HIMATRIX F60 SAFETY-RELATED I/O
F3 DIO 24/16 01
24 Digital Inputs | 16 Digital Outputs | Line Monitoring
|
|
MODULE PROFILE
DIO 24/16 01
HIMatrix F60 modular I/O module
|
The F3 DIO 24/16 01 is a safety-related digital I/O module designed for the modular HIMatrix F60 system. It provides 24 digital input channels and 16 digital output channels, with the I/O circuits galvanically separated from the I/O bus. Front-panel LEDs provide channel status indication for inputs and outputs.
|
|
01 / CORE FUNCTION
Designed for F60 I/O Architecture
The module is installed in the base plate of the HIMatrix F60 and occupies an I/O position in slots 3 through 8. Slot 1 is assigned to the power supply module and slot 2 to the processor module. The module supports safety-related digital inputs and outputs. Input and output signal status is displayed by front LEDs, allowing channel states and diagnostic conditions to be monitored during operation. SAFETY ARCHITECTURE
The DIO 24/16 01 is certified for safety-related applications up to SIL 3 according to IEC 61508, IEC 61511 and IEC 62061, and Cat. 4 / PL e according to EN ISO 13849-1. The HIMatrix F60 documentation also identifies the module for CENELEC SIL 4 applications under the applicable railway standards. |
I/O STRUCTURE
|
| EMAIL · sales@amikon.cn | WHATSAPP · 86-18020776792 |
|
Sales Manager: Miya zheng
|
|
| General | HIMatrix F60 digital I/O module; safety-related inputs and outputs |
| Operating Voltage | 24 VDC, -15 % / +20 %, with ripple allowance as specified for the supply system |
| Power Consumption | 24 VDC / 380 mA; 3.3 VDC / 150 mA |
| Ambient Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Space Requirement | 6 RU, 4 HP |
| Weight | Approx. 260 g |
| Digital Inputs | 24 galvanically separated inputs; nominal 24 VDC; high level 10–30 V; low level max. 5 V |
| Input Current | Approx. 2 mA at 10 V; approx. 5 mA at 24 V; approx. 1 mA at 5 V |
| Input Switching Point | Typical 7.5 V |
| Input Supply | 3 × 20 V / 100 mA at 24 V; short-circuit protected |
| Digital Outputs | 16 galvanically separated outputs; output voltage 18.4–26.8 VDC |
| Output Current | Up to 2 A per channel; maximum 8 A for the module |
| Output Protection | Permanently short-circuit protected; minimum load 2 mA per channel; leakage current max. 1 mA at 2 V |
|
FUNCTIONAL HIGHLIGHTS
Built Around Safety I/O Diagnostics
|
LINE MONITORING
Cross-Circuit & Open-Circuit Detection
Digital outputs DO 1 through DO 8 can be operated as pulsed outputs for line control. When connected with safety-related digital inputs, this arrangement can support detection of short circuits and open circuits, including applications such as emergency-stop circuits. Pulsed outputs used for line monitoring are not to be treated as safety-related outputs. |
|
APPLICATION LOGIC
Where F3 DIO 24/16 01 Fits
|
The module is suited to safety-related digital signal exchange within a HIMatrix F60 architecture where a comparatively high number of digital field signals must be monitored and controlled from a modular safety controller. Typical HIMatrix applications include process-industry safety systems, fire and gas systems, burner-related solutions, turbine monitoring, wellhead control, logistics systems, machine safety, conveyors, cranes, presses, robot cells and other industrial safety functions. |
If a digital input fault is detected, the user program receives a low level and the module activates the ERR LED. The corresponding error code can be evaluated by the user program for an additional fault reaction.
If an output channel is overloaded, it is switched off for approximately 10 seconds until the overload condition is no longer present. If the total module output load exceeds 8 A, all outputs are switched off for approximately 10 seconds and a new test is performed. A detected output fault places the affected output in the safe de-energized state; a module fault switches off all digital outputs.
| Module | Digital Inputs | Digital Outputs | Key Role |
| DIO 24/16 01 | 24 | 16 | Digital I/O with line monitoring |
| DI 32 01 | 32 | — | High-density digital input; line-control configuration |
| DI 24 01 | 24 | — | 24-channel digital input, 110 V application |
| CIO 2/4 01 | — | 4 | Counter functions up to 1 MHz |
|
DIRECT CONTACT
Need F3 DIO 24/16 01?
Send the part number and application details for a quotation and availability check.
|
|
||||
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
PAYMENT
T/T
|
SHIPPING
E-packing / FedEx / EMS / TNT / DHL / UPS
|
|
Q1. Is F3 DIO 24/16 01 suitable when an existing F60 system requires both additional inputs and outputs?
Yes. The module combines 24 digital inputs and 16 digital outputs in one F60 I/O module. This makes it relevant where the replacement or expansion requirement involves both signal directions rather than input-only or output-only capacity. Final suitability should be checked against the existing F60 slot arrangement, electrical conditions and configured safety function.
|
|
Q2. Can F3 DIO 24/16 01 replace another HIMatrix I/O module with a similar channel count?
Not automatically. A channel-count match does not establish functional equivalence. F3 DIO 24/16 01 combines digital inputs, digital outputs and line-monitoring capability, while other F60 modules may provide input-only, output-only, analog or counter functions. Replacement should therefore be checked against the original module's signal type, wiring, load, safety function and system configuration.
|
|
Q3. What should be checked before purchasing F3 DIO 24/16 01 for a safety-related replacement?
The key checks are the HIMatrix F60 architecture, installed slot position, 24 VDC supply conditions, input and output electrical requirements, total output loading, field wiring, configured safety function and required diagnostic behavior. The module's maximum output load is 2 A per channel and 8 A for the module, so the connected load must be evaluated before replacement.
|
|
Q4. Does F3 DIO 24/16 01 provide line monitoring for emergency-stop related circuits?
It can support line-control arrangements using digital outputs DO 1 through DO 8 as pulsed outputs connected with safety-related digital inputs. This arrangement can be used to detect short circuits and open circuits in suitable circuit designs, including emergency-stop applications. The pulsed outputs used for line monitoring must not be treated as safety-related outputs.
|
|
Q5. What happens if an F3 DIO 24/16 01 output is overloaded during operation?
An overloaded output channel is switched off for approximately 10 seconds while the overload condition is present. If the total output load of the module exceeds 8 A, all outputs are switched off for approximately 10 seconds and the module performs a new test. A detected module fault switches off all digital outputs and activates the error indication.
|
