WOODWARD / 8446-1068 OVERVIEW FEATURES SPECS SERIES FAQ CONTACT PARTS




WOODWARD REMOTE PANEL / RELEASE 2
8446-1068
RP-3000XT Remote Operator Panel

A compact touch-screen remote control and annunciation panel for compatible Woodward XT family power-management controls. The RP-3000XT provides remote HMI access through Ethernet while keeping the main control hardware positioned where the system architecture requires it.
7"
WSVGA TFT LCD
1024 × 600
32
XT Controls
One device at a time
IP66
Front Sealing
Front-panel mounting

HARDWARE IDENTIFICATION
8446-1068
RP-3000XT hardware part number
Platform RP-3000XT
Touch P-CAP
Communication Ethernet
Power 24 Vdc ±20%
Operating Range -20 to 60 °C


01 / PRODUCT OVERVIEW
Remote HMI
Without Moving
the Main Control

KEY ARCHITECTURE
Front access / rear control
The RP-3000XT is particularly useful when compatible XT controls are mounted on a rear panel and operator interaction is required from the front.
Woodward 8446-1068 is the hardware part number for the RP-3000XT remote panel. The unit combines a color touch display, Ethernet communication and remote terminal control for compatible XT family power-management controls.
Full HMI capability
The RP-3000XT is designed to provide the HMI resources of compatible display variants through its touch interface, including the mirrored controller HMI and front-panel functions.
The panel can be configured for full mode, annunciator mode or deactivated. In networked installations, the MULTICAST screen presents compatible XT controls on the same Ethernet network, allowing the operator to select the device to access.
ETH Communication between the RP-3000XT and connected XT control is through Ethernet.
02 / FUNCTIONAL ADVANTAGES
Designed Around the Operator
The RP-3000XT combines a compact front-panel footprint with remote HMI access, making it suitable for switchgear builders, genset packagers and system integrators.
01
Remote Operator Control
Provides remote control, monitoring and visualization for compatible XT controls.
02
P-CAP Touch
Projected capacitive touch technology with 36 million-touch life under specified test conditions.
03
Multi-Cast Access
Can connect to a fleet of compatible XT controls and access one selected device at a time.
04
Compact Footprint
Front-panel dimensions support compact switchgear and control-door arrangements.
MODES Full Mode
Remote HMI resources available.		 Annunciator Mode
Focused annunciation operation.		 Off
Remote panel can be deactivated.
03 / TECHNICAL PARAMETERS
8446-1068 at a Glance
RP-3000XT / RELEASE 2
Front-panel remote HMI

Parameter 8446-1068 / RP-3000XT
Power supply 24 Vdc ±20%
Intrinsic consumption Typical 9 W
Operating temperature -20 to 60 °C (-4 to 140 °F)
Storage temperature -30 to 70 °C (-22 to 158 °F)
Ambient humidity 10 to 90% RH at 40 °C, non-condensing
Housing PC plus ABS with die-cast aluminum alloy front bezel
Dimensions W × H × D 205 × 146.9 × 46 mm
Front cutout W × H 192 × 138.5 mm
Weight Approx. 1.2 kg
Front sealing IP66 with clamp fastening
Power connection Screw/plug terminals, 2.5 mm²
Communication Ethernet
CPU 32-bit RISC processor, 600 MHz ARM Cortex
Backup memory FRAM 128 KB
Memory DDR3L 512 MB onboard
Storage 8 GB eMMC onboard
Operating system Linux
Display WSVGA TFT LCD, 177.8 mm (7")
Maximum resolution 1024 × 600
Maximum colors 16.7 million
Luminance 400 cd/m²
Viewing angle H/V 170° / 170°
Backlight LED, 50,000 h
Brightness Adjustable
Contrast ratio 800:1
Touch technology Projected capacitive (P-CAP)
Touch life 36 million touches under specified test conditions
Light transmission Above 85%
Vibration protection Operating random vibration, 2 Grms, 5–500 Hz
Listings CE, BSML, CCC, UL, FCC Class A

