VIBRO-METER VM600 MPC4 200-510-078-115 standard machinery protection card

VIBRO METER 200-510-078-115
VIBRO METER 200-510-078-115
VIBRO METER 200-510-078-115

VIBRO-METER VM600 MPC4 200-510-078-115 standard machinery protection card

Calculate shipping
Quotation Request
VIBRO-METER

MPC4
MACHINERY
PROTECTION
▂▅▇▅▂ ▂▅▇▅▂
VM600
SYSTEM CARD
VM600 MPC4 · LATER RoHS BUILD
200-510-078-115
04 DYNAMIC INPUTS Four programmable vibration measurement channels
02 SPEED INPUTS Two tachometer channels for speed and phase
50 Ω BUFFERED PATH Reduced output impedance · RoHS hardware

GLOBAL RESPONSE
↗ International Delivery on the Day
⚙ Quick Response Support
◎ Intercontinental Cooperation Network

Sales Manager
Miya Zheng
✉ sales@amikon.cn ◉ 86-18020776792
◈4 DYNAMIC · 2 SPEED◎
STANDARD MPC4 · RoHS · 50 Ω OUTPUT

200-510-078-115

VM600 MACHINERY PROTECTION

VIBRO-METER VM600 MPC4

VIBRO-METER VM600 MPC4 200-510-078-115 is a later-generation standard machinery protection card in the VM600 MPS platform. It combines four programmable dynamic inputs and two programmable speed inputs with DSP measurement, sensor supervision, configurable alarms and buffered raw-signal access. The matching IOC4T card completes field termination, analog outputs, discrete control inputs and relay interfaces.
Confirm VM600 MPC4 200-510-078-115 compatibility
Sales Manager: Miya Zheng · Send the full PNR, IOC card, rack details, quantity and destination.
EMAIL · sales@amikon.cnWHATSAPP · 86-18020776792
Version-specific purchasing point
Hardware generation 115 belongs to the later RoHS-compliant MPC4/IOC4T design and uses a 50 Ω buffered raw-signal output. It should be paired with a compatible later IOC4T such as the 114 generation or later applicable arrangement.

Verified Electrical and Measurement Profile

Dynamic inputs 4 individually programmable channels Speed inputs 2 tachometer channels
Voltage input, DC 0 to +20 V or 0 to -20 V Voltage input, AC ±10 V maximum
Current input, DC 0 to 25 mA Current input, AC ±8 mA maximum
Common-mode range -50 to +50 V Input impedance 200 kΩ
Analog input bandwidth DC to 60 kHz (-3 dB) Processed AC range 0.1 Hz to 10 kHz without integration
Integrated AC range 2.5 Hz to 10 kHz Current measuring resistor 324.5 Ω
PROTECTION ENGINEERING

Channel Processing, Alarms and Diagnostics

◆ Measurement engine
Parallel multichannel processing supports relative and absolute vibration, shaft position, eccentricity, expansion, displacement, speed and dynamic-pressure applications.		 ◎ Sensor flexibility
Dynamic channels accept voltage or current signals from supported Vibro-Meter sensor chains and other compatible conditioners. Integrated sensor supplies support applicable transducers.		 ◈ Tracking capability
The standard MPC4 supports narrow-band tracking, speed/phase inputs and speed-related measurements in addition to programmable broadband filtering.
◆ Protection decisions
Each channel can generate Alert and Danger states with adjustable delays, hysteresis and latching. IOC4T and rack buses route the resulting protection outputs.		 ◎ Low-impedance raw output
The 115 hardware generation uses a 50 Ω buffered-output circuit, supporting robust signal sharing to external analysis equipment when loading rules are respected.		 ◈ Online service
The card performs power-up checks and continuous signal-path supervision. VM600 design supports controlled card insertion and removal under the approved site procedure.
VM600 SIGNAL PATH

MPC4 / IOC4T System Relationship

Four dynamic + two speed
Six programmable measurement paths		 MPC4 078-115
DSP processing, alarms, OK supervision and BNC outputs		 IOC4T later generation
50 Ω raw path, DSI inputs, analog outputs and relays		 RLC16 / IRC4
Optional expansion for additional alarm relay outputs

Amikon industrial service

 Amikon industrial service

Amikon's large stock is the core of our supply.
More than 400,000 electronic products across PLC, HMI, drives, servo, CNC, IPC and PG categories.
 Amikon industrial service

Current and long-unavailable industrial products are coordinated through strategic purchasing. A preferred supplier network supports urgent searches when an item is temporarily unavailable. Worldwide service, multilingual support and order tracking help reduce production interruption.
Contact Miya Zheng for VM600 MPC4 200-510-078-115
Sales Manager: Miya Zheng · Send the full PNR, IOC card, rack details, quantity and destination.
EMAIL · sales@amikon.cnWHATSAPP · 86-18020776792
Prompt contact
Notify us within seven days after receipt if an issue is found.		 Original condition
Keep the unit unchanged and provide the specific return reason.		 Return freight
Shipping costs arising from the return are borne by the buyer.
PURCHASING QUESTIONS

VM600 MPC4 200-510-078-115 FAQ

01 Is VM600 MPC4 200-510-078-115 a standard or SIL-version card?
Its x-position denotes the standard MPC4 version. It is not the MPC4SIL x=3 version.
02 Which IOC4T should be matched with VM600 MPC4 200-510-078-115?
Use a compatible later-generation IOC4T with the 50 Ω buffered-output design, then confirm the complete rack configuration and installed software.
03 Can VM600 MPC4 200-510-078-115 replace a 113-generation card without engineering checks?
No. Buffered-output impedance, paired IOC4T hardware, loading, embedded program compatibility and rack configuration must all be reviewed.
04 What should a buyer provide for VM600 MPC4 200-510-078-115 matching?
Provide clear front and side label images, IOC4T code, rack type, software release, channel application, required condition and quantity.
05 How should VM600 MPC4 200-510-078-115 be commissioned after replacement?
Restore the approved setup, verify every sensor and speed channel, test Alert/Danger logic, prove relay paths and compare displayed values with expected machine behavior.
