MOTOROLA / VME COMPUTING
6U VME Processor Module
PowerPC architecture PMC expansion platform |
INDUSTRIAL COMPUTING PLATFORM
MVME2305
300 MHz MPC604 PowerPC · 16MB ECC DRAM
A 6U VME processor module combining PowerPC processing, PCI local-bus architecture, VMEbus connectivity and dual PMC expansion.
|
MODEL
MVME2305
|
|
PowerPC Processing Core
MVME2305 belongs to the MVME2300 VME processor family and uses the MPC604 PowerPC processor at 300 MHz. Its processor and memory architecture are designed around the board's embedded VME computing role.
MEMORY PATH
16MB ECC DRAM
The MVME2305 configuration provides two-way interleaved, ECC-protected DRAM. The 16MB capacity distinguishes this model from the higher-memory members of the same family.
BOARD ROLE
6U VMEbus processor module with PCI-based PMC expansion
|
◇
CORE CONFIGURATION
|
|
◈
300 MHz
MPC604 PowerPC
|
▣
16MB ECC
Protected DRAM
|
◇
2 PMC
IEEE P1386.1 interface
|
◎
10/100Base-T
Front-panel Ethernet
|
|
VMEbus Connectivity
The processor module connects to the VMEbus through its P1 and P2 connectors. The architecture supports VMEbus access together with PCI local-bus resources, making the board suitable for embedded computing systems built around a VME backplane. |
PMC Expansion
Two onboard PMC positions provide a modular PCI mezzanine architecture. PMC I/O can be routed through the front panel and/or P2 depending on the installed PMC design and system configuration. |
|
INTERFACES
Connectivity at the Front
MVME2305 provides front-panel access for Ethernet and debug communication, while VMEbus and PMC resources extend through the board and backplane architecture. |
|
|
16MB
ECC DRAM
Two-way interleaved ECC-protected main memory. |
Flash
Boot / Program Storage
Flash banks are part of the MVME2300 board architecture. |
8KB
NVRAM
Battery-backed nonvolatile memory with RTC. |
4 + 1
Timer Resources
Four 32-bit timers plus a 16-bit timer, with watchdog support. |
| Model | Motorola MVME2305 | Processor | MPC604 PowerPC, 300 MHz |
| Form Factor | 6U VMEbus | Main Memory | 16MB ECC DRAM |
| PMC | Two IEEE P1386.1-compatible positions | Ethernet | 10Base-T / 100Base-TX |
| Debug Interface | Asynchronous EIA-232-D | NVRAM | 8KB with RTC and battery backup |
| VME Interface | P1 / P2 VMEbus connections | Firmware | PPCBug |
|
MVME2300 Series
The MVME2300 family uses a common 6U VME processor architecture with MPC603- or MPC604-based configurations, ECC DRAM, PCI/PMC expansion, Ethernet and serial interfaces.
|
|
|
01
Processor / Memory Match
Confirm that the required 300 MHz MPC604 and 16MB ECC configuration matches the existing board. |
02
PMC / I/O Arrangement
Check installed PMC devices and whether their I/O is routed through the front panel or P2 connection. |
03
Backplane Environment
Confirm the VME chassis, P1/P2 backplane connections and any PMCspan expansion requirements. |
