IC755CSS10CDA
GE QuickPanel+ 10" View & Control Operator Interface
The IC755CSS10CDA is a 10-inch QuickPanel+ operator interface combining an industrial touchscreen display with embedded computing and communication functions. The unit uses a color TFT display with 800 × 600 SVGA resolution and projected-capacitive two-point multi-touch operation. Its architecture is intended for machine and process operator-interface applications where visualization, control and industrial communication need to be combined in one panel-mounted unit.
|
QUICKPANEL+ VIEW & CONTROL
10"
COLOR TFT / MULTI-TOUCH
INDUSTRIAL HMI
Integrated operator visualization, control and communication platform |
|
01 / TECHNICAL PROFILE
Compact hardware.
Industrial interface. The IC755CSS10CDA combines a 10-inch operator display with embedded processing, memory, industrial communication ports and removable storage capability. This arrangement is useful when the operator station must do more than display graphics and needs local processing and connectivity. |
|
|
12/24 VDC
±20% power input
|
0–55°C
Operating temperature
|
30 W
Maximum power consumption
|
278 × 222 × 65
mm external dimensions
|
|
02 / INDUSTRIAL USE
The operator station
inside the process The QuickPanel+ platform is intended for industrial operator-interface and control applications. Its combination of local processing, graphical visualization, Ethernet and serial communication makes the IC755CSS10CDA suitable for machine-level and process-level HMI installations. It can be used where operators need to monitor values, interact with control screens, access connected equipment and maintain visibility of production conditions from a panel-mounted workstation. |
|
|
03 / MAINTENANCE CONTEXT
Why an IC755CSS10CDA
replacement can become urgent The IC755CSS10CDA is normally searched for when an existing QuickPanel+ 10-inch operator station can no longer perform its intended HMI function. A failed display, unresponsive touchscreen, unstable startup, communication failure, damaged front assembly or hardware fault can remove the operator's normal access to the machine interface. The consequence is not limited to a dark screen. If the panel is being used for operator commands, process visualization, alarm handling or machine status, loss of the HMI can slow troubleshooting and prevent normal interaction with the controlled equipment. In a production environment, that can increase the time required to restore operation. For replacement planning, the important check is not only the catalog number. The installed screen size, bezel version, power arrangement, communication interfaces, mounting dimensions and application software environment should all be considered before the replacement is committed. |
REPLACEMENT CHECKPOINTS
01 Match IC755CSS10CDA and the installed 10-inch configuration.
02 Confirm the 266 × 210 mm panel cutout requirement.
03 Check 12/24 VDC ±20% power compatibility.
04 Confirm Ethernet, serial, USB and SD requirements.
05 Check software and project compatibility before commissioning.
|
|
PANEL INSTALLATION
266 × 210
mm panel cutout
278 × 222 × 65
mm external dimensions
|
MOUNTING & ENVIRONMENT
The IC755CSS10CDA is designed for panel installation and includes mounting brackets and a mounting gasket. VESA 100 × 100 mounting is also specified for the product family. Natural convection is used for cooling. The specified operating temperature is 0°C to +55°C, while storage is specified from -10°C to +60°C. Relative humidity is specified at 85% RH, non-condensing, at 30°C. The external dimensions are approximately 278 mm wide, 222 mm high and 65 mm deep, which should be considered when checking cabinet space and rear-side clearance. |
|
04 / QUICKPANEL+ FAMILY
10" · 12" · 15"
The QuickPanel+ family includes multiple screen sizes using the same general operator-interface concept. The 10-inch IC755CSS10CDA is the compact member of the 10/12/15-inch group and is suited to installations where panel space is more limited. |
|
|
05 / BUYER QUESTIONS
Questions that matter
before replacement The following points focus on compatibility, installation and operational continuity rather than basic catalog identification. |
Q1 — Can IC755CSS10CDA replace a failed 10-inch QuickPanel+ operator station?
It can be considered when the existing installation uses the same IC755CSS10CDA configuration. Before ordering, compare the complete part number, bezel arrangement, mounting dimensions, power input and installed communication requirements rather than matching screen size alone.
Q2 — Is IC755CSS10CDA suitable when the machine HMI must communicate through both Ethernet and serial ports?
Yes. The unit provides two 10/100Base-T Ethernet ports together with RS-232 and RS-485 serial interfaces. The actual connection method should still be matched to the machine's existing network and device architecture.
Q3 — What should be checked when IC755CSS10CDA is being installed into an existing cabinet?
The panel cutout is specified as 266 × 210 mm, while the external unit dimensions are approximately 278 × 222 × 65 mm. Cabinet depth, rear connectors, mounting arrangement, ventilation and cable routing should therefore be checked before installation.
Q4 — Why might an IC755CSS10CDA become a priority spare after an HMI failure?
If the panel is the operator's primary interface, loss of its display, touchscreen or communication function can remove access to machine status, operator commands and process visualization. This can extend troubleshooting and increase production interruption until the HMI station is restored.
Q5 — Does IC755CSS10CDA have enough local storage and processing for an embedded HMI role?
The unit combines a 1 GHz ARM Cortex-A8-based processor, 1 GB DDR3 SDRAM, 512 MB SLC NAND flash and 512 KB battery-backed SRAM. It also provides SD/SDHC storage and USB interfaces, giving the panel local computing and data-handling capability beyond a simple display terminal.
|
 |
