Allen Bradley 25B-D017N104 7.5 kW / 10 HP AC Drive

Allen Bradley 25B-D017N104
Allen Bradley 25B-D017N104
Allen Bradley 25B-D017N104

Allen Bradley 25B-D017N104 7.5 kW / 10 HP AC Drive

Calculate shipping
Quotation Request
ALLEN-BRADLEY
25B-D017N104
PowerFlex 525
AC Drive

380–480V AC  •  3 Phase
POWER
7.5 kW
10 HP
OUTPUT
17 A
Rated Output Current
FRAME
C
IP20 / Open Type
SALES CONTACT Miya Zheng sales@amikon.cn
DIRECT CONTACT WhatsApp  86-18020776792
25B-D017N104 Overview Specifications Application FAQ Commercial Contact
ALLEN-BRADLEY / POWERFLEX 525
25B-D017N104

7.5 kW / 10 HP AC Drive
380–480 V AC • Three Phase • 17.5 A Output • Frame C
DRIVE PROFILE
PowerFlex 525
Voltage 380–480 V AC
Output 17.5 A
Frame Frame C
POWER
7.5 kW
10 HP
OUTPUT
17.5 A
AC drive output rating
ENCLOSURE
IP20
NEMA / Open Type
TECHNICAL PROFILE
Key Specifications

Product family PowerFlex 525 AC Drive
Catalog number 25B-D017N104
Input voltage 380–480 V AC, 3 Phase
Output current 17.5 A
Normal-duty rating 10 HP / 7.5 kW
Heavy-duty rating 10 HP / 7.5 kW
Frame Frame C
Enclosure IP20 NEMA / Open Type
EMC filtering No Filter
Interface Standard interface module
Network / safety Embedded EtherNet/IP and Safety
OPERATING CONTEXT
Where This Drive Fits

The 25B-D017N104 is a PowerFlex 525 variable frequency drive intended for three-phase motor control in the 380–480 V class. Its embedded EtherNet/IP capability makes it suitable for automation architectures where drive operation and motor control are integrated into a networked control system.
In maintenance situations, this catalog number is particularly relevant when an installed PowerFlex 525 has a failed power section, drive fault, loss of motor control, or a replacement requirement where the original electrical rating and frame configuration must be preserved.



NETWORKED CONTROL
Embedded EtherNet/IP
SAFETY FUNCTION
Embedded Safety
INSTALLATION CLASS
IP20 / NEMA Open Type
01
Drive Fault
A failed or faulted drive can interrupt controlled motor operation.
02
Motor Control Loss
Unexpected loss of drive control can stop the connected process.
03
Downtime
A correct replacement can help reduce the duration of an unplanned shutdown.
PURCHASING FAQ
Questions Before Replacement

Can the 25B-D017N104 be considered when the existing drive requires a 10 HP replacement in a 380–480 V system?
Yes. The 25B-D017N104 is rated for 10 HP / 7.5 kW in both normal-duty and heavy-duty service, with a 380–480 V AC three-phase input class and 17.5 A output rating.
What should be checked if the installed cabinet uses a networked PowerFlex 525 architecture?
The 25B-D017N104 includes embedded EtherNet/IP, so the replacement evaluation should consider the existing control-network arrangement as well as the drive's voltage, current, frame, enclosure, and interface configuration.
Why does the no-filter configuration matter when selecting this exact drive?
This catalog number is specified with no EMC filter. If the installation was designed around a different filtering configuration, that difference should be evaluated before ordering a replacement.
What makes the Frame C designation worth checking during a replacement?
Frame size affects the physical installation arrangement. The 25B-D017N104 uses Frame C, so the replacement should be checked against the existing mounting and enclosure arrangement rather than matching only horsepower.
When is this catalog number especially useful to provide during an urgent plant repair?
It is most useful when the failed unit must be matched by exact catalog number, electrical class, output rating, frame, enclosure type, and configuration so that the replacement assessment does not rely on horsepower alone.
SEND THESE FIVE DETAILS
Make Matching Faster

01 Part Number
02 Quantity
03 Destination
04 Required Date
05 Machine / System
ORDER ARRANGEMENT
Delivery & Commercial Terms

DELIVERY
3–5 Days
WARRANTY
12 Months
PACKAGING
New
PAYMENT
T/T
DELIVERY WAY
E-packing / FedEx / EMS / TNT / DHL / UPS
AFTER DELIVERY
Return & Replacement
• Contact us within 7 days if an issue is found after receipt.
• Returned items should remain in their original condition and include the specific reason for return; return or replacement arrangements will be handled after receipt.
• Return shipping costs are the buyer's responsibility.
SERVICE APPROACH
Built Around Industrial Parts Support
A broader service network supports every stage of an automation parts order, from multilingual communication and order coordination to shipment tracking. The goal is simple: make difficult-to-source industrial components easier to connect with the right customer and application.
