YOKOGAWA AIP830-111 Operation Keyboard for Single-loop Operation

YOKOGAWA AIP830-111
YOKOGAWA AIP830-111
YOKOGAWA AIP830-111

YOKOGAWA AIP830-111 Operation Keyboard for Single-loop Operation

Calculate shipping
Quotation Request
YOKOGAWA · HIS
AIP830-111
Operation Keyboard for Single-loop Operation
Flat keyboard
USB speaker function

OPERATOR INTERFACE
USB A ×2
CONNECTORS
5V±5%
INPUT
1A
MAX CURRENT
The AIP830 is a flat operation keyboard for Desktop Type HIS. The operation-keyboard function uses USB 2.0 full-speed, bus-powered connection, while its sound function uses USB 1.1.
Ambient operation: 5–40°C · Storage/transport: −20–60°C
AMIKON CONTACT
Miya zheng
Sales Manager
✉ EMAIL ☎ WHATSAPP
We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.




YOKOGAWA • CENTUM VP • DESKTOP HIS
OPERATION KEYBOARD

YOKOGAWA AIP830-111

Operation Keyboard for Single-loop Operation
01
Single-loop operation
02
Dual USB A interface
03
64 function keys
04
USB speaker sound function
The AIP830-111 is a dedicated operation keyboard for a Desktop Type Human Interface Station. Its layout combines alphanumeric input, dedicated operation keys, grouped window-call keys and 64 user-definable function keys for process control and plant monitoring. The -111 configuration incorporates the mode selection switch and Type B operation confirmation key arrangement.
CONFIGURATION CODE
AIP830-111
Base model AIP830
First suffix -1
Confirmation key Type B
Fixed code 1
ENGINEERED OPERATOR INTERFACE
AIP830-111 Product Architecture
01 / Operator-Centered Layout
The keyboard combines conventional alphanumeric keys with dedicated operation keys. Window-call keys are grouped by function, while the 64 function keys provide a dedicated area for user-defined functions used in process control and plant monitoring.
Designed around direct operator access rather than general-purpose PC keyboard use.
02 / Independent Sound Function
AIP830 includes an independent USB speaker sound function in addition to the electronic buzzer. The sound function uses the second USB interface and is bus-powered from the connected computer.
USB 2.0 / Keyboard USB 1.1 / Sound
03 / Direct USB Bus Power
The AIP830 uses two USB A-type connectors. The operation keyboard function conforms to USB 2.0 Full-speed and is bus-powered; the sound function conforms to USB 1.1 Full-speed and is also bus-powered. Both connectors are intended to be connected directly to the computer.
04 / Industrial Control-Room Form
The flat keyboard has a black chassis and is intended for Desktop Type HIS operation. The standard unit weighs approximately 2.0 kg without the VESA bracket and approximately 2.5 kg with the VESA bracket.
◌
Technical Profile
Product type Flat operation keyboard Application Desktop Type HIS
PC connectors 2 × USB A type Keyboard USB USB 2.0 Full-speed, Bus-powered
Sound USB USB 1.1 Full-speed, Bus-powered Input voltage 5 V ±5%
Maximum current 1 A Chassis color Black, equivalent to Munsell N1.5
Weight Approx. 2.0 kg without VESA / 2.5 kg with VESA Cable length 2300 ±100 mm
Normal operation temperature 5 to 40 °C Storage / transport temperature -20 to 60 °C
Ambient humidity 20 to 80 %RH, non-condensing Installation category IEC 61010-1 Class I
Operator Function Map
Function Keys
64 user-definable function keys for process control and plant monitoring.
Window Calls
Special window-call keys grouped according to operating functions.
Control Keys
Dedicated control and operation confirmation areas support direct operator interaction.
Alarm Handling
Alarm acknowledgement and buzzer reset functions are directly available on the keyboard.
Fn + Page Keys
Volume control function		 Fn + Cursor Keys
Scroll function		 Fn + Clear Screen
Clear-screen function


