YOKOGAWA ALE111-SE1 Ethernet Communication Module for N-IO / FIO

YOKOGAWA ALE111-SE1
YOKOGAWA ALE111-SE1
YOKOGAWA ALE111-SE1

YOKOGAWA ALE111-SE1 Ethernet Communication Module for N-IO / FIO

Calculate shipping
Quotation Request
YOKOGAWA · FIO
ALE111-SE1
Ethernet Communication Module
10BASE-T

NETWORK INTERFACE
RJ45
CONNECTOR
 ↔
LAN
POINT-TO-POINT
10BASE-T
PHYSICAL LAYER
0.5 A
CURRENT
ALE111-SE1 is a standard-type Ethernet communication module for FIO. The suffix combination identifies the standard type with ISA Standard G3 option.
DIRECT CONTACT
Miya zheng
Sales Manager
✉ SALES EMAIL ☎ WHATSAPP
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world. YOKOGAWA · FIO · GLOBAL SUPPLY






YOKOGAWA • CENTUM VP • FIO / N-IO
ETHERNET COMMUNICATION MODULE

YOKOGAWA ALE111-SE1

Ethernet Communication Module for N-IO / FIO
10
Mbps Ethernet
RJ45
Single port
100 m
Maximum segment
1
Communication function
ALE111 is an Ethernet communication module used by a Field Control Station to communicate with external subsystems. It can be mounted on applicable field control and bus-node hardware and transfers subsystem data through an Ethernet connection. Within the control application, subsystem data can be handled through the communication I/O area and used by function blocks in a manner comparable to general analog and digital I/O signals.
SUFFIX ARCHITECTURE
ALE111-SE1
Base model ALE111
Type S / Standard
Protection code E
Option ISA Standard G3
CONTROL-NETWORK INTERFACE
ALE111-SE1 Product Architecture
01 / Ethernet Communication Role
ALE111 provides an Ethernet interface between the Field Control Station and connected subsystems. The module uses an IEEE 802.3 10BASE-T physical interface and communicates through a single RJ-45 port. The standard transmission speed is 10 Mbps and the transmission method is half-duplex.
Core path: FCS → ALE111 → Ethernet → subsystem
02 / Physical Interface
Interface IEEE 802.3 10BASE-T
Connector RJ-45
Ports 1
Cable 100 Ω twisted pair
03 / Subsystem Data Path
ALE111 stores subsystem data in the communication module's I/O image. The FCS accesses that image asynchronously and can reference or set the data through its communication I/O area. This architecture allows subsystem values to participate in sequence-control and regulatory-control processing.
Subsystem → ALE111 I/O Image → FCS Function Blocks
04 / Installation Platforms
The module can be mounted on applicable Yokogawa field-control and bus-node hardware.
AFV30□ / AFV40□
A2FV50□
ANB10□ ESB bus node unit
ANB11□ optical ESB bus node unit
◌
Technical Profile
Physical layer IEEE 802.3 10BASE-T Transmission speed 10 Mbps
Transmission method Half-duplex Connector RJ-45
Transmission route 100 Ω twisted-pair cable Maximum segment 100 m
Number of ports 1 Current consumption Approx. 0.5 A
Weight Approx. 0.30 kg Mounting FIO / N-IO compatible hardware
Communication definitions 128 definitions / ALE111 Communication I/O 1000 words / ALE111
Communication functions One function per ALE111 FCS total I/O capacity Up to 8000 words


MULTI-SUBSYSTEM CONNECTIVITY
Communication Functions
FA-M3
Ethernet communication with FA-M3 interface and CPU modules. TCP/IP is used, with up to 30 subsystem stations per ALE111.
Modbus
Supports OPEN Modbus/TCP based subsystem communication with applicable Yokogawa and Schneider Electric equipment.
MELSEC
Ethernet communication with applicable Mitsubishi Q Series, QnA Series and A Series interface configurations.
YFGW
Communication with YFGW410 and YFGW710 gateways. Field wireless device communication can be integrated into the control environment.
DARWIN / DAQSTATION
Measurement, alarm and calculation data can be acquired from compatible DARWIN and DAQSTATION systems.
PLC-5 / SLC500
Ethernet communication is available with applicable PLC-5 and SLC500 CPU modules using CSP protocol.
Important architecture point: a single ALE111 module establishes one communication function at a time. Multiple communication functions are not performed simultaneously on the same ALE111 module.
Capacity & Architecture Snapshot
32
communication modules / FCS
16
dual-redundant pairs / FCS
128
definitions / ALE111
1000
words / ALE111
8000
words / FCS


