MOTOROLA COMPUTER GROUP
MVME2304

POWERPC VME PROCESSOR
6U · ECC · PMC EXPANSION
PowerPC VME Computing with ECC Memory and PMC Expansion
01
PROCESSOR
MPC603
200 MHz PowerPC


02
MEMORY
ECC DRAM
128 MB


03
EXPANSION
PMC
2 × PMC slots



We have a wide range of brands and products for various industries, we provide services to tens of thousands of customers around the world.



INDUSTRIAL AUTOMATION
LET'S
CONNECT


✉   Miya zheng · SALES EMAIL   sales@amikon.cn ☎   86-18020776792






MOTOROLA COMPUTER GROUP / VME PROCESSOR MODULE
MVME2304
PowerPC VME Processor Module
200 MHz MPC603 • 128MB ECC DRAM • Dual PMC Expansion
CPU
MPC603
200 MHz
MEMORY
128MB
ECC DRAM
EXPANSION
2 × PMC
32/64-bit
FORM
6U
VMEbus

SYSTEM CORE
Embedded VME Computing

PCI local-bus architecture connects processor resources with Ethernet, VMEbus and PMC expansion.
ECC MEMORY CONTROL
Two-way interleaving with error correction support.

ARCHITECTURE / EXPANSION / I/O
A Single VME Slot Built Around Expansion
01 / PROCESSING
PowerPC 603
32-bit MPC603 at 200 MHz with on-chip instruction and data cache.
→
02 / MEMORY
128MB ECC DRAM
ECC-protected DRAM is controlled through the Falcon memory architecture.
→
03 / PCI DOMAIN
Two PMC Slots
IEEE P1386.1-compatible 32/64-bit PMC expansion with front-panel and P2 I/O capability.
→
04 / VME SYSTEM
VMEbus Interface
P1 and P2 connectors provide the board interface to the VMEbus backplane.

TECHNICAL PROFILE
MVME2304 at a Glance
Processor MPC603 PowerPC, 200 MHz
DRAM 128MB ECC-protected memory
Flash 5MB total Flash capability in the MVME2304 configuration
PMC Two 32/64-bit PMC expansion slots
Form Factor 6U VMEbus single-board module
NETWORK
10/100Mb/s Ethernet
Ethernet transceiver interface with auto-negotiated speed selection.
DEBUG
Asynchronous Serial
Dedicated asynchronous serial debug interface for board-level access.
NONVOLATILE
8KB NVRAM / RTC
NVRAM with time-of-day clock and replaceable battery backup.
TIMING / CONTROL
Timers + Watchdog
Four 32-bit timers, one 16-bit timer and one watchdog timer.

WHY THE MVME2304 ARCHITECTURE MATTERS
Processing, memory and expansion are arranged around the VME system bus.
VMEbus Integration
The MVME2304 communicates with the VMEbus through its P1 and P2 interfaces, making it suitable as a processor module in a VME-based system.
PMC Expansion
Two PMC positions provide a modular path for adding PCI-based functions while retaining the main VME processor architecture.
ECC Memory
The 128MB memory configuration uses ECC protection for improved memory error handling at the board architecture level.
Embedded Diagnostics
PPCBug firmware provides power-up initialization, diagnostic functions and an interactive PowerPC debugging environment.

PURCHASE SUPPORT
Need MVME2304 for Your VME System?
Send the complete part number and application details for a faster quotation.
EMAIL
sales@amikon.cn 		PHONE / WHATSAPP
86-18020776792 		SALES MANAGER
Miya zheng
DELIVERY
3–5 Days
WARRANTY
12 Months
PACKAGING
Brand New
DELIVERY WAY
E-packing / FedEx / EMS / TNT / DHL / UPS
PAYMENT
T/T
FOR QUOTATION
Please provide Part Number, Quantity, Destination, Required Date and Machine/System.

PURCHASE & CONFIGURATION QUESTIONS
MVME2304 FAQ
Can MVME2304 be matched by memory capacity alone?
No. The base MVME2304 configuration is specifically associated with the 200 MHz MPC603 and 128MB ECC DRAM. When replacing an installed board, the processor generation, exact model designation and front-panel configuration should be checked together rather than using memory capacity as the only matching criterion.
What should be checked before replacing an MVME2304 in a VME chassis?
The VMEbus slot arrangement, P1/P2 backplane connections, PMC requirements, front-panel I/O and installed firmware or system configuration should be reviewed. The MVME2304 occupies a 6U VMEbus position and its PMC architecture can affect the overall mechanical and I/O arrangement.
Does MVME2304 support PMC-based expansion?
Yes. MVME2304 provides two IEEE P1386.1-compatible PMC expansion positions supporting 32/64-bit PMC operation. The architecture also supports the PMCspan expansion approach described for the MVME2300 family.
How does MVME2304 handle memory reliability in an existing control system?
The 128MB DRAM configuration is ECC-protected. The Falcon memory controller architecture provides error-correction capability, making the ECC design an important part of the board's memory subsystem when evaluating a replacement.
Is MVME2304 interchangeable with every MVME2300-series board?
Not automatically. The MVME2300 family contains different processor and memory configurations. MVME2301–MVME2304 use the MPC603 family at 200 MHz, while MVME2305–MVME2308 use MPC604 configurations. Exact model and board variant should therefore be matched before replacement.
