SIMATIC S7-1500 / MOUNTING SYSTEM
6ES7590-1AF30-0AA0
530 mm Mounting Rail · Integrated DIN Rail
The Siemens SIMATIC S7-1500 6ES7590-1AF30-0AA0 is a 530 mm mounting rail designed for S7-1500 installation arrangements. The rail incorporates a grounding screw and an integrated DIN rail section for mounting smaller cabinet components such as terminals, circuit breakers and relays. Its aluminum construction and defined mounting geometry make it suitable for structured control-cabinet assembly.
530 mm LENGTH ALUMINUM S7-1500
|
ENGINEERING IDENTIFICATION
S7 / 1500 / RAIL
|
|
530 mm
Mounting rail profile
DIN
RAIL ALUMINUM STRUCTURE
|
Mounting Geometry
The 530 mm rail provides the physical mounting base for compatible SIMATIC S7-1500 components. Siemens also specifies a 500 mm centric bore-hole distance for this rail configuration.
|
|
STRUCTURE
Aluminum rail
|
BORE-HOLE DISTANCE
500 mm centric
|
GROUNDING
Grounding screw included
|
INTEGRATED SECTION
DIN rail
|
|
Built Around Cabinet Installation
6ES7590-1AF30-0AA0 is a SIMATIC S7-1500 mounting rail with a 530 mm length. The rail is intended for installation within control cabinets and provides the mechanical base for compatible S7-1500 components. The rail incorporates a grounding screw and an integrated DIN rail section. The additional DIN rail area is intended for smaller cabinet components such as terminals, automatic circuit breakers and relays, allowing the mounting structure to serve more than the S7-1500 module assembly alone. Siemens specifies aluminum as the rail material. The defined 530 mm length and 500 mm centric bore-hole distance provide a predictable mechanical arrangement for cabinet planning. |
|
||||||||||||||
|
245 mm class
A shorter S7-1500 rail option for compact cabinet arrangements.
|
530 mm class
6ES7590-1AF30-0AA0 provides the 530 mm mounting length used for this configuration.
|
830 mm class
A longer rail option for larger cabinet arrangements.
|
Selection principle
Rail selection should follow the required module arrangement and available cabinet space.
|
|
REQUEST SUPPORT
6ES7590-1AF30-0AA0
Send the exact part number and your installation requirements for a faster quotation.
|
|
||||
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
DELIVERY WAY
E-packing / FedEx / EMS / TNT / DHL / UPS
|
|
Make Your Inquiry Precise
Include the following details when requesting a quotation for 6ES7590-1AF30-0AA0. This helps match the rail to the intended cabinet arrangement.
|
|
||||||||||||
|
01 · Is 6ES7590-1AF30-0AA0 suitable when the existing S7-1500 rail is 530 mm long?
The model is specifically the 530 mm SIMATIC S7-1500 mounting rail. When replacing an existing rail, confirm the mounting arrangement and cabinet space rather than relying only on the series name.
|
02 · Can 6ES7590-1AF30-0AA0 also support cabinet accessories?
Yes. The rail includes an integrated DIN rail intended for mounting smaller components such as terminals, automatic circuit breakers and relays. The cabinet arrangement should still be checked for available space.
|
|
03 · What should be checked before replacing 6ES7590-1AF30-0AA0 with another S7-1500 rail?
Check the rail length, cabinet space, mounting-hole arrangement and grounding requirements. A different rail length may change the available mounting area even when it belongs to the same S7-1500 family.
|
04 · Does 6ES7590-1AF30-0AA0 include a grounding provision?
Yes. The product description specifies a grounding screw. Proper grounding connection should use the appropriate grounding terminals and follow the installation requirements of the control cabinet.
|
|
05 · Is the 6ES7590-1AF30-0AA0 material relevant when matching an existing rail?
Yes. Siemens specifies aluminum for this mounting rail. For a replacement check, compare the complete mechanical arrangement rather than matching only the nominal length.
|
|
|
