Woodward 5466-315 legacy MicroNet High Density Analog I/O Module

Woodward 5466-315
Woodward 5466-315
Woodward 5466-315

Woodward 5466-315 legacy MicroNet High Density Analog I/O Module

Calculate shipping
Quotation Request
✦ AMIKON AUTOMATION
WOODWARD
MICRONET

SYSTEM PART NUMBER
5466-315
❖ GLOBAL DCS / PLC
551,867 parts in stock • 128 brands • Fast dispatch
TECHNICAL SPECIFICATIONS & ARCHITECTURE MODEL PROFILE
DISCRETE INPUT
High-density 48-channel binary signal acquisition module.
ISOLATION
Optically isolated channels protecting control backplane from field noise.
FAST RESPONSE
Sub-millisecond status update speed for critical interlock detection.
Sales Manager
Miya zheng
✉ EMAIL US ☎ WHATSAPP




MICRONET / HIGH-DENSITY ANALOG I/O
WOODWARD INDUSTRIAL CONTROL
5466-315

Simplex High-Density Analog I/O for established Woodward MicroNet control architectures.
Woodward 5466-315 is a MicroNet High-Density Analog I/O module configured for 24 analog inputs and 8 analog outputs. The input channels are designed for 4–20 mA signals and the output channels provide 4–20 mA signals in a simplex arrangement.
SIMPLEX 24 AI 8 AO

MODULE PROFILE
AI CHANNELS 24
AO CHANNELS 8
INPUT RANGE 4–20 mA
OUTPUT RANGE 4–20 mA
FTM 5501-376 × 2
System role:
High-density analog interface for simplex MicroNet installations.
24
ANALOG INPUTS
4–20 mA current-loop inputs
8
ANALOG OUTPUTS
4–20 mA output channels
2
FIELD TERMINATION
5501-376 FTMs
1
CONFIGURATION
Simplex architecture
01 / ENGINEERING
Technical
Architecture

The 5466-315 concentrates 32 analog channels in a single high-density MicroNet I/O position. The combination of 24 current-loop inputs and 8 current-loop outputs is intended for simplex applications.
Engineering focus
Match the complete module number, FTM arrangement, field wiring, channel assignment and application configuration when planning a replacement.
TECHNICAL ITEM 5466-315
Manufacturer Woodward
System Family MicroNet
Module Type High-Density Analog I/O
Analog Inputs 24 × 4–20 mA
Analog Outputs 8 × 4–20 mA
System Configuration Simplex
Field Termination 5501-376 × 2
Signal Interface Current-loop analog I/O
Application Position Established MicroNet simplex control installations
DESIGN CHARACTERISTICS
High-density current-loop handling
With 24 analog inputs and 8 analog outputs, 5466-315 provides a concentrated analog interface for a simplex MicroNet installation. The architecture reduces the number of separate I/O module positions required for a large group of 4–20 mA process signals.
MAINTENANCE VIEW
Replacement is configuration-sensitive
A replacement should be checked against the installed chassis, module position, two 5501-376 FTMs, field wiring and application channel assignments rather than by mechanical appearance alone.
02 / FAMILY MAP
MicroNet High-Density Analog Family

TARGET MODULE
5466-315

Simplex
24 × 4–20 mA AI
8 × 4–20 mA AO
2 × 5501-376 FTM
5466-257 High-density analog configuration with 24 voltage inputs and 8 current outputs for TMR applications.
5466-315 24 × 4–20 mA inputs and 8 × 4–20 mA outputs for simplex use.
5466-425 High-density analog I/O using the Dataforth field-termination arrangement.
5466-5025 High-density analog I/O with selectable 4–20 mA or 0–5 V inputs and isolated I/O.
5466-5026 Simplex high-density analog I/O with 24 × 4–20 mA inputs and 8 × 4–20 mA outputs; channels 23/24 use a 5 ms anti-aliasing filter.
Selection point: The same MicroNet family contains variants with different input ranges, system architectures, field termination arrangements and filtering characteristics. The installed configuration should be matched before selecting an alternate family member.
03 / FIELD APPLICATION
Application & Replacement Scenarios

01

Existing 4–20 mA process loops
The module is appropriate where an installed MicroNet simplex application requires a concentrated interface for 4–20 mA analog signals. The 24 input channels allow a large number of process measurements to be handled through the high-density architecture.
02

Output-side maintenance
Eight 4–20 mA analog outputs provide the output side of the same module architecture. During troubleshooting, the maintenance team should compare channel assignments and field termination wiring before changing the module.
03

Suspected I/O module failure
If an installed 5466-315 is suspected of failure, compare the complete part number, module position, two 5501-376 FTMs, field connections and application channel assignment before ordering a spare. This helps distinguish a module problem from a field-loop or termination issue.
04

Evaluating 5466-5026 as a replacement
Woodward permits 5466-5026 to be used in place of 5466-315 when the application can accept the different anti-aliasing filter on analog input channels 23/24. The change is from 10 ms on 5466-315 to 5 ms on 5466-5026, so application engineering review is appropriate before substitution.
QUOTATION DESK
Request Woodward 5466-315
Provide the exact part number and application details so the requested configuration can be checked before shipment.
Part Number Quantity Destination Required Date Machine/System
DIRECT CONTACT
Miya zheng
Sales Manager
EMAIL   sales@amikon.cn PHONE / WHATSAPP   86-18020776792
Delivery: 3–5 days
Warranty: 12 months
Packaging: Brand New
Delivery way: E-packing / FedEx / EMS / TNT / DHL / UPS
Payment term: T/T
04 / PURCHASE QUESTIONS
5466-315 Buyer FAQ

01
Is Woodward 5466-315 the correct choice for a simplex MicroNet installation using 4–20 mA loops?
It is the documented simplex high-density analog configuration with 24 × 4–20 mA inputs and 8 × 4–20 mA outputs. The installed controller arrangement, field termination modules and channel requirements should still be matched before ordering.
02
Can Woodward 5466-5026 be purchased as a substitute for 5466-315?
Woodward identifies 5466-5026 as a possible replacement for 5466-315 in simplex applications when the application can accept its different filtering on analog input channels 23/24. Those channels use a 5 ms anti-aliasing filter on 5466-5026 compared with 10 ms on 5466-315, so it should not be treated as an unconditional drop-in substitution.
03
Does Woodward 5466-315 require specific field termination hardware?
Yes. The 5466-315 simplex high-density analog arrangement uses two 5501-376 field termination modules. The installed FTM numbers and field wiring should be checked before a replacement is ordered.
04
Why does the channel 23/24 filter matter when replacing Woodward 5466-315?
The filter difference can matter to an existing control application. Woodward states that 5466-5026 changes the anti-aliasing filter on analog input channels 23/24 from 10 ms on 5466-315 to 5 ms. If these channels participate in a control strategy where filtering characteristics matter, application review should be completed before substitution.
05
What should I send when requesting a Woodward 5466-315 quotation?
Please provide the Part Number, Quantity, Destination, Required Date and Machine/System. For a replacement project, the existing module label, hardware revision, two FTM numbers and channel requirements are also useful for configuration checking.
