and helps maintain the intended physical enclosure arrangement of the chassis. Its purpose is mechanical and environmental rather than signal processing: it does not provide an I/O function, power conversion function, or control logic.
Core purchasing point: 8108X should be selected by chassis position and module-position requirement, not simply because another Tricon CX position is unused.
|
PART NUMBER
8108X
|
|
01
|
A Closure Component, Not an Electronic I/O Module
In a Tricon CX installation, unused chassis positions are not intended to remain open. The 8108X is specifically designed to close a position associated with a single I/O module. It supports a completed physical chassis arrangement while helping limit exposure of the internal chassis area to dust and other particulate matter and helping address electromagnetic and radio-frequency interference considerations.
Because the 8108X has no signal-processing role, the most important purchasing question is whether the vacant position is the specific single-I/O-module position for which this panel is intended.
|
|
Key Characteristics
Single I/O Module Position
The 8108X is assigned to the Tricon CX position intended for one I/O module.
Passive Hardware
It is a blank panel rather than an electronic I/O assembly and does not perform control or signal-processing functions.
Chassis Closure
The panel is used to cover an unused position so the chassis remains physically closed.
Environmental Consideration
Closing unused positions helps minimize exposure to dust and particulate matter and supports the intended EMI/RFI protection approach.
|
ENGINEERING SNAPSHOT
TRICONEX 8108X
|
| Model | 8108X | System Family | Tricon CX |
| Product Type | Blank Slot Panel | Position Type | Single I/O Module |
| Electrical Function | Passive panel | Signal Processing | None |
| Primary Use | Cover unused module position | System Environment | Tricon CX chassis |
| Typical Chassis | 8131X I/O Expansion Chassis | Related Panel | 8107X / 8109X |
| Mechanical Purpose | Close vacant chassis position | Environmental Role | Limits exposure to dust/particulates |
| EMI/RFI Role | Supports closed chassis arrangement | Installation Decision | Match physical chassis position |
| Replacement Reference | 3001128-100 | Recommended Approach | Verify position before purchase |
|
TRICON CX BLANK PANEL FAMILY
Same-Series Selection
The Tricon CX blank-panel family is position-specific. The three models should not be selected solely because they all close unused areas of the chassis. The correct model depends on whether the vacant position belongs to a communication module, a single I/O module, or an I/O slot.
Selection rule: Match the blank panel to the actual chassis position before ordering.
|
Why the distinction matters
A blank-panel replacement should preserve the intended chassis position. Using 8107X, 8108X or 8109X interchangeably can result in a position mismatch even though all three products serve a blank-panel role.
|
|
An Unused I/O Position in a Tricon CX Chassis
When a single I/O module position is intentionally left vacant, the corresponding opening should not simply be left exposed. The 8108X provides the designated blank-panel function for this type of position.
|
During Chassis Maintenance
A maintenance team may remove an I/O module during planned work or equipment replacement. If the position remains unused, the correct blank-panel arrangement helps keep the chassis physically closed until the module is restored.
|
|
|
Dust and Particulate Exposure
Tricon CX installation guidance calls for unused chassis positions to be covered. The 8108X therefore has value beyond appearance: it helps reduce direct exposure of the chassis interior to dust and other particulate matter.
|
EMI / RFI Considerations
Keeping unused positions covered also supports the intended closed-chassis arrangement for electromagnetic and radio-frequency interference considerations. The 8108X is therefore relevant when maintaining the physical configuration of a critical-control cabinet.
|
|
|
Planned Spare Strategy
Although it is a passive component, a missing blank panel can become a practical maintenance issue when a cabinet must be restored to its intended configuration. Keeping the correct position-specific panel available can simplify planned intervention.
|
Tricon CX Expansion Architecture
The 8108X is particularly relevant to Tricon CX I/O expansion arrangements. When the vacant position belongs to a single I/O module position in an 8131X I/O Expansion Chassis, confirm the exact chassis position before ordering.
|
|
PURCHASING CHECK
Verify the Position
|
Before ordering 8108X, verify that the vacant position is the single-I/O-module position within the Tricon CX chassis. If the vacant position is associated with a communication module or a different I/O-slot designation, another blank-panel model may be required.
|
|
DIRECT SALES CONTACT
Need 8108X?
Send the exact part number and system position details so the correct Tricon CX blank-panel arrangement can be checked before shipment.
|
|
||||
| Delivery: 3–5 days | Warranty: 12 months | Packaging: Brand New | Payment Term: T/T |
| Delivery Way: E-packing / FedEx / EMS / TNT / DHL / UPS | |||
| Part Number | Quantity | Destination | Required Date | Machine/System |
|
01
|
Is TRICONEX 8108X the correct replacement when an unused Tricon CX position is intended for one I/O module?
Yes, when the vacant position is specifically the single-I/O-module position for which 8108X is designated. The key check is the physical chassis position rather than simply whether the cabinet has an empty opening. If the position belongs to a communication module or another I/O-slot designation, the corresponding blank-panel model should be selected instead.
|
|
02
|
Can TRICONEX 8108X replace a missing blank panel in an 8131X I/O Expansion Chassis?
8108X is associated with the single-I/O-module blank-panel position and is listed for use with the 8131X I/O Expansion Chassis. Before replacement, the actual vacant position should still be checked because 8131X chassis positions can require different blank-panel models depending on their intended function.
|
|
03
|
Why would a maintenance team keep TRICONEX 8108X as a spare if it has no electronic control function?
8108X is a physical chassis-closure component. Tricon CX installation guidance calls for unused positions to be covered to minimize exposure to dust and particulate matter and to support the intended EMI/RFI arrangement. A spare can therefore be useful when an I/O module is removed during maintenance and the vacant position must remain properly closed.
|
|
04
|
How should I distinguish TRICONEX 8108X from 8107X and 8109X when preparing a replacement order?
The distinction is based on the chassis position. 8107X is the blank panel for a communication-module position, 8108X is for a single I/O module position, and 8109X is for an I/O slot. These three models should therefore be matched to the actual position rather than treated as interchangeable blank covers.
|
|
05
|
What should I verify before purchasing TRICONEX 8108X for a critical-control cabinet?
Verify the complete part number, Tricon CX system type, chassis model, exact vacant position and whether the position is designated for a single I/O module. For an 8131X installation, confirm that the vacant position corresponds to the 8108X function. This check is more important than matching the panel only by appearance or overall cabinet location.
|
|
