SCHNEIDER ATV610D45N4 frequency inverter

Parameters

&Drive Type: Easy Altivar 610 wall-mount VSD, IP20

&Input: 380…460 V ±10 %, 50/60 Hz, 3-phase

&Normal-duty motor: 45 kW (60 hp) / 88 A cont.

&Heavy-duty motor: 37 kW (50 hp) / 75 A cont.

&Max transient: 97 A (60 s ND) / 112 A (60 s HD)

&Switching freq: 2…12 kHz (default 4 kHz)

&Built-in EMC filter C3 (50 m) & STO (SIL3/PLe)

&Dimensions: 300 × 715 × 280 mm, weight ≈ 30 kg

Applications

&Centrifugal pumps & irrigation systems—keeps flow exactly on the set-point and saves 15-30 % energy.

&HVAC supply & return fans—soft start, quiet running, easy BACnet hook-up.

&Conveyors & mixers in food plants—tight torque control, wash-down safe IP20 cabinet mount.
