EIGHT CHANNELS, ONE CONTROL PLANE
IC695ALG8088-CHANNEL ISOLATED ANALOG OUTPUT
|
||
|
08
ISOLATED OUTPUT CHANNELS
|
IC695ALG808 provides eight individually selectable analog output channels for PACSystems RX3i control applications. Each channel can be configured for voltage or current operation, allowing one module to serve mixed final-control requirements while retaining channel-level setup and diagnostics.
|
8 ms
ALL-CHANNEL UPDATE
|
|
8
Output channels
Voltage or current by channel.
|
±10 V
Bipolar range
15-bit resolution.
|
0–10 V
Unipolar range
14-bit resolution.
|
0/4–20 mA
Current ranges
15-bit resolution.
|
24 VDC
Field power
660 mA external requirement.
|
RX3i rack
Mounting
Universal backplane format.
|
| 01 | Channel architecture | Eight isolated analog outputs support a mix of voltage and current signals. Range selection is made by channel, reducing the need to separate unlike final-control signals across multiple modules. |
| 02 | Voltage operation | Available voltage ranges are -10 to +10 V and 0 to 10 V. Bipolar operation uses 15-bit resolution; the unipolar 0 to 10 V range uses 14-bit resolution. |
| 03 | Current operation | Current channels support 0 to 20 mA and 4 to 20 mA at 15-bit resolution. The selected mode must agree with field-device input characteristics and wiring. |
| 04 | Update performance | All eight channels are updated in 8 ms. Control-loop timing should include CPU execution, communications, module update and final-device response. |
| 05 | Power demand | The module consumes 250 mA at 3.3 V and 17 mA at 5 VDC from the rack, plus 660 mA from an external 24 VDC source for field-side operation. |
| 06 | Commissioning discipline | Confirm channel range, scaling, commanded safe state, external supply, terminal assignment and load resistance before enabling outputs. A similar-looking module is not sufficient evidence of interchangeability. |
|
01
Control strategy
Produces the engineering-unit command.
|
02
IC695ALG808
Converts eight commands to analog signals.
|
03
Field wiring
Carries the selected voltage or current.
|
04
Final control element
Positioner, drive or converter receives the command.
|
| RELATED MODEL | PRIMARY DISTINCTION | CAPACITY / MEMORY | SYSTEM ROLE |
| IC695ALG704 | 4 channels | Voltage / current | Lower channel density |
| IC695ALG708 | 8 channels | Voltage / current | Non-isolated family option |
| IC695ALG808 | 8 channels | Voltage / current, isolated | Channel isolation emphasis |
| IC695ALG616 | 16 channels | Current output | Higher current-channel density |
|
QUALITY + RESPONSE
Fast, reliable delivery supports urgent automation maintenance.
|
VERIFY + PREPARE
Careful order tracking and part checks protect shutdown schedules.
|
STOCK + DELIVERY
Current and discontinued automation parts are sourced for global customers.
|
| ◇ QUALITY | ⇄ RELIABILITY | ✦ TRANSPARENCY | ☎ CUSTOMER SUPPORT |
| 01 | IC695ALG808: Can IC695ALG808 mix voltage and current outputs in one module? | Yes. Output type and range are selectable by channel, so the eight-channel set can combine supported voltage and current modes when configured and wired correctly. |
| 02 | IC695ALG808: What external power is required for IC695ALG808? | The module requires an external 24 VDC supply rated for the stated field-side demand of 660 mA, in addition to its 3.3 V and 5 V rack consumption. |
| 03 | IC695ALG808: Will IC695ALG808 update every channel at the same speed? | The specified update time is 8 ms for all eight channels. Overall loop response also depends on controller scan, network traffic and the connected final element. |
| 04 | IC695ALG808: What must be verified before replacing IC695ALG808? | Match the full catalog number, hardware revision, terminal assembly, per-channel range and scaling, wiring polarity, external supply and configured fault behavior. |
| 05 | IC695ALG808: Is IC695ALG808 interchangeable with another eight-channel analog module? | Not automatically. Isolation, range set, resolution, power demand, terminal arrangement and project configuration can differ even when channel count appears identical. |
