YOKOGAWA • SERIAL COMMUNICATION • FIO
ALR121-S01
RS-422 / RS-485 COMMUNICATION MODULE
|
|||||
|
↔
SERIAL
LINK |
Industrial Serial Communication Interface
The ALR121-S01 is a serial communication module designed for Yokogawa field-control architectures, providing RS-422/RS-485 connectivity between the control system and external serial devices. Its communication architecture supports point-to-point RS-422 connections and multipoint RS-485 networks.
RS-422 RS-485 HALF-DUPLEX 1200 m
|
◎
FIO
NETWORK |
|||
|
|||||
| Interface | RS-422 / RS-485 | Connection | Point-to-point / Multipoint |
| Communication | Half-duplex | Synchronization | Start-stop |
| Transmission Speed | 1200 / 2400 / 4800 / 9600 / 19200 / 38400 bps | Transmission Code | ASCII / Binary |
| Character Length | 7 / 8 bits | Stop Bit | 1 / 2 bits |
| Parity | None / Even / Odd | Transmission Distance | Up to 1200 m total extended length |
| Current Consumption | 0.5 A | Weight | Approx. 0.30 kg |
ALR121 is the RS-422/RS-485 member of the ALR serial communication family. Within Yokogawa control architectures, it provides the serial interface between the control-side node and compatible external subsystems.
|
ALR111
RS-232C Path
The ALR111 uses RS-232C and is intended for point-to-point serial communication. |
TARGET MODULE
ALR121-S01
RS-422/RS-485 interface with point-to-point RS-422 and multipoint RS-485 connection capability. |
ALR121 FAMILY
Serial Integration
Communication functions include FA-M3, Modbus, MELSEC-A, YS, SLC500 and PLC-S communication according to the applicable configuration. |
|
01
FA-M3 Communication
1200 / 2400 / 4800 / 9600 / 19200 / 38400 bps*
|
02
Modbus Communication
1200 / 2400 / 4800 / 9600 / 19200 bps
|
03
MELSEC-A Communication
1200 / 2400 / 4800 / 9600 / 19200 bps
|
|
04
YS Communication
9600 bps
|
05
SLC500 Communication
1200 / 2400 / 4800 / 9600 / 19200 bps
|
06
PLC-S Communication
1200 / 2400 / 4800 / 9600 / 19200 bps
|
Send your required quantity, destination and required delivery date for a direct quotation.
|
EMAIL
sales@amikon.cn
Click to send inquiry →
|
SALES MANAGER
Miya zheng
Industrial automation sales
|
PHONE / WHATSAPP
86-18020776792
Click to contact →
|
|
AFTER-SALES
Return / Replace
|
01. Please contact us within 7 days if you have any question after you receiving the items.
02. The returned items has to be in its original condition, with a specific reason for the return. We will issue a return or replacement for your order after we received the returns.
03. The buyer is responsible for all the shipping cost incurred.
|
|
Can ALR121-S01 be used when the existing network requires RS-485 multipoint communication?
Yes. ALR121 supports RS-485 multipoint connection, while RS-422 is used for point-to-point communication. This distinction is important when matching the module to the physical topology of the existing serial network.
|
Is ALR121-S01 suitable when the serial device is located far from the control node?
The specified maximum transmission distance for ALR121 is up to 1200 m in total extended length. Actual installation performance still depends on the selected communication method, wiring arrangement and connected equipment.
|
|
Which transmission settings should be checked before ordering ALR121-S01 for an existing subsystem?
The serial configuration should be checked against the intended communication function, including transmission speed, character length, stop-bit setting, parity and transmission code. ALR121 supports 1200 to 38400 bps depending on the selected communication function.
|
Can the two ALR121-S01 ports be configured for different communication functions?
No. The ALR121 communication module selects one communication function, so the two ports use the same communication function rather than independently selecting different functions.
|
|
What should buyers verify when replacing an ALR121-S01 in an operating Yokogawa node?
Verify the exact ALR121 variant, the host node arrangement, the intended communication function, serial wiring configuration and environmental conditions before replacement. For ALR121-S01 installations, the applicable ambient-temperature condition is 0 to 60°C.
|
|
