VIBRO-METER VM600 MPC4 200-510-041-021 standard machinery protection card

VIBRO METER200-510-041-021
VIBRO METER200-510-041-021
VIBRO METER200-510-041-021

VIBRO-METER VM600 MPC4 200-510-041-021 standard machinery protection card

Calculate shipping
Quotation Request
VIBRO-METER

MPC4
MACHINERY
PROTECTION
▁▃▆▃▁ ▂▇▂
VM600
SYSTEM CARD
VM600 MPC4 · LEGACY COMPLETE PNR
200-510-041-021
Real-time vibration and speed supervision with programmable Alert, Danger and measurement-chain OK thresholds.
4+2 CHANNEL FORMAT Up to four dynamic and two speed channels
10 kHz VIBRATION BAND Processing range from 0.1 Hz to 10 kHz
PNR PAIRING CHECK Match the complete number and companion IOC4T

GLOBAL RESPONSE
↗ International Delivery on the Day
⚙ Quick Response Support
◎ Intercontinental Cooperation Network

Sales Manager
Miya Zheng
✉ sales@amikon.cn ◉ 86-18020776792
◈4 DYNAMIC · 2 SPEED◎
LEGACY MPC4 · EXACT-MATCH PRIORITY

VIBRO-METER VM600 MPC4 200-510-041-021

LEGACY
EXACT MATCH		 VIBRO-METER VM600 MPC4 200-510-041-021 is a legacy machinery protection card used in earlier VM600 installations. It belongs to the MPC4 measurement family and provides continuous machinery protection through programmable dynamic and speed channels. Because this older PNR does not follow the later xHh version pattern in the same way, replacement planning must begin with the exact card, paired IOC hardware and active rack setup.
Confirm VM600 MPC4 200-510-041-021 compatibility
Sales Manager: Miya Zheng · Send the full PNR, IOC card, rack details, quantity and destination.
EMAIL · sales@amikon.cnWHATSAPP · 86-18020776792
Version-specific purchasing point
Treat 200-510-041-021 as an exact-match legacy assembly. Do not infer standard, separate-circuit or SIL behavior only from the later version-decoding rule. Confirm the existing front panel, IOC pairing, software generation, relay routing and channel application before substitution.

Verified Electrical and Measurement Profile

Dynamic inputs 4 individually programmable channels Speed inputs 2 tachometer channels
Voltage input, DC 0 to +20 V or 0 to -20 V Voltage input, AC ±10 V maximum
Current input, DC 0 to 25 mA Current input, AC ±8 mA maximum
Common-mode range -50 to +50 V Input impedance 200 kΩ
Analog input bandwidth DC to 60 kHz (-3 dB) Processed AC range 0.1 Hz to 10 kHz without integration
Integrated AC range 2.5 Hz to 10 kHz Current measuring resistor 324.5 Ω
PROTECTION ENGINEERING

Channel Processing, Alarms and Diagnostics

◆ Legacy system continuity
The card supports the established VM600 protection path for vibration and speed measurements. Maintaining the existing machine-protection behavior is more important than choosing a visually similar card.		 ◎ Channel engineering
Four dynamic inputs and two speed inputs are individually configured. The setup defines sensor type, sensitivity, bias or gap, measurement processing, scaling and alarm response.		 ◈ Signal processing
MPC4 processing supports programmable filtering, integration and monitoring functions used for shaft, bearing, casing, expansion and speed-related protection.
◆ IOC dependency
Field wiring, discrete control inputs, analog outputs and relay functions are completed by the paired rear card. The exact IOC code and hardware generation must be captured.		 ◎ Configuration recovery
Before exchange, record channel setup, relay logic, bypass and trip-multiply behavior, rack position and software compatibility. A blank spare cannot reproduce protection behavior on its own.		 ◈ Acceptance testing
After installation, validate sensor health, raw signals, processed values, speed response, Alert/Danger timing, latching, relay actuation and the system safety line.
VM600 SIGNAL PATH

MPC4 / IOC4T System Relationship

Installed sensor chains
Machine vibration, position and speed inputs		 MPC4 041-021
Legacy measurement and protection processing		 Paired rear I/O card
Field wiring, outputs, DSI and relay interface		 Rack controller / relay cards
Configuration access and expanded protection outputs

Amikon industrial service

 Amikon industrial service

Amikon's large stock is the core of our supply.
More than 400,000 electronic products across PLC, HMI, drives, servo, CNC, IPC and PG categories.
 Amikon industrial service

Current and long-unavailable industrial products are coordinated through strategic purchasing. A preferred supplier network supports urgent searches when an item is temporarily unavailable. Worldwide service, multilingual support and order tracking help reduce production interruption.
Contact Miya Zheng for VM600 MPC4 200-510-041-021
Sales Manager: Miya Zheng · Send the full PNR, IOC card, rack details, quantity and destination.
EMAIL · sales@amikon.cnWHATSAPP · 86-18020776792
Prompt contact
Notify us within seven days after receipt if an issue is found.		 Original condition
Keep the unit unchanged and provide the specific return reason.		 Return freight
Shipping costs arising from the return are borne by the buyer.
PURCHASING QUESTIONS

VM600 MPC4 200-510-041-021 FAQ

01 Can VM600 MPC4 200-510-041-021 be replaced using only the MPC4 family name?
No. This legacy PNR requires exact comparison of the front card, rear I/O card, rack, channel setup and software generation.
02 Does the later MPC4 version-decoding rule fully describe VM600 MPC4 200-510-041-021?
No. Do not classify this legacy PNR solely by the later xHh convention. Confirm the actual installed assembly.
03 What should be captured before removing VM600 MPC4 200-510-041-021?
Capture every label, rack slot, paired rear-card code, sensor connection, channel setup, alarm threshold, delay, latch, DSI state and relay route.
04 Why might VM600 MPC4 200-510-041-021 show different readings after exchange?
Possible causes include sensitivity, scaling, integration mode, filter settings, bias or gap, wiring polarity and unmatched rear-card hardware.
05 What proves VM600 MPC4 200-510-041-021 is ready for service?
A controlled test must confirm sensor supervision, measurement accuracy, speed and phase behavior, Alert/Danger timing, relay action and communication with the rack environment.
