MTL / EATON MTL8810-HI-TX 8-Channel 4–20 mA Analog Input Module with HART

MTL / EATON MTL8810-HI-TX
MTL / EATON MTL8810-HI-TX
MTL / EATON MTL8810-HI-TX

MTL / EATON MTL8810-HI-TX 8-Channel 4–20 mA Analog Input Module with HART

Calculate shipping
Quotation Request
EATON / MTL
SAFETYNET
8810-HI-TX

Safety Analog Input
4–20 mA · HART
SAFETYNET I/O
01
01
CHANNELS
8
Single-ended inputs

ANALOG INPUT
02
02
SIGNAL
4–20 mA
HART supported

CURRENT INPUT
03
03
RESOLUTION
16 bit
Input data resolution

SAFETY I/O
AMIKON
CONTACT

SALES MANAGER
Miya zheng
EMAIL WHATSAPP
SAFETY ANALOG INPUT We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world. INQUIRE NOW ↗
MTL


MTL
8810
SAFETYNET ANALOG INPUT
MTL / EATON 8810-HI-TX
8-Channel 4–20 mA Analog Input Module with HART

A SafetyNet analog input module designed for 2-wire, 3-wire and 4-wire transmitters, combining analog acquisition, configurable signal processing, HART handling and diagnostic functions.
MODULE
A1

42 mm
module width
TECHNICAL CORE
Eight Channels. One Structured Signal Layer.

Input architecture 8 single-ended analog input channels
Nominal signal 4–20 mA
Full input range 0.25–24 mA
Transmitter types 2-wire / 3-wire / 4-wire
Resolution 16 bit
Accuracy ±0.1% of span at 25°C
Repeatability 0.05% of span
Temperature coefficient 38 ppm/°C
◈
Signal Processing
The module converts the analog input into a 16-bit digital value for communication over the Railbus. In 4–20 mA operation, current values are acquired at a maximum signal-change-to-Railbus availability of 25 ms.
Data
16-bit unsigned
HART
IEEE 754 floating point
Output voltage
10.2 V minimum at 20 mA
Maximum current
28 mA
01 / FIELD
Transmitter Interface
The 8810-HI-TX supports active analog signals from 2-wire, 3-wire and 4-wire transmitters. The specified full signal range extends beyond the nominal 4–20 mA operating range.
SIGNAL PATH
01
FIELD
02
CONVERT
03
RAILBUS
The architecture separates field signal acquisition from controller communication while maintaining channel-level diagnostics.
02 / DIGITAL
HART Handling
HART data retrieved through the module is treated as non-interfering with the required safety function. HART command 3 can provide device status and process-variable data.
DIAGNOSTIC MATRIX
Four-Level Alarm Logic
The 8810-HI-TX provides high-high, high, low and low-low alarm levels. Alarm dead band can be configured to prevent small signal fluctuations from repeatedly changing alarm status.
HH High-high
H High
L Low
LL Low-low
Measurement Verification
A second measurement path with different internal circuitry checks the primary measurement. A channel is flagged when the diagnostic comparison exceeds the specified 2% threshold or when the primary measurement differs from an internal reference by more than 2%.
A failed channel is flagged as faulty and made inactive. Other channels continue operating. Reset or power cycling can reactivate the affected channel.
The specified SafetyNet diagnostic test interval is no more than 5 seconds.
SAFETYNET ARCHITECTURE
1oo1D Architecture for SIL 2 Applications
The 8810-HI-TX is specified as an 8-channel SafetyNet analog input module using a 1oo1D architecture for SIL 2 safety applications. Internal diagnostic functions continuously monitor the analog acquisition path.
The configurable failsafe timeout is specified from 400 ms to 5 seconds. If communication with the master SafetyNet Controller does not occur within the configured period, the module enters controlled shutdown.
Intrinsic Safety Integration
For intrinsically safe field connections, an external galvanic isolator meeting the required hazardous-area and functional-safety requirements is specified.
IS zener barriers are normally unsuitable for 8810 modules because their leakage characteristics can affect measurement error or earth-leakage behavior.
POWER ARCHITECTURE
Field Power & Module Interface
24 VDC
BUSSED FIELD POWER
Specified for the field transmitter supply arrangement.
70 mA
MAX SYSTEM CURRENT
Maximum specified system power supply current.
350 mA
2-WIRE TX
Specified maximum bussed field power for 2-wire transmitters.
110 mA
4-WIRE TX
Specified maximum bussed field power for 4-wire transmitters.
42
mm width
Physical Interface
Module key A1
Width 42 mm
Weight 200 g
Railbus isolation 250 VAC RMS
Channel isolation No channel-to-channel isolation
SAFETYNET FAMILY
Same-Series System Components
8811-IO-DC
An 8-channel SafetyNet digital I/O module supporting digital input and output configurations.
8851-LC-MT
A SafetyNet Controller used for execution of the safety application and controller-level diagnostics.
8751-CA-NS
SafetyNet Controller carrier incorporating earth-leakage fault detection capability.
8914-PSAC
Specified as the 24 VDC bussed field-power source associated with the 8810-HI-TX arrangement.
AMIKON / GLOBAL SALES
DIRECT INQUIRY
Source Your MTL / EATON 8810-HI-TX
Send the part number, quantity, destination, required date and machine/system details. Our sales team can assist with product matching, availability and order coordination.
Miya Zheng
Sales Manager
EMAIL SALES CALL SALES WHATSAPP
sales@amikon.cn   |   +86 180 2077 6792
PURCHASING / APPLICATION FAQ
MTL / EATON 8810-HI-TX Questions
Can MTL / EATON 8810-HI-TX support different transmitter wiring arrangements?
Yes. The 8810-HI-TX is specified for 2-wire, 3-wire and 4-wire transmitters. This makes the wiring configuration an important point to verify when replacing an existing analog input position.
Is HART communication on MTL / EATON 8810-HI-TX suitable for the safety signal?
HART data retrieved through the module is treated as non-interfering with the required safety function. HART command 3 can provide status and process-variable data, but the HART data path is not the safety signal path.
What field-isolation arrangement should be checked for MTL / EATON 8810-HI-TX in an intrinsically safe application?
An external galvanic isolator meeting the required hazardous-area and functional-safety requirements is specified for intrinsically safe field connections. The specified arrangement should therefore be checked before selecting the interface hardware.
What happens to the other channels if one MTL / EATON 8810-HI-TX input fails diagnostics?
The failed channel is flagged and made inactive, while the other channels continue operating. The affected channel can be reactivated following a reset command or power cycle.
How should the MTL / EATON 8810-HI-TX failsafe timeout be considered during replacement?
The module provides a configurable failsafe timeout from 400 ms to 5 seconds. If communication with the master SafetyNet Controller is not received within the configured period, the module enters controlled shutdown. The selected value therefore needs to match the response requirements of the complete SafetyNet application.
