32 MM · LARGE-SHAFT MEASUREMENT
The Rotor Moves.
|
|
| 01 | Product type | Non-contact eddy-current sensor |
| 02 | Sensor family | PR6426, 32 mm |
| 03 | Complete order code | PR6426/000-130 |
| 04 | Measurement duties | Radial and axial displacement, position, eccentricity and shaft motion |
| 05 | Static measurement range | ±4.0 mm |
| 06 | Nominal center air gap | Approximately 5.5 mm |
| 07 | Sensitivity | 2 V/mm; 50.8 mV/mil |
| 08 | Target | Ferromagnetic steel 42CrMo4 standard |
| 09 | Minimum shaft diameter | 200 mm |
| 10 | Maximum surface speed | 2,500 m/s |
| 11 | Operating temperature | −35 to +175 °C |
| 12 | Construction | Stainless-steel sleeve with PTFE cable |
| 13 | System rule | Use as a factory-matched chain with cable and compatible CON converter |
| 14 | Installation control | Maintain the required ferrous-material clearance and correct cable bend radius |
| Confirm suffix, cable, converter and monitor scale together. | REQUEST A MATCH CHECK |
|
1
PR6426/000-130
32 mm · ±4 mm · 2 V/mm
Large-shaft measurement
|
2
PR6424 family
16 mm · ±2 mm · 4 V/mm
Medium measurement range
|
3
PR6423 family
8 mm · 2 mm linear range · 8 V/mm
Compact turbomachinery probe
|
4
CON011 / 021 / 031 / 041
Matched signal conversion
Completes the calibrated chain
|
The installed channel is a calibrated chain. Mechanical similarity or connector fit does not prove electrical interchangeability.
|
20 Years of Supply Experience
Experienced support for current and hard-to-find automation parts. |
Inspection Focus
Clear part matching helps reduce avoidable order errors. |
Emergency Dispatch
Responsive coordination for downtime-driven requirements. |
| Contact us within seven days if a concern appears after receipt. | Keep the item in its original condition and state the specific reason. Resolution follows receipt and inspection. | Return-related shipping costs are paid by the buyer. |
| 01 |
PR6426/000-130 — Can PR6426/000-130 be replaced by another PR6426 suffix?
Not automatically. Confirm mounting construction, armor, total cable length, cable end, converter pairing and the complete installed order string.
|
| 02 |
PR6426/000-130 — Why is shaft size important for PR6426/000-130?
The published PR6426 performance is based on large targets, with a minimum shaft diameter of 200 mm. Target geometry and surrounding metal affect the field.
|
| 03 |
PR6426/000-130 — What converter is required with PR6426/000-130?
The PR642x system is used with a compatible, matched CON011, CON021, CON031 or CON041 arrangement, or an approved integrated converter. Match the installed chain.
|
| 04 |
PR6426/000-130 — What must be checked after installing PR6426/000-130?
Verify mechanical clearance, cable routing, center gap, output voltage, polarity, monitor scale, alarms and the machine-specific functional test.
|
| 05 |
PR6426/000-130 — Can continuity testing prove PR6426/000-130 is healthy?
No. Continuity can find an open circuit, but it cannot validate calibration, sensitivity, linearity, target compatibility or converter matching.
|