SERIES / SYSTEM RELATIONSHIP
Where ALE111 Fits in the CENTUM VP Communication Layer
FCS
Performs control computation and provides the function-block environment in which communication I/O data can be used.
 →
ALE111-SE1
Provides the Ethernet communication interface and manages the communication I/O image used by the FCS.
 →
Subsystem
External equipment such as FA-M3, Modbus devices, MELSEC, YFGW, DARWIN/DAQSTATION and PLC-5/SLC500.
Series distinction: ALE111 is the Ethernet communication module in the CENTUM VP communication-module family. ALR111 / ALR121 provide serial communication roles, while ALF111 is used for FOUNDATION Fieldbus communication and ALP111 / ALP121 serve PROFIBUS-DP communication roles. The correct module therefore depends on the external network and subsystem interface required by the FCS.
ALE111-SE1 Configuration Focus
S
Standard type
E
Explosion-protection option code
1
ISA Standard G3 option
10BASE-T
Ethernet physical layer
When replacing an installed ALE111, the suffix should be matched rather than treating all ALE111 variants as interchangeable. The environmental and protection configuration represented by the suffix can affect whether the replacement is suitable for the existing installation.





AMIKON / INDUSTRIAL NETWORK
NODE 01 — GLOBAL SOURCING
NODE 02 — RAPID DELIVERY
NODE 03 — SUPPLY CONTINUITY
AMIKON GLOBAL INDUSTRIAL SUPPLY
Sustainable Supply.
Faster Industrial Recovery.

At AMIKON, our mission is to promote the development of a sustainable and efficient global industrial supply chain. With an inventory of more than 1 million hard-to-find industrial parts, we help system integrators and suppliers reduce unexpected shortages and extended lead times. Long-term industrial asset partnerships across industries allow us to support global sourcing for new, obsolete and discontinued industrial parts, equipment and machinery.
1M+
Industrial Parts		 FAST
Delivery		 CARE
Customer Service		 GLOBAL
Supply Needs
PURCHASING SUPPORT
Looking for YOKOGAWA ALE111-SE1?
Send the exact part number, required quantity, destination, required date and machine or system details. This helps the sales team check the correct configuration and arrange a suitable delivery route for your maintenance or replacement requirement.
Delivery
3–5 days		 Warranty
12 months
Packaging
Brand New		 Payment
T/T
AMIKON LIMITED
Sales Manager: Miya Zheng
Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS
After-Sale Support
01 / Contact Window
Please contact us within 7 days after receiving the items if any issue arises.		 02 / Return Condition
Returned items should remain in original condition and include a specific reason for the return.		 03 / Resolution
A return or replacement can be arranged after the returned item is received. Shipping costs are the buyer's responsibility.
PURCHASE DECISION POINTS
ALE111-SE1 Buyer FAQ
Q1. When replacing an ALE111-SE1, should the new unit be matched by the complete suffix rather than only the ALE111 base model?
Yes. The suffix carries configuration details. ALE111-SE1 combines the S type, E protection designation and the ISA Standard G3 option. A replacement should therefore be checked against the installed configuration instead of treating every ALE111 variant as identical.
Q2. Can an ALE111-SE1 be selected simply because the existing system has an Ethernet connection?
Not by Ethernet availability alone. ALE111 is specifically an Ethernet communication module for the applicable CENTUM VP FCS architecture. The installed FCS, mounting position, communication function and connected subsystem should all be checked before selecting a replacement.
Q3. If an ALE111-SE1 is being used for subsystem communication, can one module simultaneously perform several communication functions?
No. The ALE111 architecture establishes one communication function for each module. Multiple communication functions are not performed simultaneously on a single ALE111. The required subsystem protocol should therefore be identified before assigning the module.
Q4. Is ALE111-SE1 suitable when a project needs a long Ethernet run between the FCS and subsystem?
The specified 10BASE-T transmission route uses 100 Ω twisted-pair cable with a maximum segment distance of 100 m. If the planned physical route exceeds that distance, the network architecture should be reviewed rather than assuming that one direct segment will cover the complete route.
Q5. What should be checked when an ALE111-SE1 replacement is intended for a redundant communication arrangement?
ALE111 supports dual-redundant communication by using two ALE111 modules in adjacent odd- and even-numbered slots of the same node unit. The existing node arrangement and communication architecture should therefore be checked before ordering a single replacement module for a redundant pair.
