Allen-Bradley 2711P-T10C4D6 Color Touch HMI / Ethernet / RS-232 / DC

Allen-Bradley 2711P-T10C4D6
Allen-Bradley 2711P-T10C4D6
Allen-Bradley 2711P-T10C4D6

Allen-Bradley 2711P-T10C4D6 Color Touch HMI / Ethernet / RS-232 / DC

Calculate shipping
Quotation Request
ALLEN-BRADLEY
2711P-
T10C4D6
PANELVIEW PLUS CE
1000 Color Terminal
⌘   ▦

TERMINAL PROFILE
HMI / COMMUNICATION / MEMORY
DISPLAY
10.4"
FLASH
128 MB
RAM
128 MB
01   Color touchscreen terminal
02   Ethernet and RS-232
03   24V DC nominal power
Legacy equipment · Check configuration and revision before ordering.
AMIKON LIMITED
Industrial Parts Service
International Delivery on the Day
Quick Response Support
Intercontinental Cooperation Network
Sales manager: Miya zheng
HMI
DATA
PLC
PANELVIEW PLUS 1000 TERMINAL

2711P-T10C4D6

Color Touch HMI / Ethernet / RS-232 / DC

A configured machine-level operator terminal combining a 10.4-inch touch display, logic module, built-in communications and the extended-feature software configuration.

  +   +
/01 TOUCH INPUT
/02 ETHERNET
/03 RS-232
/04 24 VDC CLASS
[+] PRODUCT DETAIL

Role, Hardware and Operating Fit

2711P-T10C4D6

The 2711P-T10C4D6 is a complete modular HMI terminal rather than only a display. Its catalog code combines the 1000-size color touch display, base Ethernet/RS-232 communication, DC power and the extended-feature memory/software configuration used in legacy PanelView Plus installations.

Manufacturer: ALLEN-BRADLEY
Product type: PanelView Plus 1000 Touch Terminal

Operator input Touch screen
Display 10.4 in. color active-matrix TFT
Display area 211 x 158 mm (8.3 x 6.2 in.)
Resolution 640 x 480, 18-bit color graphics
Base communications Ethernet and RS-232
Power input DC-powered terminal
Memory code Extended-feature configuration
Migration path 2711P-T10C4D9 on PanelView Plus 6
01 / Direct operation

Color touch input presents machine status, commands, alarms and navigation at the equipment.


02 / Network integration

Built-in Ethernet and serial communication support established controller connections and application transfer.


03 / Migration clarity

The catalog structure provides a defined PanelView Plus 6 conversion path when modernization is planned.
Confirm the complete installed configuration
Back up the runtime application and confirm communication drivers, firmware, memory option, power type, panel cutout, optional communication module and controller path before replacement.		 REQUEST A QUOTE >
[X] SERIES / SYSTEM

Select by System Role and Catalog Code

MODEL SYSTEM POSITION PURCHASING DISTINCTION
2711P-T10C4D6 Complete 1000 touch terminal Ethernet/RS-232, DC, extended features
2711P-T10C4D1/D2 Complete terminal Different memory/software code
2711P-T10C15D6 Complete terminal Adds ControlNet communication
2711P-RDT10C Display module only No logic module or stand-alone operation
Selection checkpoint
Back up the runtime application and confirm communication drivers, firmware, memory option, power type, panel cutout, optional communication module and controller path before replacement.
[20+] AUTOMATION SUPPLY

Experienced Support for Urgent Requirements

Quality and Experience

AMIKON supports current, scarce and discontinued automation requirements with responsive communication and careful order checks.


Inspection Awareness
Catalog-code and condition checks help reduce ordering mistakes.

Urgent Dispatch Support
Fast handling options support recovery from unplanned downtime.
[@] DIRECT CONTACT

Keep the Requirement Moving

MIYA ZHENG - SALES MANAGER SALES@AMIKON.CN WHATSAPP +86 180 2077 6792
Contact within seven days
Raise any concern promptly after receipt.		   Keep original condition
State the return reason and preserve the item.		   Resolution after inspection
Buyer covers return-related shipping costs.
[?] PURCHASING FAQ

Five Checks Before Ordering

01
2711P-T10C4D6: Is 2711P-T10C4D6 the same item as 2711P-RDT10C?
No. The T10C4D6 is a configured terminal; RDT10C is the replaceable display module only.

02
2711P-T10C4D6: What network capability is built into 2711P-T10C4D6?
The base unit has Ethernet and RS-232 ports. Any additional communication module must be checked separately.

03
2711P-T10C4D6: What is the practical migration path for 2711P-T10C4D6?
The catalog conversion path points to 2711P-T10C4D9 on the PanelView Plus 6 platform. Application and firmware work must still be planned.

04
2711P-T10C4D6: What must be saved before replacing 2711P-T10C4D6?
Secure the runtime application, communication settings, shortcuts, firmware level, passwords and any external storage contents.

05
2711P-T10C4D6: What should be checked before powering 2711P-T10C4D6?
Confirm DC supply polarity and range, protective earth, cutout fit, communication wiring and the installed option module.