SERIES / SYSTEM RELATIONSHIP
AIP830 and AIP831 in the Operation Keyboard Family
AIP830-111
Operation Keyboard for Single-loop Operation

Designed for single-loop operation on a Desktop Type HIS. The AIP830 family provides a dedicated operator keyboard with 64 user-definable function keys and dedicated process-operation controls.
 VS
AIP831
Operation Keyboard for Eight-loop Simultaneous Operation

A related operation keyboard in the same family, intended for eight-loop simultaneous operation rather than the single-loop role assigned to AIP830.
The CENTUM VP system documentation lists AIP830 and AIP831 as operation keyboard products. AIP830 is associated with single-loop operation, while AIP831 is associated with eight-loop simultaneous operation. This distinction is important when matching the keyboard to the intended operator workflow.
Why the “-111” Configuration Matters
-1
Mode selection switch
1
Operation confirmation key Type B
1
Fixed final code
AIP830
Single-loop keyboard family

AMIKON / GLOBAL INDUSTRIAL SUPPLY
01 — RAPID SOURCING
02 — HARD-TO-FIND PARTS
03 — GLOBAL DELIVERY


AMIKON INDUSTRIAL SUPPLY NETWORK
Sustainable Supply.
Faster Industrial Recovery.

At AMIKON, our mission is to promote a sustainable and efficient global industrial supply chain. With an inventory covering more than 1 million hard-to-find industrial parts, we help system integrators and suppliers reduce unexpected shortages and extended lead times. Long-term industrial asset partnerships across multiple industries enable AMIKON to support sourcing for new, obsolete and discontinued industrial parts, equipment and machinery.

1M+
Industrial Parts

 FAST
Delivery		 CARE
Customer Service		 GLOBAL
Supply Needs
PURCHASING SUPPORT
Need AIP830-111 for your next maintenance window?
Send the part number, quantity, destination, required date and machine/system details. Our sales team can check availability and arrange the appropriate delivery route for your requirement.
Delivery
3–5 days		 Warranty
12 months
Packaging
Brand New		 Payment
T/T
AMIKON LIMITED
Sales Manager: Miya Zheng
Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS
After-Sale Handling
01 / 7-Day Contact
Please contact us within 7 days after receiving the item if a question or issue arises.		 02 / Condition & Review
Returned items should remain in their original condition, with a specific reason supplied for the return.		 03 / Return or Replacement
After the returned item is received, a return or replacement can be arranged according to the case. Return shipping costs are the buyer's responsibility.
PURCHASING QUESTIONS
AIP830-111 Buyer FAQ
Q1. Can AIP830-111 be used when the Desktop Type HIS requires a single-loop operation keyboard rather than an eight-loop keyboard?
Yes. AIP830 is specifically designated for single-loop operation on a Desktop Type HIS. AIP831 is the related keyboard designated for eight-loop simultaneous operation, so the required operator workflow should be confirmed before ordering.
Q2. Does AIP830-111 actually include the hardware mode selection switch?
Yes. In the AIP830 suffix structure, “-1” specifies the version with the mode selection switch. Therefore the first “1” in AIP830-111 is significant when replacing a differently configured AIP830 unit.
Q3. Why should the Type B operation confirmation key be checked before replacing an AIP830-111?
The AIP830 family allows two operation confirmation key symbol configurations. The “1” configuration specifies Type B. When replacing an installed keyboard, matching the confirmation-key configuration helps maintain the intended operator interface rather than changing the physical control arrangement.
Q4. What should be checked if the replacement AIP830-111 is being connected to a Desktop Type HIS with limited USB connections?
AIP830 uses two USB A-type connections: one for the operation keyboard function and one for the sound function. Both connectors are intended to be connected directly to the computer, so available USB connections should be verified before installation.
Q5. Is the VESA mounting requirement relevant when purchasing an AIP830-111 replacement with a bracket?
Yes. The AIP830 can be supplied with a VESA bracket as an option. When the bracket is used, the mounting location must be capable of supporting at least 10 kg. The bracket version also increases the approximate keyboard weight from 2.0 kg to 2.5 kg.
