HONEYWELL • EXPERION • SERIES C
CC-PPIX01
Pulse Input Module
A Series C pulse-input module for the Experion C300 controller, designed to process pulse-generating field signals and provide calculated rate, accumulated total, frequency, period and pulse-width values. The architecture also supports dual-pulse measurement for custody-transfer applications and fast-cutoff functions.
|
ENGINEERED FOR PULSE MEASUREMENT
High-impedance differential voltage input, optical isolation, configurable edge selection and dedicated fast-cutoff capability on channels 7 and 8.
|
|
01 / SIGNAL ARCHITECTURE
Differential Pulse Acquisition
High-impedance differential voltage inputs with optical isolation rated at 1000 VDC.
|
02 / MEASUREMENT
Frequency + Pulse Analytics
Frequency, period, pulse width, process value and accumulated value can be handled by the pulse-input function.
|
03 / CONTROL RESPONSE
Fast Cutoff
Channels 7 and 8 provide optically isolated solid-state relay outputs for fast cutoff operations.
|
REDUNDANCY
YES
with redundant IOTA configuration
|
|
PRODUCT PROFILE
Pulse data where
measurement integrity matters. The CC-PPIX01 is the Series C Pulse Input Module associated with the Experion C300 controller. It processes pulse-generating field signals and makes pulse-derived process values available to the control environment.
CORE FUNCTION
Linear counting, PV generation and pulse measurement, with support for quadrature input in custody-transfer applications.
|
|
||||||||||||||||||||||||||||
|
SIGNAL PROCESSING
From pulse train
to process value. |
|
|
Input Thresholds
High setting: Low-to-High 8.4 V; High-to-Low 7.7 V.
Low setting: Low-to-High 2.8 V; High-to-Low 2.0 V. |
Excitation Arrangement
Internal 24 V operation or external user-supplied excitation from +5 to +30 VDC can be selected for the pulse input connection.
|
|
SERIES C / SYSTEM RELATIONSHIP
The module is part of a larger I/O architecture.
Series C I/O combines the I/O module with field termination around the IOTA architecture. The IOM plugs onto the IOTA, while field wiring, signal conditioning, field-power distribution and network connections are integrated into the Series C arrangement.
|
|
|
PULSE INPUT
CC-PPIX01
8-point pulse architecture with mixed single/dual configuration.
|
→ |
IOTA
CC-TPIX01 / CC-TPIX11
Provides the termination and Series C mounting interface for the IOM arrangement.
|
→ |
CONTROL
Experion C300
Receives pulse-derived values for process monitoring and control applications.
|
|
APPLICATION ANGLE
Where pulse integrity becomes a process variable.
|
|
|
PROJECT / SPARE PART SUPPORT
Need to confirm a CC-PPIX01 replacement?
Send the exact model, quantity, destination and required date. We can also help check the relationship between the IOM, IOTA and installed Series C configuration before an order is finalized.
ORDER CHECKPOINT
Part Number • Quantity • Destination • Required Date • Machine/System
|
|
||||||||
|
DELIVERY
3–5 Days
|
WARRANTY
12 Months
|
PACKAGING
Brand New
|
DELIVERY WAY
E-packing / FedEx / EMS / TNT / DHL / UPS
|
PAYMENT
T/T
|
|
AFTER-SALES
Return & Replacement
|
