SCHNEIDER ATV610D30N4 frequency inverter

Parameters

&Drive Type: Easy Altivar 610, IP20 wall-mount

&Input: 380…460 V –15 % / +10 %, 50/60 Hz, 3-phase

&Motor Power: 30 kW (40 hp) ND / 22 kW (30 hp) HD

&Rated Output Current: 61.5 A ND – 46.3 A HD @ 4 kHz

&Max Transient: 110 % 60 s (67.7 A ND / 69.5 A HD)

&Switching Freq: 2…12 kHz (default 4 kHz)

&Built-ins: STO (SIL3/PLe), C3 EMC filter, DC choke, Modbus-RTU

&Size / Weight: 300 × 715 × 280 mm, ≈ 23 kg, forced-air cooled

Applications

&HVAC chilled-water pumps & cooling-tower fans—automatic PID keeps constant pressure and saves up to 50 % energy.

&Wastewater submersible pumps—multi-pump macro alternates duty, prevents water-hammer and cuts maintenance.

&Compressors & belt conveyors in food plants—smooth start, quiet running, simple plug-and-play I/O.

Call Miya, get the best price

( Whatsapp：+86-18020776792

* E-mail：sales@amikon.cn  

Our service

& Professional support, complete parts supply

& Trusted service with full component coverage

&Comprehensive support, every part you need

&Quality:original and brand new

&Payment Term: T/T Wire Transfer

&Warranty: 12 Months Warranty

&Shipment : Worldwide Fast Shipment

Our specialty is stocking parts that have been discontinued by manufacturers.

One of our top priorities is comprehensive, professional and timely customer service.

We are constantly improving our service quality and the quality of our employees. We treat every order with 110% commitment.
