| BENTLY NEVADA · MACHINERY CONDITION MONITORING | OverviewSpecificationsIntegrationRelated ModelsFAQ |
An armored standard-mount 3300 XL 8 mm probe for non-contact shaft vibration, position, speed and Keyphasor measurements.
CHECK PRICE & AVAILABILITY| Probe family 3300 XL 8 mm Proximity Probe |
Probe-tip diameter 8 mm |
Mounting thread 3/8-24 UNF-2A |
| Cable armor Armored |
Unthreaded length 0.0 in |
Overall case length 3.0 in |
| Total probe length 1.0 m (3.3 ft) |
Connector / cable ClickLoc with protector; standard cable |
Approval option CSA, ATEX and IECEx |
| 01 Conductive target |
02 8 mm probe tip |
03 Extension cable / system length |
04 Matched Proximitor sensor |
05 Monitor or control input |
| Experienced support for exact-code part matching. | Inspection and configuration checking before dispatch. | Urgent delivery coordination to reduce downtime. |
AMIKON supports global industrial automation buyers with responsive quotations, careful part matching, quality-focused fulfillment and international delivery coordination.
| Q1 | What does the complete catalog number control? It defines probe family, mechanical dimensions, total cable length, connector arrangement and approval option. |
| Q2 | Can a similar-looking probe be installed directly? Do not assume interchangeability. Match probe diameter, thread, length, cable, Proximitor system length and target material. |
| Q3 | What should be checked before installation? Confirm mounting geometry, probe gap, cable routing, system length, connector condition and monitor configuration. |
| Q4 | What should accompany an inquiry? Provide the full catalog number, quantity, required condition and delivery destination. |
Send the catalog number, quantity and delivery destination for quotation.
CONTACT MIYA ZHENG| 01 6SE7032-6EG84-1GG0 | 02 51307687-176 | 03 KJ4010X1-BG1 12P0830X062 | 04 SP100401-010064 | 05 330173-00-05-10-02-00 | 06 DS200TCPSG1APE |
| 07 TM0182-A50-B00-C00 | 08 1769-L18ERM-BB1B | 09 1336F-MCB-SP1C | 10 990-04-70-02-00 | 11 PFSK101 YM322001-ED | 12 DSTC120 57520001-A |
| 13 AI835 3BSE008520R1 | 14 E2172/1/80 | 15 DS200TBQBG1ACB | 16 MC-TAOX12 51304335-175 | 17 MU-TAIH02 51304453-100 | 18 SPD36006-00 |
| 19 T2798I-1000 | 20 A5E00677650 | 21 51401946-100 | 22 PM802F 3BDH000002R1 | 23 900P01-0201 51450991-002 | 24 ST3/4X2.500 |
| 25 IC695CMM002 | 26 NMTU-21C 3BSE017429R1 | 27 DNA-040K-22B | 28 1336F-MCB-SP1K | 29 6SY7000-0AA88 | 30 YXI115B YT204001-AL |
| 31 DSDO115 57160001-NF | 32 YPQ202A YT204001-KB | 33 129716-125-040-15-05 | 34 DS200TBQCG1ABB | 35 MC-TDOR12 51309148-175 | 36 MU-TDID12 51304441-125 |
| 37 BSM80C-275AFX | 38 1C31223G01 | 39 6SE7090-0XX84-6FE0 | 40 1151DP3J12B2 | 41 AI895 3BSC690086R1 | 42 C6691/IRD |
| 43 MGQL20-20 | 44 8718L-08S-21RO | 45 2711C-K3M | 46 4-HESI 5X20 | 47 FS-CPCHAS-0003 | 48 6SE7031-7HF84-1HH2 |
| 49 NCQ7B400-250DC | 50 KJ4010X1-BF1 12P0831X072 | 51 CLV440-0010 | 52 330180-X1-05 MOD: 145004-75 | 53 DS200TCPSG1AME | 54 100S-C16EJ422C |
| 55 MU-TLPA02 51309204-125 | 56 1336-BDB-SP38A | 57 3HAC14549-3 | 58 DSPC173 57310001-MT | 59 6L-L45-F1A-RR | 60 CI854AK01 3BSE030220R1 |
| 61 E2170/1/80 | 62 AG24A02A | 63 MC-TAIH12 51304337-150 | 64 VQ4600-5W1-Q | 65 CE02TFNHK-FD000-D | 66 CC-PDOD51 51454408-175 |
| Catalog number | 330102-00-30-10-01-05 |
| Quotation details | Quantity, required condition, installed system length and destination |
| Return arrangement | Contact us within seven days after receipt if assistance is needed. Eligible items must remain in original condition and include a clear return reason. Return or replacement is arranged after inspection, and shipping charges are the buyer's responsibility. |