04 / APPLICATION FIT
Where 8446-1068 Makes Sense
01
Front-Door Operation
A practical arrangement when the main XT control is mounted behind the panel but operators require front-facing access.
02
Remote Location
Suitable when the remote panel is installed away from the genset room and Ethernet communication is used to reach the compatible XT controller.
03
Multi-Control Access
Useful for installations where one RP-3000XT needs to access a networked group of compatible XT controls one at a time.
PURCHASING CHECK
Before Replacement
 Part Number
Confirm 8446-1068.		 Controller
Confirm compatible XT control.		 Panel Cutout
192 × 138.5 mm.
05 / SAME PLATFORM
RP-3000XT Family Position
Release 2 remote-panel architecture
The 8446-1068 is the hardware P/N assigned to the RP-3000XT. For replacement planning, the most important distinction is between the older 8446-1061 Release 1 and the newer 8446-1068 Release 2 architecture.
CURRENT TARGET
8446-1068
RP-3000XT Release 2
Linux-based RP-3000XT platform. Multiple RP-3000XT panels and compatible easYgen controls can be connected through a common switch on ETH-A according to Woodward's current technical support guidance.
VS
EARLIER RELEASE
8446-1061
RP-3000XT Release 1
Older Windows-based Release 1 architecture. Woodward states that this version was limited to peer-to-peer connection through ETH-A, unlike the newer 8446-1068 Release 2 arrangement.
Compatibility direction: For a replacement order, do not select by screen appearance alone. Confirm the existing RP-3000XT part number, connected XT controller, Ethernet topology and physical panel opening.
SUPPORTED CONTROL FAMILY
easYgen-3000XT
Compatible genset-control family.
SUPPORTED CONTROL FAMILY
easYgen | LS-6XT
Compatible circuit-breaker control family.
NOT SUPPORTED
easYgen | GC-3000XT
Not supported by the RP-3000XT specification.
06 / DIRECT QUOTATION
Need
8446-1068?
Send the key purchasing details below so the correct part and delivery arrangement can be checked quickly.
PLEASE INCLUDE
Part Number Quantity Destination Required Date Machine/System
SALES MANAGER
Miya zheng
✉ EMAIL
sales@amikon.cn 		☎ PHONE / WHATSAPP
86-18020776792
Delivery
3–5 days		 Warranty
12 months
Packaging
Brand New		 Payment Term
T/T
Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS
07 / BUYER QUESTIONS
8446-1068 FAQ
Compatibility · Replacement · Purchase
Q1. Is Woodward 8446-1068 the appropriate remote panel for a rear-mounted XT controller?
It is specifically designed for remote operation of compatible XT family controls and is particularly useful with back-panel mounted easYgen-3100XT, easYgen-3400XT and LS-6XT arrangements. This allows operator control from the front while keeping the main control and high-voltage connections at the rear.
Q2. Can Woodward 8446-1068 be used with several XT controls instead of one dedicated panel per controller?
Yes. The RP-3000XT can connect to a fleet of compatible XT controls through its Ethernet network and lets the operator select one device at a time. The published specification states support for up to 32 XT controls.
Q3. What should be checked when replacing an installed Woodward 8446-1068?
Confirm the exact 8446-1068 part number, the connected XT controller family, Ethernet network arrangement, front-panel dimensions and the 192 × 138.5 mm cutout. For an existing RP-3000XT installation, these checks are more useful than selecting a replacement only by display size or appearance.
Q4. Does Woodward 8446-1068 provide the same operator resources as the compatible display variants?
The RP-3000XT is designed to provide the HMI resources of the compatible display variants through its touch interface. Its HOME screen mirrors the connected XT HMI and front-panel functions, making it useful when the operator needs remote interaction rather than a status-only panel.
Q5. What is the main difference a buyer should consider between 8446-1068 and older 8446-1061 units?
Woodward identifies 8446-1068 as the Release 2 RP-3000XT hardware, using the newer Linux-based architecture. Woodward's current support guidance states that Release 2 allows several RP-3000XT and easYgen units to share a common switch on ETH-A, whereas the older 8446-1061 Release 1 was limited to peer-to-peer connection through ETH-A. Therefore, network topology should be checked carefully when replacing an older unit.
