C200
CONTROLLER PAIR
|
|
SERIES E · DUAL MEDIA CNI
TC-CCR014
CONTROLNET INTERFACE
|
|
I/O
NETWORK LOAD
|
| MEDIA A | ACTIVE PATH | |
| MEDIA B | RESERVE PATH |
| DUAL MEDIA Redundant ControlNet paths |
SERIES E CCR014 generation |
MATCHED PAIR Same partner CNI type |
| 01 | Product type | Series E dual-media ControlNet Interface |
| 02 | Network role | ControlNet communication interface for redundant media |
| 03 | Controller relationship | Supports redundant controller configurations |
| 04 | Fieldbus relationship | Required for optional Fieldbus communication support |
| 05 | Generation | Supersedes TC-CCR013, TC-CCR012 and TC-CCR011 |
| 06 | Coated counterpart | TK-CCR014 |
| 07 | Single-media counterpart | TC-CCN014 |
| 08 | Partner rule | Both CNI modules in a redundant chassis pair must be the same type |
| 09 | Migration rule | An older CNI partner must be replaced in coordination with the CCR014 transition |
| 10 | Backplane demand | Approximately 970 mA at 5.1 V DC and 1.7 mA at 24 V DC |
| 11 | Installation state | Remove chassis power and control electrostatic discharge before handling |
| 12 | Commissioning focus | Verify both media paths, controller communication and partner synchronization |
| Replacing one member of a redundant pair? | ASK MIYA TO CHECK THE PAIR |
| TC-CCR014 | Series E · dual ControlNet media | Selected interface |
| TK-CCR014 | Series E · dual media · coated | Environmental counterpart |
| TC-CCN014 | Series E · single media | Non-redundant cable option |
| CCR013 / 012 / 011 | Earlier CNI generations | Superseded by CCR014 |
Both partner modules in a redundant chassis pair must be the same type. Cable redundancy, coating and installed generation must be considered together.
| EMAIL · SALES@AMIKON.CN | WHATSAPP · 86-18020776792 | SALES MANAGER · MIYA ZHENG |
| Contact us within seven days if a concern appears after receipt. | Keep the item in its original condition and state the reason. Resolution follows receipt and inspection. | Return-related shipping charges are paid by the buyer. |
| 01 |
TC-CCR014 —Can TC-CCR014 be paired with TC-CCR013 in a redundant chassis pair?
No. Both partner modules in the redundant chassis pair must be the same type. Coordinated replacement prevents an unsupported mixed-generation pair.
|
| 02 |
TC-CCR014 —What is the difference between TC-CCR014 and TC-CCN014?
TC-CCR014 is the dual-media option for redundant ControlNet cable paths. TC-CCN014 is the single-media interface.
|
| 03 |
TC-CCR014 —When should TK-CCR014 be selected instead of TC-CCR014?
TK-CCR014 is the coated counterpart. Select it only when the installed hardware and environmental requirement call for the coated version.
|
| 04 |
TC-CCR014 —What should be confirmed before purchasing TC-CCR014?
Check both partner CNI models, chassis positions, ControlNet media arrangement, controller redundancy, coating requirement and installed system release.
|
| 05 |
TC-CCR014 —Which checks should follow TC-CCR014 installation?
Verify module status, both cable paths, partner synchronization, controller communication, optional Fieldbus traffic and recovery after a single-media interruption.
|
